12. GUITAR: GUITAR IN volume control
13. ECHO: Mic Echo control
14. MIC.VOL: Mic volume control
15. BASS
16. TREBLE
17. VOLUME: Control the master volume
18. FULL RECHARGE: Full charging LED
19. CHARGING: Charging LED ON
20. GUITAR IN: With a 6.3MM plug to connector
21. MIC IN: with a 6.3mm plug to connector
22. 3.5MM LINE IN
23. LINE OUT: RCA (Unbalanced signal) channel line output, used for
recording or another line out
24. LINE IN: LINE RCA input (Unbalanced signal)
25. DC IN 15V
26. POWER: Power Supply Switch
