- Page 1 SaMASZ Sp. z o.o. tel. (+48) (85) 664 70 31 ul. Trawiasta 1 fax (+48) (85) 664 70 41 16-060 Zabłudów e-mail: samasz@samasz.pl Poland www.samasz.pl OPERATOR’S MANUAL ROAD SHOULDER CUTTER RP 110 The orginal operator’s manual IN335EN002 ENGLISH Serial number 05.01.2015...
- Page 2 Well-proven design with thousands of machines in regular use in many countries and quality materials ensure high durability and reliability of SaMASZ machines. We congratulate you on the purchase of your new SaMASZ machine and wish you much pleasure and the very best work results through the years to come.
-
Page 3: Table Of Contents
OPERATOR’S MANUAL ROAD SHOULDER CUTTER RP 110 Contents page IDENTIFYING THE MACHINE.........................4 INTRODUCTION ...........................4 SAFETY PRECAUTION ..........................5 3.1. Safety rules ........................... 5 3.2. Safety labels ..........................8 3.3. Residual risk ..........................10 OPERATING ............................11 4.1. Intended use and design .......................11 4.2. -
Page 4: Identifying The Machine
RP 110 ROAD SHOULDER CUTTER OPERATOR’S MANUAL 1. IDENTIFYING THE MACHINE Each road shoulder cutter can be identified with a nameplate, which is permanently attached to the frame, as shown below Fig. 1. Fig. 1. Data place location Data plate includes:... -
Page 5: Safety Precaution
OPERATOR’S MANUAL ROAD SHOULDER CUTTER RP 110 3. SAFETY PRECAUTION CAUTION! The road shoulder cutter is a dangerous machine. The machine can only be operated by personnel who have learned this manual. Every user of the road shoulder cutter should be completely aware of the existing hazards and should know how to avoid them. - Page 6 For any break in the machine operation, disconnect the drive. ❑ The road shoulder cutter should be operated at 540 rpm of the PTO (applies to SaMASZ extension ❑ arms). All machine movements must be performed only from the operator’s seat. Do not control the ❑...
- Page 7 OPERATOR’S MANUAL ROAD SHOULDER CUTTER RP 110 Do not operate after dusk. ❑ Do not leave the tractor-arm system on slopes without additional protection. ❑ Do not operate with damaged or missing guards. ❑ Inspection and repair Perform any inspection, repair and maintenance works as well as cleaning parts or assemblies ❑...
-
Page 8: Safety Labels
RP 110 ROAD SHOULDER CUTTER OPERATOR’S MANUAL Qualifications of operator To provide safe machine operation each person being the machine operator must meet the following requirements: Operator should hold driving license, have ability to drive vehicles safely and know road traffic ❑... - Page 9 OPERATOR’S MANUAL ROAD SHOULDER CUTTER RP 110 N-100 Wear protective eyewear Wear protective gloves N-52 Wear protective clothing N-101 Wear protective helmet N-102 Wear ear protection N-103...
-
Page 10: Residual Risk
RP 110 ROAD SHOULDER CUTTER OPERATOR’S MANUAL 3.3. Residual risk CAUTION! There is a residual risk mainly due to incorrect behaviour of the machine operator and failure to comply with the instruction manual. CAUTION! When presenting the residual risk, the road shoulder cutter is treated as a machine which has been designed and manufactured in accordance with the state of the art on the date of its manufacture. -
Page 11: Operating
20 cm. A few crossings should be made to level the soil shoulders of higher height. The RP 110 road shoulder cutter is designed to work with the following extension arms: • KWT 550, KWT 550 E, KWT 550 EP, •... -
Page 12: Steerage
The road shoulder cutter is controlled by the extension arm via its individual control panel. 4.3. Transport position and drives The transport position of the road shoulder cutter attached to SaMASZ extension arm is in accordance with the transport position of the arm. See the Fig. 4. -
Page 13: Installing
OPERATOR’S MANUAL ROAD SHOULDER CUTTER RP 110 If the road shoulder cutter is installed on another type of an extension arm, the assembly of the machine and the extension arm should be folded to the most compact position. During the transport of the cutter-arm assembly, use all transport safety devices provided for the ❑... -
Page 14: Initial Adjustment
RP 110 ROAD SHOULDER CUTTER OPERATOR’S MANUAL Lift the machine slightly above the pallet and check the condition of the screw connections (see Table 1) and also check for any visible damage. Start the road shoulder cutter to check its correct connection and operation. -
Page 15: Operation
Respect work safety and traffic rules solely. ❑ keep hydraulic oil consumption for machine supply pump at max. 70-100 l/min. For SaMASZ ❑ extension arm such demand is achieved at tractor’s PTO shaft rpm of 540 rpm. Before starting the operation, it is recommended that the operator should adjust the road ❑... -
Page 16: Malfunctions And Their Repair
RP 110 ROAD SHOULDER CUTTER OPERATOR’S MANUAL remove the ignition key and secure the vehicle against uncontrolled movements or unintended ❑ start up, wear protective gloves and remove the part which causes the machine's locking. ❑ 4.10. Malfunctions and their repair... -
Page 17: Equipment And Fittins
CAUTION! SaMASZ is not liable for any damage resulting from the use of non-original parts and accessories. 6. OPERATING 6.1. Maintenance and service... - Page 18 RP 110 ROAD SHOULDER CUTTER OPERATOR’S MANUAL Examine torque of all bolts and nuts Table 1, ❑ Table 1. Torque values for bolts check the condition of hydraulic hoses and connections, ❑ check the condition of the cutting blades and, if necessary, renovate or replace them with new ❑...
-
Page 19: After-Season Maintenance And Storing
OPERATOR’S MANUAL ROAD SHOULDER CUTTER RP 110 The parts whose damage may pose threat to the operator’s health and safety are: the working tool and the damaged protective covers. 6.2. After-season maintenance and storing Carry out all the actions in accordance with the section: “Maintenance and storage”. -
Page 20: Specifictions
95 ± 1 dB 106 ± dB Amax 109 ± dB Cpeak Table 3. Extension arm operating range with RP 110 road shoulder cutter Extension arm type Operating range (arm + RP 110) KWT 550 5,8 m KWT 550 E... -
Page 21: Disassembly And Scraping
OPERATOR’S MANUAL ROAD SHOULDER CUTTER RP 110 10. DISASSEMBLY AND SCRAPING CAUTION! When removing and installing the machine, remember about personal protection equipment and environmental protection equipment. 10.1. Disassembly In the case of partial wear of the road shoulder cutter, it should be repaired by replacing the worn parts. -
Page 22: Warranty
RP 110 ROAD SHOULDER CUTTER OPERATOR’S MANUAL 11. WARRANTY 11.1. Warranty card The product quality has been checked and meets the required standards and regulations. ROAD SHOULDER CUTTER Type Serial no. Date of manufacture stamp Date of purchase Dealer signature... - Page 23 OPERATOR’S MANUAL ROAD SHOULDER CUTTER RP 110 8. The parts of the road shoulder cutter which are not subject to warranty due to natural wear and tear during operation: a) cutting blades, b) worm shaft, c) hydraulic motor, d) transmission,...
-
Page 24: Warranty Repairs Record
ROAD SHOULDER CUTTER OPERATOR’S MANUAL CAUTION: The SaMASZ Company is continually working on improvement and development of all types and models of tree stump grinders. For this reason the form, accessories and technology of delivered products can change. No claims can be made based on the data, illustrations or descriptions contained in this manual or the spare parts catalogue. - Page 25 SaMASZ Sp. z o.o. tel. (+48) (85) 664 70 31 ul. Trawiasta 1 fax (+48) (85) 664 70 41 16-060 Zabłudów e-mail: samasz@samasz.pl Poland www.samasz.pl...
