Auralex MAX Kit Series Installation & User Manual

MAX Kits
™
Installation & User Guide
Thank you for purchasing an Auralex
Kit:
VoxMAX ™ Designed for Voice-Over/
Vocal recording and easy-to-use instrument or
microphone baffling. The Auralex
Kit can also be quickly positioned to address
™
reflections within a small recording, monitoring
or mixing environment.
VoxMAX
™
DeskMAX / ProMAX v2
™
➊ Set up the stand and firmly
tighten the pole into the base.
Extent the top tube and firmly
tighten the adjustment collar.
➋ Remove star washer if present.
MAX Kit
®
EditMAX ™
configured baffling solution for recording but
VoxMAX
® can also be quickly positioned to create an
accurate monitoring environment for editing and
mixing in spaces where permanently mounted
acoustical treatments are not desired.
EditMAX
Setup
™
➌ Insert tube into the hole in the
center of the DeskMAX/ProMAX
v2 panel. This is best accomplished
by raising the panel over the top of
the stand pole and aligning it with
the hole in the panel. Gently pull the
panel down the pole to the desired
height. If the ceiling is low tilting
the stand and using assistance is
recommended.
DeskMAX ProMAX
™
Auralex
1-800-959-3343
9955 Westpoint Drive, Suite 101, Indianapolis IN USA 46256
Portable Treatment Kit.
™
Kit:
Designed as an easily-
™
➍ ProMAX v2 only: Orient the foam side towards you to absorb acoustical
reflections. Position the angled / reflective side of the
ProMAX v2 facing you to redirect acoustical energy relative to your
listening position to achieve the desired effect.
When using the reflective side the panel's overall angle can be adjusted
by rotating it on the stand. When using multiple pairs of ProMAX v2s
flanking the listening position, orient the angled reflective surfaces in
the same manner for a
balanced image and
soundstage.
To reverse the orientation of
the angled surfaces swap the
panel positions from one side
of the listening position to the
other.
v2
™
Acoustics, Inc.
®
| 317-842-2600 | Auralex.com
Kit:
ProducerMAX ™ A comprehensive and
easily-configured acoustical treatment solution
for recording. The Auralex ProducerMAX Kit
can be quickly positioned to create an accurate
monitoring and mixing environment in spaces
that do not permit permanently mounted
acoustical treatments.
ProducerMAX
™
ProMAX v2 Front ProMAX
™
1694-618.MAX Kits User Guide (03/05/2020 - 1:18 PM)
v2 Back
™
