Summary of Contents for HazSim Pro 1.0
- Page 1 HazSim Pro 1.0 User Manual 3.20.2019 V1.2 ─ HazSim LLC PO Box 3642 Palos Verdes, CA 90274 310-997-9030 ...
-
Page 2: Table Of Contents
Startup Sequence 2.1.1. HazSim LAN 2.1.2. HazSim Server 2.1.3. HazSim Handheld 2.2. Turning Off the System 2.3. Charging the HazSim Handheld Operating the System 3.1. Selecting a Meter 3.2. Meter Control Buttons 3.3. Controlling the Meter 3.4. Asking Questions Advanced Features ... -
Page 3: Overview
1. Overview The original HazSim Pro (v1) system is made up of three main parts. The server, the LAN, and the Hazsim handheld. The system is contained with all accessory cords and a confined space probe in a Pelican case. ... -
Page 4: Hazsim Lan
HazSim handhelds. The LAN will work up to a one thousand foot range, which is about the ... -
Page 5: Hazsim Handheld
The HazSim handheld, once connected to the server via the LAN, will become any meter chosen by the instructor on the server. The HazSim has a power on/off button and touch screen for ‘answering’ questions and ‘confirm’ power off of the unit. The HazSim handheld ... - Page 6 2.1.3 STEP THREE - Turn on the HazSim handheld by pressing and holding the power button (Figure 06) located on the top of the HazSim for at least 2 seconds. Wait for the startup to complete, approximately 30 seconds. When the device has completed ...
-
Page 7: Turning Off The System
Select the ‘Power’ icon then select ‘Shut Down’. Wait until the server turns off before storing. To turn the HazSim handheld off, press and hold the power button for at least 2 seconds; a ‘Power Off’ option will appear on the screen of the HazSim, select ‘Power Off’ and the unit ... - Page 8 Figure 09: M eter Control Window for standard Four Gas meter. Using the touch screen or cursor, the instructor can manipulate the values shown on the HazSim handheld up or down accordingly to create a simulated training environment. ...
-
Page 9: Meter Control Buttons
Change Meter - Opens meter select popup window Buzz Meter - Press with cursor or touch and hold to activate the alarm on the HazSim handheld in order to get the student’s attention back to the meter during training. This ... -
Page 10: Controlling The Meter
Norm-All returns ALL ‘gases’ to normal. To change meters entirely, simply select the change meter icon on the meter control screen and the previous list of meters will show. Select a new meter from the list and the HazSim will change to the selected meter. ... - Page 11 Edit/Add Questions Your HazSim Pro 1.0 is delivered with a complement of standard questions sorted in different question databases. Switch question databases with the Change Questions list button on the meter control screen. To add a new question select Edit Question and a new ...
- Page 12 Alarms Your HazSim Pro 1.0 system has several factory preset alarms based on industry standards but may not be the same as your local protocol. Select the Edit Alarm button and the Alarm edit window will open as shown in Figure 09. ...
- Page 13 ● Edit the right box to the desired alarm level ● Closing the window will save what was entered ● ‘Remove alarm’ will remove each alarm from the bottom of the list up ● Check with HazSim if alarm is correct before using in training. ...
- Page 14 Batteries - Handheld batteries are designed to be quick-charged 8 to 12 hours prior to training but do not hold a charge during storage so require charge before use. The batteries are NOT user serviceable. Contact HazSim for repair or replacement. ...
-
Page 15: Maximizing Range
In general if the instructor can see the LAN, and the LAN can ‘see’ the students with the HazSim, the range should be good. If you are training in an area with thick concrete or steal, several feet below grade, reinforced vaults, or reinforced ships. ... - Page 16 Out of range, behind obstacle which blocks signal, check LAN, server off (also see connection issues) Nothing on HazSim screen HazSim is off, HazSim is booting up (blank for a few seconds) HazSim screen shows Logo HazSim is ‘on’ but not connected to server...
