Summary of Contents for Kora Pro 3D PC
- Page 1 Quickstart Guide Kora Pro 3D PC Printer Rev001/01/2018 Kora Pro PC...
- Page 2 'Kora Pro 3D PC Printer Firmware Manual See also ' for detailed operation of the machine This file is located on the USB via the built-in LCD Screen and Jog Wheel controller. Stick Drive supplied with the machine in the sub-directory /Kora/Instructions Rev001/01/2018 Kora Pro PC...
-
Page 3: Machine Overview
14. CPU Motherboard 15. SD Card Slot 16. CPU Power 'ON/OFF' Button 17. Filament Spool Holder 18. Power Supply Cable 19. Power Supply Switch 20. Mechanism Support Rods 21. Main HOT END Block 22. Drive Belts Rev001/01/2018 Kora Pro PC... -
Page 4: Removing The Packaging
WARNING: Only lift the Kora Pro 3D PC by the metal frame, NEVER lift by the printing mechanism, support rods, conduit wiring loom or toothed belts. See ‘Removal Guide Sheet’ Supplied with the machine packaging. -
Page 5: Initial Setup
4. Attach Mains Power Cable, as shown below and turn on Printer Power Supply Switch then press and release the CPU Power Button located to the right of the CPU panel (shown above in blue or green). Rev001/01/2018 Kora Pro PC... - Page 6 Repetier-Host (no donation) - https://www.repetier.com/download-now/ For users unfamiliar with Repetier-Host, full details of Repetier-Host set-up for the Kora Pro 3D PC please refer to the document ‘Instructions_RepetierHost_KoraPro3DPC_Rev01.pdf’ - located on the USB Stick Drive supplied with the machine in the sub-folder /Kora/Instructions.
-
Page 7: Loading The Filament
With one hand gently squeeze/pinch the filament extruder arm as shown below, and carefully feed the filament up through the 'rectangular nipple' past the filament drive gear and up into the PTFE feeder tube. Do not over squeeze/pinch the filament extruder during filament loading as this will make feeding the filament more difficult. Rev001/01/2018 Kora Pro PC... - Page 8 NEVER shut down the built in PC or turn off the Mains Power Supply if the Nozzle temperature is showing above 60⁰C on the Printer LCD screen - failure to follow this instruction can cause a machine Nozzle blockage. If this is done in error - immediately restoring the power will avoid possible Nozzle blockage. Rev001/01/2018 Kora Pro PC...
- Page 9 (to lower printer bed) and repeat test from 'Note:' (above). Continue this procedure until the lowest LED on the hot end PCB illuminates when the nozzle is just touching the bed. Rev001/01/2018 Kora Pro PC...
- Page 10 7. You can repeat the process as often as you like, until completely satisfied that the Nozzle is lightly touching the Printer Bed in all positions. To repeat if required, start again at step b)1. above. Rev001/01/2018 Kora Pro PC...
- Page 11 60⁰C. Shut down the onboard PC by following the usual Windows 10 shut down procedure. Then turn off the mains power supply using the switch next to the mains power supply cord plug. Selecting ‘Cooldown’ from within the ‘Quick Settings’ menu will disable all machine heaters. Rev001/01/2018 Kora Pro PC...
- Page 12 Rev001/01/2018 Kora Pro PC...
