Included are interchangeable keystone jacks that allow this phone box to be configured
as follows:
The cable gland included is designed to allow pre-
terminated telephone or Ethernet cables to be
inserted into the phone box. Once tighten, the cable
gland seals around the cable preventing water from
entering the box.
Mounting
Mounting Feet
The (4) steel mounting feet included in the hardware
kit can be used to mount the enclosure to most
surfaces.
(4) Threaded inserts are provided on the rear of the
enclosure. Using the included screws, secure the (4)
mounting feet to the enclosure as shown.
These phone boxes can also be pole mounted using
the optional NMK Series Pole Mount Kits which can be
purchased by visiting www.ALTELIX.com
IS0095 Rev B 12/16/19
NF141206-T02/NF141208-T02 IP Phone Box Installation Guide
Accessory Kit Included
Got Questions?
We are here to help.
Contact us at:
sales@altelix.com
USA & Canada: 866-660-9434
International: +1 561-660-9434
