MINI-MASTERZONE
Zone Thermostat
Terminals
Zone Damper
Connections
Zone Damper Motor
Test Button
Installation..............................................2
Operation...............................................3
HVAC Equipment Set-Up.......................... 3
Checkout............................................... 3
Wiring................................................. 3-4
Troubleshooting.....................................4-5
Form 2263-110506
System Mode Indicator LED
System Mode Indicator LED
Table of Contents
MMP2 Installation and Operating Instructions
ZONING SYSTEM
™
MMP2
Features
Power Indicator LED LED
Zone Calling Indicator LED
Sensor Jumper
Leaving Air Sensor
Terminals
24VAC Transformer
Terminals
HVAC Equipment
Terminals
