OWNER'S MANUAL
JHub TABLET
TEAMBMPRO.COM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JHub and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BMPRO JHub

  • Page 1 OWNER’S MANUAL JHub TABLET TEAMBMPRO.COM...
  • Page 2 To learn more about the BMPRO range of products, please visit our website teambmpro.com TEAM BMPRO...

  • Page 3: Table Of Contents

    Pairing APPENDICES Specifications WARRANTY TERMS AND CONDITIONS Designed by BMPRO, one of Australia’s leading power solution experts, the BMPRO range of MANUAL PART 034722 products are proudly Australian-Made in Melbourne, Victoria and represent a high-quality REV 7.0 product that will provide years of service.

  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS Please read the Safety Precautions before installing or using the JHub Tablet. Be sure to observe all precautions without fail. Failure to observe these instructions properly may result in personal damage, or personal injury which depending on the circumstances may be serious and cause loss of life.

  • Page 5: About The Jhub Tablet

    BMPRO’s JHub Tablet is a portable app-driven RV monitor and control hub that operates with BMPRO’s J35 Battery Management System via the ControlNode. The JHub Tablet provides a new level of comfort and knowledge about the caravan including: 9 The freedom to operate caravan features, including lights, hot water, slide-out  ...

  • Page 6: Description Of Parts

    DESCRIPTION OF PARTS JHub TABLET Figure 1: The JHub Tablet Power Turn JHub Tablet on/off and turn tablet screen on/off. microUSB Input To charge the JHub Tablet. Return Navigate to previous page. Main Screen Navigate to JHub Tablet’s main screen.

  • Page 7: Jhub Application

    JHub APPLICATION HOME SCREEN Figure 2: The JHub Home Screen Settings Menu Access to the JHub App settings and functions and Owner’s Manual. Pairing Status Indicates pairing status between JHub Tablet and ControlNode. Please be aware that when BLUETOOTH ICON...
  • Page 8 Battery Icon Enables Sleep Mode the J35 will provide power to the CAN bus. This allows you to continue to monitor battery consumption from the battery monitor. However, power to the load terminal block will be turned off and you will not be able to use your battery monitor to power caravan loads.
  • Page 9 12. Tanks Monitor water levels of up to 4 water tanks. Tank properties, such as name, water-source (i.e. fresh or grey water) are configurable via the Settings Menu. When a ‘Fresh’ tank is almost empty, the lowest water level segment of the tank will turn red to indicate the tank is almost out of water.

  • Page 10: Using Your Jhub Tablet

    30 seconds to pair your JHub. 5. If the app is not automatically launched, launch the JHub app on your JHub and press the “Scan” button and it will now search for the nearby ControlNode devices.
  • Page 11 6. Select the device with the number that corresponds to the last six digits of the serial number of the ControlNode you wish to pair to. 7. After a successful connection, the LED status indicator on the ControlNode will turn OFF and the Bluetooth icon in the JHub will turn from red to blue.
  • Page 12 When you clear the memory on the ControlNode, the Bluetooth connection to all mobile devices already paired to, but not in Bluetooth range with the ControlNode will be lost. To use the JHub App on these devices again, these devices will need to be re-paired.

  • Page 13: Configuring A New Battery

    4. Scroll Down to the Battery Profile and select the appropriate battery type, Lead Acid (default) or LiFeP04. Figure 9: Configuring a new battery from the JHub App settings. 5. Return to the JHub Home screen by the arrow in the top left of the screen.

  • Page 14: Controlling Loads With The Jhub App

    CONTROLLING LOADS WITH THE JHUB APP Controlling the caravan’s load from the JHub App is as simple as a push of a button. A tan icon indicates that the load is on, grey - the load is off and blue - the load is unable to be used.

  • Page 15: Pairing And Using Sensors

    PAIRING AND USING SMARTCONNECT SENSORS Pairing SmartSense Gas Bottle Level Sensor 1. Enter SmartConnect screen from the JHub Home screen 2. Press the “Add” button displayed in top right corner. 3. A notification message will appear with instruction on how to pair.
  • Page 16 7. The gas bottle should appear on the SmartConnect page as per below. Figure 13: Gas bottle level after Successful Pairing 8. To unpair, press the red “Unpair” under the corresponding gas bottle. Figure 14: Unpairing the SmartSense gas bottle level sensor...

  • Page 17: Pairing Smartpressure Tyre Sensor

    Pairing SmartPressure Tyre Sensor 1. To pair the tyre sensor, press the “Pair” button at the wheel location where you want to install the tyre sensor. Figure 15: Adding SmartPressure tyre sensor 2. After Pressing the “Pair” button, tighten the lock nut on the tyre with the provided tool.
  • Page 18 4. If pairing was unsuccessful, a notification message will appear “Pairing Failed: Cannot Detect Sensor” along with “Try again” and “Cancel” buttons. Figure 18: SmartPressure tyre sensor pairing failure 5. To unpair the SmartPressure sensor, press the “Unpair” button below the SmartPressure tile, and then press the red “Unpair”...

  • Page 19: Pairing Smarttemp Temperature Sensor

    Pairing SmartTemp Temperature Sensor 1. To pair the temperature sensor, press the “ADD” button. Figure 20: Adding SmartTemp temperature sensor 2. A list will appear to select the intended temperature sensor location. Figure 21: Selecting SmartTemp temperature sensor location 3. Turn on the temperature sensor by pressing and holding the power button on the temperature sensor for 3 seconds.
  • Page 20 5. After pairing is successful, temperature sensors will be listed. Figure 24: Successful pairing of the SmartTemp temperature sensor 6. To unpair the SmartTemp sensor, press the “Unpair” button below the SmartPressure tile, and then press the red “Unpair” button to complete the process of unpairing the sensor.

  • Page 21: Setting Sensor Alarms

    SmartPressure Tyre sensor follow the below instructions. 1. Press the “Menu” button in the top left corner of the App homepage and select “Settings” from the list. Figure 26: JHub menu list 2. Press the “Settings” button in the Sensor’s tile. Figure 27: Selecting Sensors settings...

  • Page 22: Servicing

    Figure 29: Warning signs SERVICING Do not attempt to service the JHub Tablet yourself, OR dismantle, modify or repair the JHub Tablet yourself; this will void your warranty. If your JHub Tablet requires servicing, please consult your Jayco dealer for assistance.

  • Page 23: Faqs And Troubleshooting

    I’ve charged the JHub Tablet, but the screen is off? Check the following: 1. The JHub Tablet may be off. Press and hold the JHub Tablet power button to see if it will turn on. 2. Ensure the switch connected to the J35 Load Isolation input is not activated as this will turn power to the tablet charger off.

  • Page 24: Controlnode

    DATE AND TIME How do I set the date and time on the JHub Tablet? To set date and time, return to the tablet homescreen and click on the settings icon.

  • Page 25: Load Control

    J35 will flash a solid red. Should you encounter any faulty loads, please contact your caravan dealership. None of my loads appear to be powered and I can’t use the JHub App to power the loads on again? In this situation, when you attempt to power loads from the JHub App, the resultant pop-up message will help to diagnose why the loads are no longer powered.
  • Page 26 Figure 9: Low voltage mode is switched on THERE IS NO BLUETOOTH CONNECTION All icons in the JHub App will be blue. The Bluetooth Connectivity Icon will be red. This message will appear if: 1. The switch connected to the J35 Load Isolation input is activated –...

  • Page 27: Pairing

    PAIRING I can’t pair my JHub Tablet? If you are having difficulty pairing the JHub Tablet to the ControlNode, close the JHub App then check the following: 1. Go to the tablet’s Settings menu (figure 7) and make sure Bluetooth is turned on 2.
  • Page 28 ControlNode memory (the LED Status Indicator on the ControlNode will flash red). The ControlNode will then automatically flash green for up to 30 seconds to indicate that it’s ready to pair. You may now use the JHub App to scan for the ControlNode.

  • Page 29: Appendices

    APPENDICES SPECIFICATIONS JHub Tablet Input Voltage: 5V DC Input Current: Charger Input Voltage: Communication/Charger Cable: USB-to-microUSB Weight: 0.5 kg...

  • Page 30: Warranty Terms And Conditions
