Summary of Contents for LEYRO LCB 30
- Page 1 LCB 30 y LCB 50 Calibration Bath ManUal LCB 30 & LCB 50 CALIBRATION MICRO BATH MANUAL...
- Page 2 Leyro Instruments® doesn’t accept warranty and liability claims neither upon this publication nor in case of improper treatment of the described products. The document may contain technical inaccuracies and typographical errors. The content will be revised on a regular basis. These changes will be implemented in later versions.
- Page 3 9.0 Maintenance, cleaning and Re calibration 9.1 Maintenance 9.2 Cleaning 9.2.1 Cleaning the micro calibration bath 9.2.3 External cleaning 9.3 Re calibration 10.0 Failures 11.0 Dismantling, removal and waste disposal 11.1 Dismantling 11.2 Return 11.3 Waste disposal 12.0 LCB 30 and LCB 50 accessories...
-
Page 4: General Information
• Factory calibration and calibration by the Spanish association of calibration (ENAC / ISO 17025) are performed in accordance with international standards • For more information refer to: -Web page: www.leyro.net -Relevant technical sheet: LCB 30, LCB 50 -Technical service +3491283502 info@leyro.net 1.1 Symbology DANGER ... -
Page 5: Staff Qualification
... The different chapters of this manual contain other important safety instructions. 2.1 Use as planned The micro calibration bath is a portable unit for technical service, industrial and laboratory tasks. Leyro Instruments’ micro temperature baths or micro calibration baths are provided for calibrating thermometers, switches / thermostats thermos, pyrometers electrical resistance and thermocouples. -
Page 6: Specific Risks
For your safety and the micro calibration bath is equipped with a protection on independent temperature that disconnects the power supply of heating in case of excessive temperature inside the housing. After cooling must send the micro bath to control Leyro Instruments •... - Page 7 2.5 Safety instructions for using calibration liquids Calibration liquid water Only use distilled water, otherwise Tartar forms and micro bath deposit gets dirty. Calibration liquid silicone oil WARNING Only use the silicone oil recommended in this manual Read the safety data sheet before starting to work with silicone oil. The data sheet is available from the manufacturer or distributor.
- Page 8 Calibration 3.1 calibration certificate according to DIN EN 10204 Option: calibration certificate ISO 17025 ENAC For more technical details see data sheet from Leyro Instruments and order documentation. 3.1 LCB LCB 30 and 50 Micro calibration bath LCB 30 LCB 50 -35 ...
-
Page 9: Design And Function
4. Design and function Description The micro calibration bath is a portable unit for technical, industrial service task at the laboratory. Leyro Instruments’ micro calibration baths are provided for calibrating thermometers, switches / thermostats, electrical resistance pyrometers and thermocouples. The operational safety of the equipment is only guaranteed when used as planned (control of temperature sensors). - Page 10 Micro temperature bath model LCB 30/50 Micro Calibration Bath LCB 30/50 Isometric views of micro calibration bath series LCB Front and top model LCB 30/50 At the top of the calibration is the refill opening (60 mm x 110m / 2.36 x 4.33 in )
- Page 11 Block Potentiometer for the LIQUID stirrer PID controller Rear of the equipment At the rear of the instrument is the nameplate with the most important information about the specific model. In addition the serial number is shown, for example S / N 53070005, and the main voltage and the value of the fuses Block Model nameplate Power Supply...
- Page 12 Bottom of the instrument The air inlet opening should not be blocked any way. Fun 1 Power connection box with main switch 4.4 Description of command elements Front Controller pid...
- Page 13 Overview of the control elements of the regulator front P key • Access to the defined nominal temperature • Access to menu items and parameters • Confirmation of introduction 6 key • Reduction of the adjustable values • Selection of each menu item •...
-
Page 14: Commissioning, Operation
5.0 Transport, packaging and storage 5.1 Transport Check if the micro calibration bath shows any damage caused during transport. Report evident damages immediately 5.2 Packaging Do not remove the packaging until just before installation. Keep the packaging as it is the ideal protection during transport (e.g., if the installation site changes or if the product is shipped for possible repairs). - Page 15 After about 5 seconds activation has been completed and the calibration mode is automatically displayed. Mounted heating and cooling towers regulate micro-bath’s temperature automatically modifying the room temperature to match the adjusted nominal temperature on the regulator 6.4 Viewing the reference temperature and the nominal temperature Upper indicator The 4 digt –...
- Page 16 Measure from the bottom of the basket for the sensor • Tank must not be full • Leyro instruments standard filling mean • Factory fill with the optimal height The transportation cover is equipped with a safety valve. If the micro calibration bath is closed in a hot state, inadmissible pressures may be produced.
- Page 17 front wheel controller with stirring speed The magnetic stirrer is a wear part...
- Page 18 7.0 Micro calibration bath handling For handling three modes are available Calibration mode: In this normal operating state calibration of the tester can be performed Nominal values mode: Enter the nominal temperatures in this mode Main menu: Perform all settings like the nominal temperature given and the adjustment of the control parameters in this mode 7.1 Operation in the calibration mode on each operating mode "Micro-calibration bath"...
-
Page 21: Calibration (Calibration Mode)
Calibration of thermometers surface is very complex and not without ambiguities. The probe positioned on the surface of the heat dissipating surface producing a cold spot on the surface to be measured. In the micro-bath temperature calibration multifunctional calibration in a special cap surface it is generated to measure the temperature directly below the surface with a standard thermometer. - Page 22 The LED OUT 2 indicates the current reference. The nominal temperature appears in the lower display. Calibration mode indicator FAN or COOL Heating instrument The LED OUT 2 indicates the status of the output for fan control If the LED lights OUT 2 the fan rotates faster If it does not illuminate the LED OUT 2 the fan rotates at a slower speed Heating and cooling instrument The LED OUT 2 indicates the status of the output for regulating the cooling system...
-
Page 23: Maintenance, Cleaning And Recalibration
8.0 Cooling micro-calibration bath WARNING RISK OF BURNS Before transporting or touching the micro-calibration bath it is necessary to ensure that it is sufficiently cooled because otherwise there is a risk of burns on both the micro-bathand the proof. To bring the micro-calibration bath from a high temperature to a low temperature as quickly as possible, the nominal temperature must be set to a lower temperature than ambient temperature. -
Page 24: External Cleaning
9.2.1 Cleaning micro-calibration bath Remove all the silicone oil from the trunk. Remove the trunk sensor basket and clean it, the magnetic stirrer applying water with lots of cleaning substances. Let all components dry. If distilled water is used remove the calibration liquid and allow the sensor basket dry, the magnetic stirrer and the trunk. - Page 25 10.0 Failures Causes Measurements Failure The reference sensor stops or is defective ---- Measured temperature below the limit value of the internal reference sensor (below the range-200 º C / -328 ºF ) Measured temperature above the limit value of the 0000 internal reference sensor (above the range + 850 º...
- Page 26 11.2 Return WARNING It is essential to observe the following for shipping the instrument: All instrument sent to LEYRO INSTRUMENTS must be free of hazardous substances (acids, alkalis, solutions, etc.). Use the original packaging or a suitable packaging for returning the product..
- Page 27 12.0 ACCESSORIES FOR LCB 30 AND 50 • Syringe for insertion or removal of fluid • Transport metal LID • Power cable 1.5 mm / 0.06 in with F type connector according to CEE7 / 4 standards • Basket •...
- Page 28 NOTES _____________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________...
- Page 29 HEAD OFFICE: LEYRO INSTRUMENTS SL Avda. Somosierra 24 28703 San Sebastián de los Reyes Madrid, Spain Tel: +34 912 835 502 info@leyro.net www.leyroinstruments.com...
