Summary of Contents for HiBoost Travel 4G 2.0
- Page 1 Boost Your Bars User Manual Travel 4G 2.0 C27-5S-BTW...
-
Page 2: Table Of Contents
Table of Contents Package Content ................2 Introduction ..................3 How Signal Boosters Work ............... 3 Pre-Installation Instructions ............. 4 Installation – Signal Supervisor App ..........5 Installation – Manual Method ............6 FCC and IC Statements ..............9 Technical Specifications ..............11 Return and Warranty Policies ............ -
Page 3: Package Content
Package Content Product Image Product Name Travel 4G 2.0 Model C27-5S-BTW Travel 4G 2.0 Kit Components Indoor Antenna Outdoor Magnetic Power Supply Antenna Warning: Un-authorized antennas, cables, and/or coupling devices are prohibited by new FCC rules. Please contact FCC for details: 1(888)-CALL-FCC... -
Page 4: Introduction
Introduction Thanks again for purchasing a HiBoost Travel 4G 2.0 Booster. Our new and improved travel signal booster are precision-engineered products that improve cellular reception inside of vehicles. HiBoost’s exclusive cloud-based Signal Supervisor mobile application allow users to monitor the live status of HiBoost cell phone signal boosters remotely from a mobile device anywhere at any time. -
Page 5: Pre-Installation Instructions
Pre-Installation Instructions HiBoost’s Travel 4G 2.0 vehicle booster unit and antennas must be strategically placed in order to perform and provide maximum coverage. The HiBoost Signal Supervisor app will allow users to communicate to the Travel 4G 2.0 signal booster via Bluetooth. Once registered, the user can remotely monitor the travel booster’s performance. -
Page 6: Installation - Signal Supervisor App
Step 2: Create a New Account and Log-in • Launch the app on your mobile device • Select the HiBoost Server • Log-in with an existing account create a new one Step 3: Register the Booster by adding a device on the home menu Go to My Devices >... -
Page 7: Installation - Manual Method
Installation – Manual Method Before beginning the installation, it is important that users survey and plan the layout of the vehicle booster system. Please review the following instructions before attempting to install this system. Mount or place the indoor antenna somewhere near the front of the car’s dashboard and connect it to the booster Note: Ensure that the front of the patch is facing in the direction where you would want signal to be distributed. - Page 8 Mount the magnetic antenna to roof of the vehicle towards the rear end of the vehicle and connect it to the booster Plug-in the DC power supply and power on the booster Note: The booster will flash blue lights that will last for about 20 seconds while it is adjusting to the current network environment.
- Page 9 Check that the booster is turned on and the DC power outlet is plugged into the DC 12V port or lighter adapter For more information or technical support, please contact our team. Phone: (972) 870-5666 (Mon-Fri, 9 am – 5 pm CST) Email: support@hiboostusa.com Website: www.hiboost.com...
-
Page 10: Fcc And Ic Statements
FCC and IC Statements FCC RF EXPOSURE STATEMENT This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instruction for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. - Page 11 • Consult the dealer or an experienced radio/TV technician for help Changes or modifications not expressly approved by HiBoost could void the user’s authority to operate the equipment. For a complete list of antennas and cables approved for use with these boosters see Authorized Kitting Options FCC 27.50(d)(4) Statement: Fixed, mobile, and portable (handheld) stations operating in...
-
Page 12: Technical Specifications
Technical Specifications RF Parameter Uplink Downlink LTE（ABC） 698-716MHz 728-746MHz LTE（C） 776-787MHz 746-757MHz Frequency CDMA 824-849MHz 869-894MHz Range 1850-1915MHz 1930-1995MHz 1710-1755MHz 2110-2155MHz Max. Gain 50 dB Max. Power UL 22 ± 2dBm DL 8 ± 2 dBm Electrical Parameter Power Adapter Input DC12-24V, Output DC5V/3A Power Supply Input AC 100-240V, Output DC 5V/3A... -
Page 13: Return And Warranty Policies
30-days with proof of purchase. Please contact the HiBoost customer support. 3-Year Warranty: HiBoost signal boosters and kits are warranted for 3 years. HiBoost will repair or replace the unit and will cover the cost of delivery for consumers located within the continental U.S and Canada. - Page 15 HiBoost 6210 N Beltline Rd. #110 Irving, TX 75063 (972) 870-5666 www.hiboost. support@hiboostusa.com www.hiboost.com...
