PlaSmart PlasmaCar Assembly Instructions

7
Align the steering wheel with the smaller front wheels,
so that the wide end of the steering wheel faces forward.
Note: When the front wheels are assembled and resting
on a flat surface, the smaller front wheels do not contact
the ground.
9
Push the cap into the steering wheel.
IMPORTANT!
8
This step is critical to the performance
of your PlasmaCar.
Use a 17 mm socket wrench to tighten the nut in the
steering column AS TIGHT AS POSSIBLE. Fit the wrench
onto the nut and turn until very tight.
Alternately, use the enclosed hex key and a screw driver
to tighten the nut AS TIGHT AS POSSIBLE.

Troubleshooting

The rear wheels may detach from their housing if the
PlasmaCar is subjected to overloading or impact. Fit
the wheel into its housing so that the flat sides of the
white clips contact the wheel housing. Snap the wheel
back into place.
If the steering wheel becomes loose or fails to propel
the PlasmaCar, the steering wheel nut may not have
been tightened enough during assembly. Remove the
cap from the steering wheel with a slot screwdriver
and loosen the nut with the hex key. Repeat steps 7
and 8, securing the nut as tightly as possible.
PlasmaCar
PlaSmart
Ottawa, ON, Canada. www.plasmacar.com

How it works

The only power source the PlasmaCar requires is the seemingly limitless energy
of a child. The PlasmaCar can reach exhilarating but child-safe speeds of up to
2.8 meters per second (3.1 yards per second).
Note: The PlasmaCar is not recommended for use on wooden floors. The wheels
may damage some floors.
1. Place the PlasmaCar on a smooth, flat surface.
2. Sit with the feet on the footrests, lean slightly forward,
and grip the steering wheel.
3. To propel the car forward, turn the steering wheel back and
forth continuously. To go in reverse, rotate the steering wheel
180 degrees.
4. To bring the the PlasmaCar to a stop, stop turning the wheel,
wait for the car to slow, and put your feet on the ground.
