RT5000/4000
Important Information
All
persons
authorised
RT4000/RT5000 Inverter welding unit, should read the section
on safety, before any work is undertaken. Further information
is available in publication HSG118 'Electric safety in arc weld-
ing', which may be obtained from the Health & Safety Execu-
tive. Please contact your distributor should you not understand
any of the information within this document.
INSTRUCTION MANUAL
To maintain continued developments of our products we reserve the right to alter specifications as quoted without prior notice
to
use,
repair
or
service
Newarc Equipment Ltd.
UK's Leading Manufacturer Of Welding Equipment
Newcastle +44 (0) 191 295 0111
Aberdeen +44 (0) 1224 771 063
www.newarc.co.uk
Description
Constant Current Power Source
Integrated TIG
Processes
the
Advertisement
Table of Contents
Summary of Contents for NewArc RT5000
- Page 1 RT4000/RT5000 Inverter welding unit, should read the section on safety, before any work is undertaken. Further information is available in publication HSG118 'Electric safety in arc weld- ing', which may be obtained from the Health & Safety Execu- tive.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SECTION 1 — SAFETY 1 - General Precautions_______________________________________________________ 4 SECTION 2 — SPECIFICATION 2.1 - Description_______________________________________________________________ 5 2.2 - Specification_____________________________________________________________ 5 SECTION 3 — INSTALLATION 3.1 - Siting the RT5/4000________________________________________________________ 6 3.2 - Connecting to mains supply______________________________________________ 6 3.3 - Setting supply voltage tapping____________________________________________ 6 SECTION 4 —... - Page 4 Pay attention to fire and safety regulations in force at the welding site. The RT4000/RT5000 uses argon when TIG welding. This is an inert gas and can displace oxygen in the atmosphere lead- Remove all flammable or combustible materials from •...
-
Page 5: Section 2 - Specification
SECTION 2 — SPECIFICATION 2.1 - Description The RT4000 is a 400A (500A for the RT5000) constant current welding power source based on IGBT technology. The Inverter drive circuitry operates above the audio fre- quency spectrum making the RT4000/RT5000 virtually silent in operation. The high op- erational frequency also means that the RT4000/RT5000 is able to respond quickly to changing arc dynamics, making for a very smooth and stable arc. -
Page 6: Section 3 - Installation
SECTION 3 — INSTALLATION 3.1 Siting the RT4000/RT5000 Primary cable length Site the RT4000/RT5000 on a clean dry sur- Long cable lengths may reduce the perform- • face, preferable above ground level. ance of the machine, the welding arc may Make sure there is at least 20cm clearance •... -
Page 7: Section 4 - Operation
SECTION 4 — OPERATION 4.1 Operating Controls and Connections 4.2 Description of controls 1. TIG2/TIG 4 switch - This control switches between 2s and 4s operation (normal and latch). In TIG2 position, when the torch switch is pressed the arc ignites, when the switch is released the arc goes out. In TIG4 position, when the torch switch is pressed and released the arc ignites, to extinguish the arc you must press and release the torch switch again. - Page 8 Adjust the Arc Force control to your personal preference for the size and type of welding electrode to be used. The RT4000/RT5000 is suitable for welding all types of electrodes within the current rating of the machine (see Technical Data) The RT4000/RT5000 should never be used with arc-air gouging or cutting electrodes.
-
Page 9: Section 5 - Fault Finding And Maintenance
Make sure that the display is not reading ‘HOT’, • TIG welding follow the check list below, this will if it is, it means that the RT4000/RT5000 has over- cure most problems :- heated, normally by exceeding its ’Duty Cycle’, and the power stages of the machine have been shut down. -
Page 10: Maintenance
Note! All Electric shocks are potentially fatal, switch off the machine and unplug from the mains supply before carrying out any maintenance work. It is very important that the RT4000/RT5000 is regularly maintained. The amount of use and the working environment must be taken into account when scheduling the maintenance periods. -
Page 11: Section 6 - Electrical Diagrams
SECTION 6 — ELECTRICAL DIAGRAMS 6.1 - System Diagram RT5/4000... -
Page 12: Section 7-Parts Breakdown
SECTION 7—PARTS BREAKDOWN 7.1 - Component Locations RT5/4000... - Page 13 SECTION 7—PARTS BREAKDOWN 7.1 - Component Locations RT5/4000...
-
Page 14: Parts List
SECTION 7—PARTS BREAKDOWN 7.2 - Parts list for RT5000/4000 Item no. Description Part Number Bridge handle (x 2) M01084 20mm diameter knob M00033A Torch switch socket assembly M90790 Standby switch M70069A 50 / 70 panel mount Dix socket (x 2) - Page 16 Tel: +44 (0)191 295 0111 Tel: +44 (0)1224 771063 Fax: +44 (0)191 295 0077 Fax: +44 (0)1224 724536 Website: www.newarc.co.uk e-mail: sales@newarc.co.uk Guarantee New-Arc Equipment Ltd warrants that its goods and services are guaranteed to meet the specific performance under the stated conditions of use. New-Arc cannot be held responsible for general wear and tear or for failure occurring due to misuse or abuse arising out of circumstances outside the stated conditions of use.
