STRUMENTO MARINO SM133 User Manual

Yachting timer, swiss isa movement 8270b
Hide thumbs

Advertisement

Quick Links

Download this manual
STRUMENTOMARINO.IT
User Manual
Swiss ISA Movement 8270B
YACHTING TIMER
ref.code SM133

Advertisement

loading
Need help?

Need help?

Do you have a question about the SM133 and is the answer not in the manual?

Questions and answers

Summary of Contents for STRUMENTO MARINO SM133

  • Page 1 STRUMENTOMARINO.IT User Manual Swiss ISA Movement 8270B YACHTING TIMER ref.code SM133...
  • Page 2 BATTERY: SR927W BATTERY LIFE: 2 YEARS (Button A) Crown (Button B)
  • Page 3 PUSHERS AND INDICATIONS 1. Countdown indicator (10 minutes maximum) 2. Hour/second counter to display - Countdown seconds - Race timing hours - Number of hours and seconds counted 3. Hour hand 4. Date window 5. Minute hand 6. Central hand to display: - Countdown minutes - Race timing minutes 7.

  • Page 4: To Set The Time And Date

    TO SET THE TIME AND DATE SET THE TIME • Pull the crown to position 3. • Turn the crown anti-clockwise to set the time of the day (hour & minute) and the date. • Push the crown to position 1. Attention - The date changes at 00:00 midnight, not at 12:00 noon.
  • Page 5 TO SET THE COUNTDOWN (TIMER) The countdown timer allows the user to choose the time to be counted down up to the start of race timing. The user can set the countdown duration between 10 minutes and 1 minute. Adjustment of countdown is not allowed during the last minute.
  • Page 6 ACTIVATION OF COUNTDOWN (TIMER) in progress Display of countdown minutes Display of countdown seconds • Press A to activate the countdown, 2 beeps emit. • The small counter hand at 10H turns fast to make a turn and stop shortly at “60”, then countdown starts. •...
  • Page 7 COUNTDOWN PROGRESS BEEPER (TIMER) Once countdown is activated, there are beepers to communicate to the user about the progress of the countdown. • During countdown, 2 beeps emit every minute up to the last minute. Then: • 50” before the end of countdown, 1 beep emits. •...
  • Page 8 “SECOND CHANCE” COUNTDOWN ADJUSTMENT The user can at anytime during the countdown period adjust the countdown timer, except the last minute. Example: If the countdown was set at 10 minutes at the beginning with delay: • The user can, during the countdown runs, adjust it to 9 min. by pressing B.
  • Page 9 CHRONOGRAPH (until 96 hours) Departure date Press B to display Date of arrival the race/timing hours/seconds at the 10H counter • When countdown is finished, race timing starts automatically. • The central minute counter hand displays the race timing minutes (1 step every 12 seconds). The small hand at 10H counter displays the race timing hours from 0 hour to 24 hours, up to 96 hours maximum (1 step every hour).
  • Page 10 RACING TIMER START/STOP Stop: • Press A to stop the racing timer, 1 beep emits to confirm the racing timer «OFF». Start: • Press A again to start the race timing function, 2 beeps emit to confirm that the racing timer is engaged «ON».
  • Page 11 COUNTDOWN / RACING TIMER RESET Countdown reset : • Press A to stop the countdown, 1 beep emits. • Press B, the small counter hand at 10H is reset to zero (“60”), and the central hand returns to the previously set countdown start time.
  • Page 12 RE-INITIALIZING THE COUNTDOWN/CHRONOGRAPH (for reset only after battery change ) Following a battery change, an incorrect actuation, violent impact or exposure to a strong magnetic field, the countdown/racing timer counter hands may fail to revert to its original position (zero). Attention: Setting can be done only after having stopped and reset the countdown or the race timing.
  • Page 13 RE-INITIALIZING THE COUNTDOWN/CHRONOGRAPH (for reset only after battery change ) Reset of the small counter hand at 10H: • Pull the crown to position 2, and let it stay for minimum 1 second. Press A or B, the central hand advances fast and stops (not necessarily pointing to “12”).
