Summary of Contents for Optilia Flexia BGA
- Page 1 Instructions Manual Flexia BGA Inspection Systems This manual describes how to use Flexia BGA Inspection System Optilia Instruments AB...
-
Page 2: Table Of Contents
Contents 1. Safety and maintenance Instructions 2. About Flexia BGA 3. Mounting Flexia BGA 4. How to attach Background Illumination 5. How to calibrate magnifications of BGA lens in OptiPix 6. How to Inspect BGA solders 7. Zoom, Focus and Image tilt adjustments 8. -
Page 3: Safety And Maintenance Instructions
Do not scratch or hit front edge of the side viewing prisms onto hard objects! This precaution is important especially when you operate Flexia BGA mobile ion free hand. • Only use DC Power Sources provided or approved by Optilia. • Only use accessories provided or approved by Optilia. •... -
Page 4: About Flexia Bga
Stand ( UNC ¼ -20) Flexia BGA analogue is directly plugged to a video monitor or TV. Flexia BGA digital is plugged to PC or laptop via USB2.0. In addition, Flexia analogue can also be connected to a Laptop or PC via Optilia’s High speed USB2.0 or FireWire Frame Grabbers. -
Page 5: Mounting Flexia Bga
3. Mounting Flexia BGA Remove the lens-protecting caps and attach the BGA lens onto the Flexia as illustrated. 1. Remove the protecting caps from Flexia and BGA lens first. 2. Gently push the BGA lens inwards to click. (Snap position). -
Page 6: How To Attach Background Illumination
4. How to attach Background Illumination (Optional, only if you have purchased the Background illumination) Insert BGA lens carefully into the ring of the Illumination device. Align front side of the illumination to the white mark on front side of the BGA lens and fix it by tightening the screw. -
Page 7: How To Calibrate Magnifications Of Bga Lens In Optipix
5. How to calibrate magnifications of BGA lens in OptiPix (Optional, only if you have purchased “OptiPix Full” software) Zoom ring of BGA lens is marked by Greek numbers I, II, III and IV. These positions indicate different optical magnification of the lens and can be calibrated in OptiPix software to perform dimensional measurements. -
Page 8: How To Inspect Bga Solders
& Pinion roughly. Use the Rack & Pinion unit to slide down Flexia to a few millimeters above the BGA package. “Fine adjust” position of BGA package against optical head of Flexia BGA and move down Flexia BGA slightly and carefully to contact with the PCB surface. Do not press BGA lens to the PCB. -
Page 9: Zoom, Focus And Image Tilt Adjustments
7. Zoom, Focus and image tilt adjustment Image magnification as well as object distance of the BGA lens can be adjusted by turning “focus ring” of the lens. Horizontal plane of the image (Image tilt) can also be adjusted by rotating optical head of the BGA lens about its axis a few degrees. -
Page 10: Notes
Notes ………………………………………………………………………………………………… ………………………………………………………………………………………………… ………………………………………………………………………………………………… ………………………………………………………………………………………………… ………………………………………………………………………………………………… ………………………………………………………………………………………………… ………………………………………………………………………………………………… ………………………………………………………………………………………………… ………………………………………………………………………………………………… ………………………………………………………………………………………………… …………………………………………………………………………………………………... - Page 11 ………………………………………………………………………………………………… ………………………………………………………………………………………………… ………………………………………………………………………………………………… ………………………………………………………………………………………………… ………………………………………………………………………………………………… ………………………………………………………………………………………………… ………………………………………………………………………………………………… ………………………………………………………………………………………………… ………………………………………………………………………………………………… ………………………………………………………………………………………………… ………………………………………………………………………………………………… …………………………………………………………………………………………………...
- Page 12 All rights reserved. The information contained herein is designed only for use with Optilia Instruments AB,s video microscope Flexia BGA. Optilia Instruments AB is not responsible for any use of this information for other purposes. Optilia Instruments AB shall not be liable to the purchaser of this product...
