Summary of Contents for Dyconn DPM-45

  • Page 1 PDF provided by Conference Room AV Dyconn Spider Universal Ceiling Mount, Holds up to 44lbs...

  • Page 3: Specification

    Although we try our best, Dyconn makes no claim that the information comprised herein covers all conditions or details in connection with installation or use of this product. Dyconn assumes no responsibility for accuracy or adequacy of information comprised in this document.
  • Page 4 Product Dimensions Tools required for installation Page...

  • Page 5: Supplied Parts

    Supplied Parts ASSEMBLY and INSTALLATION INSPECT THE MOUNT COMPONENTS BEFORE ASSEMBLY 1. Carefully inspect/verify that all components are present. 2. If the mount/components are damaged or missing, please contact the company/seller of the product you purchased and report the issue. NOTE: Read all assembly instructions before starting the installation process.

  • Page 6: Installing The Ceiling Plate

    Step【1】 Installing the Ceiling Plate Drilling into electrical wires can cause death or serious personal injury! Always make certain area behind mounting area is free of electrical wires before drilling or installing. Improper installation can lead to projector mount falling causing severe personal injury or damage to equipment.
  • Page 7 Figure 1-2 5. Then, proceed to place the Ceiling Plate Cover onto the Mounted Ceiling Plate and press firmly on the cover to make sure it is in place. (See Figure 1-3) Figure 1-3 Page...

  • Page 8: Masonry Installation

    Step【1】 Installing the Ceiling Plate Drilling into electrical wires can cause death or serious personal injury! Always make certain area behind mounting area is free of electrical wires before drilling or installing. Improper installation can lead to projector mount falling causing severe personal injury or damage to equipment.
  • Page 9 Masonry Pilot Pilot Hole Size Pilot Drill Depth 3/8" 3 " 10mm 75mm Figure 1-5 4. Then, proceed to place the Ceiling Plate Cover onto the Mounted Ceiling Plate and press firmly on the cover to make sure it is in place. (See Figure 1-6) Figure 1-6 Page...
  • Page 10 Step 【2】 Attaching the Ceiling Mount Assembly to Ceiling Plate 1. Remove the Projector Plate from the Ceiling Mount Assembly (1) as shown (See Figure 2-1) Figure 2-1 2. Connect the Ceiling Mount Assembly Head to the Ceiling Plate. Secure the Ceiling Mount Assembly Head by turning the Ceiling Mount Assembly head in clockwise until tight.
  • Page 11 Step 【3】 Finding Centre Gravity of the Projector 1. Pick up the projector using both of your index fingers. Move your fingers along the side of the projector until you find it is level. Repeat for perpendicular side on this process, where both balance point’s meet is the center gravity of your projector.
  • Page 12 Step 【4】 Attaching Projector Plate to the Projector 1. Determine the diameter of the Leg Posts (4, 5, 6, or 7) your projector requires by hand threading them to the Projector. (See Figure 4-1) 2. Before you assembly the Projector Legs (10), ensure that the Leg Post must be firmly attached into Projector.
  • Page 13 4. Place the Projector Plate over the Projector Legs (10) and align the mounting holes as shown. Tighten Hex Screw M5x8mm using Allen Wrench 4mm supplied.(See Figure 4-4) Figure 4-4 5. Once this is done, thread the Leg Post Cover (3) over Leg Post Assembly. (See Figure 4-5) Figure 4-5 6.
  • Page 14 7. Adjust and align the locking plate connector as shown. (See Figure 4-7) 8. Make sure locking plate connector holes are match up and aligned. Proceed to tighten the Ceiling Mount Assembly with Hex Screw M5x8mm using Allen Wrench 4mm (12) supplied. (See Figure 4-8) Figure 4-7 Figure 4-8...
  • Page 15 Step 【5】 Adjusting the position of the Projector 1. This product is designed to adjust quickly and easily according to your needs. 2. Side ways pitch and the pitch angle up to 20 degrees. (See Figure 5-1) Figure 5-1 2. To make rotate adjustment, ensure that the weight of the projector is supported. The product can reach 360 degrees rotation.
  • Page 16 Dyconn disclaims any liability for modification, improper installations, or installations over specified weight range. Dyconn will not be liable for any damages arising out of the use or inability to use Dyconn products. Warranty specification is subject to change without prior notice.
