Summary of Contents for FeelTech SGP10 S Series
- Page 1 SGP10xxS Users Manual SGP10xxS series Direct Digital Synthesis (DDS) Signal Generator Users Manual Rev1.1 2013-12-5 20140314...
- Page 2 SGP10xxS Users Manual Thank you for purchasing our products, please carefully read the contents of the use’s manual before use, to ensure the normal use of the instrument. Introduction of the instrument This manual applies to each mode of SGP10xxS series Direct Digital Synthesis (DDS) Signal Generator.
- Page 3 SGP10xxS Users Manual Main technology indexes ◆ Signal Output function Output waveforms Sine wave, Square wave (Duty cycle adjustable) and Triangle wave (include sawtooth wave) ≥10Vp-p (signal output, no load)（MAX） Output amplitude About 0.1Vp-p (MIN) Output impedance 51Ω±10%(signal output) DC offset ±...
- Page 4 SGP10xxS Users Manual circuit, reliable and durable Operation feature Button-controlled, Knob-adjusted continuously Humidity: ﹤80% Conditions requirement Temp: 0~40℃ The function introduction of front panel Operating Guide 1. Press the button【Menu】 to switch between Frequency adjusting and Function adjusting. The detailed condition (frequency adjusting or function adjusting) displayed after “*”...
- Page 5 SGP10xxS Users Manual The frequency unit is MHz 3. As function adjusting, pressing the button 【】or【】to toggle among “WAVE”， “ DUTY” ， “COUNTER” ， “EXT.FREQ” ， “SWEEP” , “SAVE” , “LOAD”. 4. The “WAVE” shows the current wave state. Press the button【Wave】to toggle the current output of waveform among SINE, TRGL and SQUR.
- Page 6 SGP10xxS Users Manual （2） 、The “EXT.FREQ”means exterior frequency measuring function, which can measure the frequency of input signal from the port【Ext. Input】. 7. Press the button 【Save】 to save the value of current frequency, waveform and duty cycle into internal storage for loading next time. There are 10 storage positions from M0 to M9, which can be chosen by rotating the 【...
- Page 7 SGP10xxS Users Manual the front panel and you will find “J6” port on the right of DC Offset Adjust potentiometer. Dual-channel differential TTL electric level can be output through this port. 12. The【AMPL】knob adjusts the amplitude of output signal. 13. The【DC Offset Adjust】knob adjusts the DC offset of output signal. 14.
