Page 1: Table Of Contents
Compliance standards Technical support and troubleshooting 1. WELCOME Thank you for choosing this quality Ektor product. This manual is intended to help you install this product in a way that ensures the safety of yourself and others. Whilst this Ektor product is designed...
Page 2: Overview
TWINSPOT IP65 EMERGENCY INSTALLATION INSTRUCTIONS 2. OVERVIEW Ektor Generation III platform introduces you to a new era of emergency lighting control. With years in the making, the third generation platform builds on the Ektor product ranges’ increasing quality, reliability and performance.
Page 3: Installation
TWINSPOT IP65 EMERGENCY INSTALLATION INSTRUCTIONS 4. INSTALLATION The Ektor Twinspot is designed to be wall mounted. To install the Twinspot please follow the steps listed below: Remove the product from the box and inspect it for any damage. If you believe the product to be damaged or otherwise unsound, DO NOT install the product.
Page 4: Mounting
TWINSPOT IP65 EMERGENCY INSTALLATION INSTRUCTIONS 5. MOUNTING SURFACE MOUNT Remove the Twinspot cover as shown in the installation instructions in section 4 (page 3) of this instruction manual. This will allow for mounting holes to become visible. Drill a hole in the Twinspot body in either of the recommended positions (A, B). Insert and tighten cable gland to the Twinspot body, then wire as shown in section 7 (page 8).
Page 5 TWINSPOT IP65 EMERGENCY INSTALLATION INSTRUCTIONS The figures below illustrate the headlights tilt movement and the coverage of the beam. Headlight tilt max. 40° Centre of rotation Figure 4: Twinspot headlight upward range of movement Centre of rotation 40° Headlight tilt max. Figure 5: Twinspot headlight downward range of movement 45°...
Page 6: Terminal Block Wiring
TWINSPOT IP65 EMERGENCY INSTALLATION INSTRUCTIONS 7. TERMINAL BLOCK WIRING Wiring schematic for the terminal block used with the Twinspot is illustrated below. Figure 4: Wiring schematic 8. MAINTAINING YOUR TWINSPOT WARNING The Twinspot is connected to an unswitched active during normal operating conditions. When disconnected from the mains supply, the Twinspot is powered by a LiFePO4 battery operated inverter.
Page 7: Battery Life
AS/NZS 2293 or an equivalent standard can have a positive effect on the battery performance as long as 12 discharge cycles per year is not exceeded. 11. POWER AND BATTERY CHARGE The Ektor Generation III platform uses smart battery charging technology which reduces power consumption and increases battery life. Max charge voltage...
Page 8: Wireless Daughterboard
TWINSPOT IP65 EMERGENCY INSTALLATION INSTRUCTIONS 12. WIRELESS DAUGHTERBOARD The Twinspot inverter also supports an optional wireless daughterboard. The driver must be disconnected from mains and battery must be removed, before installing or changing any expansion module. More information and a list of other accessories can be found in the Wireless design and installation guide. The assembly for this part onto the inverter is shown below: Wireless daughterboard (6118)(optional) Twinspot inverter (1231, 1248, 1249, 1250)
Page 9: Dali Wiring/ Central Battery System
TWINSPOT IP65 EMERGENCY INSTALLATION INSTRUCTIONS 14. DALI WIRING/ CENTRAL BATTERY SYSTEM The Twinspot inverter supports DALI out of the box, illustrated in the hardwiring diagram shown below. The inverter also supports central battery systems and can be monitored through DALI. When used as a central battery system the devices can be tested with DALI.
Page 10: Accessories List
19. DISCHARGE RATING SELECTION The inverter supports a number of discharge ratings which can be selected by the user. The output from the LED scale based on the discharge rating (see Twinspot Weatherproof Datasheet on ektor.com.au) HOURS Remove expansion cover...
Page 11: Self Test Indicator Leds
TWINSPOT IP65 EMERGENCY INSTALLATION INSTRUCTIONS 20. SELF TEST INDICATOR LEDS The table below shows the operation of the Twinspot status indicators: INDICATOR DESCRIPTION YELLOW Device is performing a duration test 2sec ON / 2sec OFF YELLOW Last duration test passed. The duration was met when last run. 4sec ON / 1sec OFF Test ran less than five days ago YELLOW...
Page 12: Product Specifications
TWINSPOT IP65 EMERGENCY INSTALLATION INSTRUCTIONS 22. PRODUCT SPECIFICATIONS TWINSPOT 132mm 321mm 189mm 279mm 129mm Voltage (V) 220~240V Viewing distance Frequency (Hz) 50Hz Mounting type Surface mounted Max. ambient temp. 40°C Wiring Hard wired Battery type LiFePO4 Battery voltage 6.4V Class Charging time 16 hours Duration...
Page 13: Construction Sites
If you choose to expose the Ektor emergency products to such harsh operating conditions, Evolt may not honour any warranty on the life of the batteries or the dish. This Ektor emergency product is designed to undergo regular discharge tests but it is recommended that the intervals between consecutive tests are not less than two weeks.
Page 14: Warranty Information
Australian Competition and Consumer Act and other Australian laws. Ektor products are warranted in Australia for a period of 12 months from the date of delivery of the product, provided that the products are properly stored, installed, used and maintained in accordance with the instructions contained within their manual.
Page 15: Compliance Standards
TWINSPOT IP65 EMERGENCY INSTALLATION INSTRUCTIONS 27. COMPLIANCE STANDARDS STANDARD TITLE Australian/ New Zealand AS/NZS 2293-3:2005+A1:2010 Emergency escape lighting and exit signs for buildings. Part 3: Emergency escape luminaires and exit signs. Standards AS/NZS 60598-2-22:2005 Luminaires Part 2.22: Particular requirements - Luminaires for emergency lighting (IEC 60598-2-22, Ed.
Page 16 Ph: + 612 9502 1161 Fax: + 612 9502 1154 Email: sales@evolt.com.au evolt.com.au Reference: 605708_V2.5...
