- Page 1 SpeedClean ® Innovative Maintenance Tools. MODEL SC-TC-60 Tube Cleaner OPERATING & MAINTENANCE INSTRUCTIONS...
-
Page 2: Table Of Contents
Thank you for purchasing SpeedClean’s SC-TC-60 tube cleaning machine. We appreciate SC-TC-60 your business and look forward to serving you in the future. As with all SpeedClean products, you can be assured that the finest quality components and workmanship have gone into this machine. -
Page 3: Important Safety Instructions
SC-TC-60 Important Safety Instructions WARNING! Read and understand all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious personal injury. Save these Instructions!! 1. Work Area • Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents. -
Page 4: Service
Use only SPEEDCLEAN recommended attachments. Don’ts • Don’t use the SC-TC-60 if it is not in good operating condition, is not completely assembled, or is damaged. Always inspect the unit to ensure there are no leaks. • Don’t operate without eye protection. -
Page 5: Grounding/Electrical Safety
Don’t use the unit in an environment or on objects that are above 175° F (79° C). • Don’t use unit with children in the immediate area. SC-TC-60 Grounding/Electrical Safety • Make certain that the power source conforms to the requirements of the equipment. -
Page 6: Overview
SC-TC-60 Overview The SC-TC-60 tube cleaner uses a brush on the end of a rotating, polymer-encased flexible steel shaft. As the operator feeds the rotating brush/shaft assembly through the tube, the brush or tool loosens any deposits (mud, sand, etc.) and water flows through the casing to flush them out. -
Page 7: Operating Procedure
8. After completing the job, always unplug machine before disconnecting water supply. Running a shaft “dry” may damage the seals. CAUTION: The SC-TC-60 is designed to be used wet or dry — NOT BOTH. It is equipped with a water seal. If used dry, the water seal will no longer prevent water leakage. -
Page 8: Troubleshooting
• Solenoid valve supply pressure insufficient. not functioning • Remove hose and clean screen. • Replace solenoid valve, call Speedclean. Problem Not Listed, Call Speedclean Customer Service: 1-888-700-3540. Specifications SC-TC-60 Motor ½ HP, 230/115 VAC motor Power Requirements 230 V 50/60 Hz @ 4.5 A | 115 V 50/60 Hz @ 9.0 A... -
Page 9: Parts List
SC-TC-60 Parts List ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION SC-TC-BH Bottom Housing HWP-45E125M25F Elbow, 1/8” NPT SC-TC-TH Top Housing Solenoid Valve Motor, ½ HP Barbed Hose Fitting SC-TC-FPR Foot Pedal 1718 Elbow, ¼” Barb x 1/8” MPT EX-005... -
Page 10: Plumbing Diagram
Brush for 13/16” ID SC-TC-BN-13/16 Brush for 15/16” ID SC-TC-BN-15/16 Brush for 3/4” ID SC-TC-BN-3/4 Brush for 5/8” ID SC-TC-BN-5/8 Brush for 7/16” ID SC-TC-BN-7/16 Brush for 7/8” ID SC-TC-BN-7/8 Brush for 9/16” ID SC-TC-BN-9/16 Model SC-TC-60 Operating and Maintenance Manual... -
Page 11: Wiring Diagram
Wiring Diagram, 115V, 50/60Hz REVERSE Yellow Light Brown CV-GFCI MOTOR Blue 230 Volt Ground 240 VOLT NC NO White Ground FORWARD Orange Blue WIRING DIAGRAM, IRAM 240V 50Hz Wiring Diagram, SC-TC-60 50Hz Wiring Diagram, 240V, 50/60Hz © 2018 All Rights Reserved. -
Page 12: Warranty Information
It is recommended that any repairs be done by SpeedClean as improperly performed repairs will void the warranty. For repairs or warranty information DO NOT contact the place of purchase. Call SpeedClean Customer Service at (888) 700-3540.
