Summary of Contents for EE link GPT49
- Page 1 LTE FDD/TDD TRACKER For ASSET/Vehicle MODEL: GPT49 User Manual <GNSS + GSM/SMS/EGPRS+WCDMA+LTE FDD/TDD> Years Standby Tracking System...
-
Page 2: Table Of Contents
CATLOG Ⅰ. Product Features ........4 Ⅱ. Components and Accessories..6 Ⅲ. SIM Card Installation.......7 Ⅳ. Test & Installation ......8 4.1 Power on/off........ 8 4.2 LED Indicators......8 4.3 Install Device....... 9 Ⅴ. Setting & Inquiry......10 5.1 Web Platform & APP....10 5.2 SMS.......... - Page 3 This user manual is for reference only. If some contents and operation steps are inconsistent with those for the actual product, the latter will prevail. With GPT49 Years Standby Tracker, we can monitor your vehicle or asset by GNSS(satellite positioning system), GPRS/WCDMA/LTE FDD/LTE TDD...
-
Page 4: Ⅰ. Product Features
Ⅰ. Product Features ■ Support GSM/SMS/EGPRS/WCDMA/ LTE FDD/ LTE TDD (2G,3G,4G) ■ GNSS: GPS/Beidou/Glonass/Galileo/Qzss etc ■ Smart and easy to hide for installation. ■ Built-in 5500mAh zero self-discharge lithium Manganese disposable battery ■ Start Emergency mode, device will start real-time tracking and uploaded data through 2G/3G/4G regularly ■... - Page 5 Basic Specifications Voltage 3.0 VDC GPRS data(500mA); Working Current LTE/WCDMA data (700mA) Sleep Current 15uA GNSS Accuracy 5-15m GSM Band B2/ B3/ B5/ B8 WCDMA Band B1/ B2/ B5/ B8 LTE FDD: B1/B2/B3/B4/B5/B8/B28 LTE Band LTE TDD: <3s，<15s，<60s Hot/warm/cold Start Battery Capacity 6500mAh Dimensions (mm)
-
Page 6: Ⅱ. Components And Accessories
Ⅱ. Components and Accessories ■ Components -Top Front- (Towards sky) -Bottom - ■ Accessories 3M Velcro (default) -
Page 7: Ⅲ. Sim Card Installation
Ⅲ. SIM Card Installation Open the back door case, check if device is OK and accessories are intact Open device cover Insert SIM Card... -
Page 8: Ⅳ. Test & Installation
Note: ●Please power off device before installing or uninstalling SIM card. ●Open SIM’s traffic transmission to send data. ●If the PIN code of SIM card enable, please use your mobile phone to disable the PIN code. ●Please make sure SIM card has sufficient balance. -
Page 9: Install Device
slowly when device has searched the satellites and can be positioned. LED(indicates Network working state) Searching for Fast blinking GSM/WCDMA/LTE FDD/LTE TDD network GSM/WCDMA/LTE FDD/LTE Slow blinking TDD works normally BLUE LED(indicates GNSS Satellite signal state) Fast blinking Searching GNSS Satellites Slow blinking GNSS works normally 4.3 Install Device... -
Page 10: Sms
5.2 SMS You can write a positioning SMS sending to device to inquiry position, device will reply position SMS or map link once it wake up. You also can set administrator number to get remove alarm. The SMS commands please refer to the Operation Commands. -
Page 11: No Positioned
check them, you can check SIM card following next steps: 1） call SIM card of device and check if you can hear connecting ring. 2）Check if vehicle is in the area where there is no GSM/WCDMA signal. 3）Check if one device or all devices are offline in the area . -
Page 12: Position Drift
GNSS signal may be weakened if device is installed in the place with electromagnetic wave absorption material(such as metal blocks), special attention should be paid if there is metal thermal insulation layer or heating layer on the front windshield, so that the position accuracy will decline, and the severe ones will not be positioned. -
Page 13: Warranty Period
3）Warranty card is only valid for devices with the following IMEI. 4）Please take care of the warranty card and show it with the original purchase receipts when enjoying the warranty service. 7.2 Warranty period Since the date of purchase, passive waste host has one year warranty.
