- Page 1 PowerView ® Model PV25 Installation/Operations Manual 00-02-0839 2018-07-10 Section 78...
- Page 2 The latest version of this manual can be found at enovationcontrols.com Please read the following information before installing. BEFORE BEGINNING INSTALLATION OF THIS MURPHY PRODUCT: • Read and follow all installation instructions. • Please contact Enovation Controls immediately if you have any questions...
-
Page 3: Table Of Contents
Table of Contents Introduction ................1 Basic Functions ......................1 Main Menu ..................2 Parameter Menu ................6 Faults, Warnings and Indicators ..........7 Visual Indication ....................... 7 Indicators for Active Fault Codes ................7 Warning or Shutdown Screens ................. 7 Tier 4 and EU Emissions Standard – Stage IV ......8 Mounting and Installation ............9 Product Dimensions .................... - Page 4 THIS PAGE INTENTIONALLY LEFT BLANK...
-
Page 5: Introduction
Introduction The PV25 diagnostic device is an economical, compact package with advanced features. This J1939-compliant device provides parameter data, displays active and stored fault messages, provides Tier4/Euro Stage IIIB features, and tracks machine and engine hours. The PV25 is equipped with two buttons to quickly access a convenient menu, a graphic display, and two LEDs to indicate Active-fault Alarm or Shutdown status in a sealed enclosure that matches the PowerView line of displays... -
Page 6: Main Menu
Main Menu This section describes the items listed in the Main Menu. All interface with the PV25 is through the Up/Down Arrows. When power is applied to the unit, the Murphy logo displays first, and then the Parameter list begins to display. - Page 7 Menu Options Action Item Stored The Stored Faults (Stored FLTS) Use the Up & Down Faults menu shows the SPN, FMI, and arrows to scroll through OC for any stored faults. A the list if there is more message is sent to the ECU, and than one stored fault.
- Page 8 Menu Options Action Item Set 1-up Use this menu to set the Pressing the Up/Down parameters you want to monitor. arrows at the same time For a full list of the parameters selects the currently available, see page 6. displayed parameter. An ( * ) asterisk to the right of the Pressing the Up/Down arrows at the same time...
- Page 9 Menu Options Action Item Set Tier 4 Auto – Automatically displays all Momentarily press the Up & Down arrows to reach Tier 4 information (symbols) from the CAN and allows for Auto the Tier 4 menu. Select Regeneration of a Tier 4 engine and set a Tier 4 choice by pressing the Up/Down through CAN messaging.
-
Page 10: Parameter Menu
Parameter Menu The following lists the parameters that can be viewed on the PV25 Description Notes If set to OFF, the machine hours do not increment. However, if at any point Internal Machine hours machine hours were accumulated, that hour value maintains through power cycles. -
Page 11: Faults, Warnings And Indicators
Faults, Warnings and Indicators The PV25 provides two means for displaying faults and warnings: visual LEDs on the casing (Amber at the upper left, and Red at the upper right), and Active Warning screens listing the SPN, FMI, and OC. In addition, Tier 4/Euro State IV symbols display to indicate Tier 4 status if Tier 4 is set to Visual Indication •... -
Page 12: Tier 4 And Eu Emissions Standard - Stage Iv
Tier 4 and EU Emissions Standard – Stage IV *Murphy products are compliant with requirements for U.S. EPA Emission Standard Tier 4 and EU Emissions Standard Stage IV for diesel engines. These engines when fitted with a DPF (Diesel Particulate Filter) can self-clean the filter of particulates. This self-cleaning is known as Regeneration. -
Page 13: Mounting And Installation
Mounting and Installation Product Dimensions Connection Detail Typical Wiring Diagram 00-02-0839 - 9 - 2018-07-10... - Page 14 WARNING! READ NOTES below before installing the PV25. Note Use resistor between CAN_H and CAN_L line near PowerView (included in some cables or factory purchased panels). Resistor can be installed in the wire harness attached to Port A or a terminating resistor (Murphy P/N 7800480) can be attached to Port B.
-
Page 15: Specifications
Specifications Operating Voltage: 6.0 VDC minimum to 36 VDC maximum Power Supply Operating Current: 460mA max @ 12VDC 810mA max @ 24VDC Reversed Polarity: Withstands reversed battery terminal polarity indefinitely within operating temperature. Environmental Operating Temperature: -40°C to 70°C (-40°F to 158°F) Storage Temperature: -55°C to 85°C (-67°F to 185°F) Sealing: IP68 CAN Bus: SAE J1939 compliant...
