WAYNE COMBUSTION SYSTEMS
801 GLASGOW AVE.
FORT WAYNE, IN 46803
PHONE: (260) 425-9200
(855) WAYNECS
FAX: (260) 424-0904
www.waynecombustion.com
Manual 64714-001 | Revision A | Publication Date: 9/27/2019
NOTE: Dimensions in () are informational only. English values take priority.
Electrical power supply: 120V/60Hz 1 Ph.
READ THIS MANUAL BEFORE USING THIS PRODUCT. FAILURE TO FOLLOW THE INSTRUCTIONS AND SAFETY
PRECAUTIONS IN THIS MANUAL CAN RESULT IN SERIOUS INJURY OR DEATH. KEEP THIS MANUAL FOR FUTURE
REFERENCE. INSTALLER: LEAVE THIS MANUAL WITH THE END USER.
INSTALLATION OF THE BURNER MUST BE DONE BY A QUALIFIED INSTALLER IN ACCORDANCE WITH
REGULATIONS OF THE NATIONAL FUEL GAS CODE ANSI Z223.1/NFPA54, AND IN COMPLETE ACCORDANCE WITH
ALL LOCAL CODES AND AUTHORITIES HAVING JURISDICTION.
A QUALIFIED INSTALLER IS THE PERSON WHO IS RESPONSIBLE FOR THE INSTALLATION AND ADJUSTMENT OF
THE EQUIPMENT AND WHO IS LICENSED TO INSTALL GAS-BURNING EQUIPMENT IN ACCORDANCE WITH ALL
CODES AND ORDINANCES.
DO NOT STORE ANYTHING, INCLUDING THIS MANUAL,
INSIDE THE BURNER ENCLOSURE
(800) 443-4625
SC80 iHEAT SYSTEM
For Bambino Oven
Maximum Input
60,000 Btu/hr (17.6 kW)
Minimum Input
20,000 Btu/hr (5.9 kW)
Turndown
Fuels
Natural & L.P. Gas
Maximum Inlet
Pressure
Minimum Inlet
5.5" w.c. Natural
Pressure
SC80
3:1
14" w.c. Natural
14" w.c. LP
11" w.c. LP
Advertisement
Table of Contents
Troubleshooting
Summary of Contents for Scott Fetzer Wayne iHEAT SC80
- Page 1 WAYNE COMBUSTION SYSTEMS 801 GLASGOW AVE. SC80 iHEAT SYSTEM FORT WAYNE, IN 46803 PHONE: (260) 425-9200 For Bambino Oven (855) WAYNECS (800) 443-4625 FAX: (260) 424-0904 www.waynecombustion.com Manual 64714-001 | Revision A | Publication Date: 9/27/2019 NOTE: Dimensions in () are informational only. English values take priority. SC80 Maximum Input 60,000 Btu/hr (17.6 kW)
- Page 2 INSTALLATION LOG BURNER MODEL: SPECIFICATION NUMBER: FUEL (NATURAL OR GAS ORIFICE DRILLED PROPANE): SIZE: INLET GAS PRESSURE (%): (%): CO (PPM): (in. w.c.): INSTALLER’S NAME: CONTRACTOR NAME: CONTRACTOR ADDRESS: CONTRACTOR PHONE NUMBER: CONTRACTOR LICENSE #: DATE OF INSTALLATION: COMMENTS ABOUT INSTALLATION/START UP: BURNER/APPLIANCE SERVICE LOG SERVICE COMPANY...
-
Page 3: Overview Of Safety Warning System And Your Responsibilities
OVERVIEW OF SAFETY WARNING SYSTEM AND YOUR RESPONSIBILITIES The safety of you and others depends upon you thoroughly reading and understanding this manual. If you have questions or do not understand the information presented in this manual, please call Wayne Combustion Systems or see www.waynecombustion.com. - Page 4 Hazard Level Pictogram Type Free Text Fire or Failure to follow safety warnings exactly could result in serious injury, Explosion death or property damage. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
-
Page 5: Table Of Contents
CONTENTS OVERVIEW OF SAFETY WARNING SYSTEM AND YOUR RESPONSIBILITIES ..............2 DESCRIPTION OF SYSTEM AND COMPONENTS ......................5 System Description ..............................5 Component Functions ...............................5 INSTALLATION ................................6 Mounting the Burner Enclosure ..........................6 Sizing and Inspection of Gas Piping ...........................8 ELECTRICAL WIRING OF BURNER ..........................11 AS-SHIPPED INITIAL BURNER SETTINGS ........................ -
Page 6: Description Of System And Components
DESCRIPTION OF SYSTEM AND COMPONENTS System Description iHEAT is an electronically controlled gas/air modulation system that can be utilized with the SC80 burner to provide a variable heat source for an appliance. The components of the system include: a fan-assisted gas burner, a modulating gas valve, and an electronic control module that varies the speed of the burner fan and the gas flow rate through the gas valve. -
Page 7: Installation
INSTALLATION Mounting the Burner Enclosure The burner ships with mounting holes to bolt to the underside of the oven floor. These holes can support the full weight of the burner and enclosure. To mount the burner into the oven, first remove the front cover by loosening or removing the four nuts as shown: Nuts Figure 1 - Burner Cover... - Page 8 Separate the enclosure cover from the rest of the burner. Next, locate the mounting studs on the rear of the oven floor as pictured below: Figure 2 - Oven Floor Mounting Studs With the open side of the enclosure facing you, install the air tube into the hole shown above and put two bolts with washers into the holes shown below: Figure 3 - Inside of Burner Enclosure We recommend using two socket head hex screws and two washers under each head (provided with oven).
-
Page 9: Sizing And Inspection Of Gas Piping
Sizing and Inspection of Gas Piping GAS LEAK HAZARD Liquefied petroleum gas is heavier than air. All connections should be checked for leaks using a soapy solution applied to gas connections. Leaking gas will settle in low lying areas such as basements and trenches. - Page 10 The piping should be so installed as to be durable, substantial and gas tight. It should be clear and free from cutting burrs and defects in structure or threading. Aluminum tubing should not be used for the main gas supply. Joint compounds (pipe dope) should be used sparingly on male threads only and be approved for all gases.
- Page 11 Table 1 - Pipe Sizing Chart for Natural Gas (0-0.5 psi) with Straight Schedule 40 Metal Pipe Pipe Sizing Chart for Liquid Propane (11” w.c.) with Straight Schedule 40 Metal Pipe The following chart is based on 11” w.c. inlet pressure and a pressure drop of 0.5” w.c.. Special use: Piping sizing between single or second stage (low pressure regulator) and appliance.
-
Page 12: Electrical Wiring Of Burner
Before turning gas under pressure into piping, all openings from which gas can escape should be closed. Immediately after turning on gas, the system should be checked for leaks. This can be done by watching the 1/2 cubic feet test dial and allowing 5 minutes to show any movement, or by soaping each pipe connection and watching for bubbles. -
Page 13: As-Shipped Initial Burner Settings
AS-SHIPPED INITIAL BURNER SETTINGS This burner comes with the proper settings for a small dome oven. If, after installing the burner into the oven and testing the operation of the burner, anything is not functioning as it should, contact Wayne Combustion Systems Customer Support for further direction. -
Page 14: Dip Switches
Technicians: To calibrate the blower, complete the following steps once: Turn off power to the burner system, and wait for LEDs on the iHEAT board to go out. Position the dip switches on the iHEAT board such that dip switch 8 is on and all others are off. ... - Page 15 low pressure setting when following the directions below. The valve must be mounted with the modulating coil horizontal. The maximum rated inlet pressure to the gas valve is ½ psi (14” w.c.). The valve will be damaged if higher gas pressure is applied. The gas valve controls the pressure of the gas supplied to the burner in order to adjust the burner’s firing rate.
-
Page 16: Burner Commissioning
Turn the low pressure nut counterclockwise to reduce the pressure; turn clockwise to increase the pressure. Adjust until the desired pressure setting is achieved. Careful! Reducing the pressure too much or too quickly may cause the burner to go out. If this happens, turn the small nut clockwise ¼... -
Page 17: Diagnostic Lights
When the iHEAT board’s relay closes its contacts, 24 VAC is supplied to the ignition control. When this happens, the ignition control’s diagnostic LED will flash rapidly while the ignition control begins sparking. After successful ignition, the LED will light green and remain lit as long as a flame is detected. If the burner fails to light, the control will wait for the interpurge time, then spark again. -
Page 18: Troubleshooting Guide
TROUBLESHOOTING GUIDE Lights Possible Symptom Corrections Flash Valve Blower 24V/Cal Input Check to make sure burner switch is With burner switch on, check for 120 volts across L1 and Neutral terminals; repair if necessary. With burner switch on, check for 24 volts across 24 VAC terminals;... - Page 19 Lights Possible Symptom 24V/ Corrections Flash T-Input Valve Blower Check wiring connections at RELAY COM and RELAY N.O. terminals. Check wiring connections on ignition control. Verify 24 VAC input to ignition control and 24 VAC at valve terminals on ignition control during call for heat.
- Page 20 Lights Possible Symptom Blowe 24V/ Corrections Flash T-Input Valve Appliance runs, Verify proper gas orifice size for model oven appliance and type of gas. temperature at or near t-stat set Flash Check low pressure setting of point, slowly modulating gas valve; adjust as increases above necessary.
-
Page 21: Troubleshooting The Burner System's Most Common Issues
Troubleshooting the Burner System’s Most Common Issues Symptom Possible Corrections Thermocouple readings are high, Check polarity of thermocouple. Yellow lead goes to the positive low, or inconsistent. terminal; red lead goes to the negative terminal. Confirm good connection between thermocouple leads and temperature controller. -
Page 22: Information
INFORMATION Electrode Position – Factory Setting ¼”± ” Figure 11 - Electrode Positions, Factory Setting 64714-001 REV. A 8/27/19... -
Page 23: Wiring Diagram
Wiring Diagram Figure 12 - Wiring Diagram for Burner Enclosure 64714-001 REV. A 8/27/19... -
Page 24: Exploded View
Exploded View Figure 13 - Burner Exploded View 64714-001 REV. A 8/27/19... - Page 25 PARTS LIST 64719-001 TUBE/HOUS-SC80-iHEAT PAINTED 62411-110 WIRE,LEAD-12" 18GA GREEN 64641-003 VENTURI ASM.-SC80 ENCL 64053-SER MOTOR/BLOWER, FASCO (120V SPEC) 64164-SER MOTOR/BLOWER, FASCO (230V SPEC) 75125-001 BUSHING,HEX HEAD 3/4" X 1/2" 304SS 63913-001 MANIFOLD, SC80 SPECIAL 62815-096 ORIFICE-1/8(.096")/2.43MM (PROPANE GAS) 62815-136 ORIFICE-1/8(.136")/3.45MM (NATURAL GAS) 64642-001 REDUCER, BELL 3/4"...
-
Page 26: Warranty
WARRANTY LIMITED WARRANTIES FOR OIL AND GAS BURNERS, MADE BY WAYNE AND USED IN RESIDENTIAL INSTALLATIONS WAYNE COMBUSTION SYSTEMS (“WAYNE”) A burner so repaired will then carry the LIMITED warrants to those who purchase its Oil Burner Models WARRANTY equal to the unexpired portion of the for resale or for incorporation into a product of resale, original burner LIMITED WARRANTY.
