Sinoamigo SPT-1 Series User Manual

Please read this manual carefully before installation!
Features and Applications
1. 1.Desktop sockets are widely used in modern
b u i l d i n g s , o ff i c e b u i l d i n g s , ex h i b t i o n h a l l s ,
airports, banks, postal and telecom munications,
laboratory buildings, schools, hotels, hospitals,
computer rooms, home decora-tion, and other
places for access to power or weak electricity(such
as:Telephones,compyters,microphones,etc.)used
to transmit signals;
2.When the product is not in use, the socket body
can be com-pletely hided under desktop and keep
clean;
3.The product's sealed structure can ensure that
water droplets, beverages and other liquids do not
penetrate easily.
Use and Maintenance
1. When using a desktop socket, press down the
cover with the palm of your hand, and when the
cover pops up, pull the socket body upwards until
the locking tab fixed.
2. When not in use, pushing the locking tab in
(the direction of the arrow), to allow the socket
body to fall slowly till close to table top. then
press the cover with the palm of your hand to
lock the socket body fully.
3 , Avo i d t h e a c i d i c a n d a l ka l i n e s o l ve nt
washing.avoid scratching or bruising the surface
of the transparent protective paint covered,to
ensure the product's own corrosion resistance.
SPT-1 Series Vertical Pop Up Socket
User Manual
121mm
Switch
Table top
Fixed plastic ring
Fixed block
1. Make sure ground system is reliable when using.
Cover
2.Do not overload, otheriwse it may cause fire.
Socket
3.Avoid using wet hands to plug sockets.
4. Please insert the power plug into the sockets
fully when using, to avoid the risk of electric
Locking tab
leakge and electric shock.
Installation Method
1
Open the hole with a drill on the table top.
2
Remove the fixed plastic ring by rotating it counter-
clockwise direction.
Put the product into the hole and adjust the direction of
3
the function sockets.
4
From the bottom of the table, insert the plug through the
Plug
fixed plastic ring, and tighten the plastic ring by clockwise
until the socket is fixed.
安 全 注 意 事 项
Safty Warning
(Installation details see the back)
