Summary of Contents for LEPSI WATCH SCOPE
- Page 1 WATCH SCOPE USER GUIDE lepsi GENEVA...
-
Page 2: Table Of Contents
CONTENTS PAGE 3 GENERAL INFORMATION PAGE 4 INSTRUCTIONS INSTALLING THE APPLICATION WATCH POSITIONNING PAGE 5 ACTIVATION PAGE 6 PAGE 7 QUICK MEASUREMENT PAGE 8 COLLECTION PAGE 9 CALIBRATION PAGE 10 FEATURES PAGE 11 WARRANTY MANUFACTURER’S WARRANTY WARRANTY RESTRICTIONS LIABILITY... -
Page 3: General Information
WATCH SCOPE, EXPERIENCE YOUR WATCH Watch Scope is a instrument that enables you to make a full check up of your mechanical watches, made up of an Android or iOS application and a watch stand with an integrated electronic measuring system. - Page 4 S e n s o r A c t i v a t i o n c o d e...
-
Page 5: Activation
Watch Scope. 1 - First device to be activated - Make sure the check button “First device“ is ON. - Enter the activation code given with your Watch Scope. Send. - Click on A message box will appear : Enter and confirm your Email address. - Page 6 CONNECT THE WATCH SCOPE - 1 - - 2 - - 3 - Plug the Watch Scope Place the your watch Or place the Watch to your mobile device on the Watch Scope. Scope on your watch. using the 3.5mm cable provided.
-
Page 7: Quick Measurement
QUICK MEASUREMENT STARTING A MEASUREMENT : Click Start and let the application do the rest. STOPPING A MEASUREMENT : In the normal mode, the measurement will stop automatically. In the continual analysis mode, you need to click Stop . Lift angle : The lift angle is a characteristic of a watch’s calibre. This angle is used to calculate the amplitude. -
Page 8: Collection
CHART In the continual analysis mode, a chart will appear that allows you to determine the rate performance of your watch in real time. Normal curve : Average rate perfor- mance of the watch. Dotted curve : Current rate of the last 10s, 30s, 45s, 60s and so on, according to the selected duration. -
Page 9: Calibration
6 - Calibrating your mobile device To obtain a precise measurement, calibrating your Watch Scope is IMPERATIVE. Connect to the internet, start the calibration and wait 30 minutes or 3 hours (select your calibration mode). You only need to do this for first time... -
Page 10: Features
FEATURES Compatibility iOS 8.2 and higher (iPhone, iPad, iPod touch) Android 4.4 and higher Measurement Automatic vibration detection: 14,400 - 36,000 a/h Rate performance: 0.1 s/d resolution Amplitude: 1 ° resolution Beat error: 0,1 ms resolution Calibation via atomic clocks Weight and dimensions 30 g 38 x 38 x 15 mm... -
Page 11: Warranty
WARRANTY MANUFACTURER’S WARRANTY Watch Scope is guaranteed for 3 years after the purchase date against all manufacturing defects. The warranty is only valid upon presentation of proof of purchase or a valid receipt. WARRANTY RESTRICTIONS Damages due to normal wear and tear such as scuffs, scratches, marks, cuts, colour fading, etc. - Page 12 Published on August 16th 2015 For more information www.lepsi.ch...
