Super Boost Ultra WiFi Pro Super Booster Manual

LED Explanation

Power LED NO: The device is power on.
OFF: The Device is not receiving electrical power.
WLAN LED: Wireless signal
WPS LED: Flashing - WPS connection is established or WPS signal
LAN LED: ON: The LAN port is connect
OFF: The LAN port is disconnected
Flashing: Transferring data to/from a network device

Button Explanation

WPS Button: If your host router supports WPS function, you can press the WPS button and then press the
WPS button of the Wi-Fi Repeater to establish a secure connection between the host router and the WIFI
Repeater.
Reset Button: This button is used to restore The Repeater's factory default settings With the Repeater
powered on. Use a pin to press and hold the Reset button for about 8 seconds.
LAN Port: One 10/100 Mbps RJ45 Ethernet port is used to connect an Ethernet-enabled device to a Wi-Fi
network, such as Internet TV, DVR, Gaming console and so on Please note that this port cannot be
connected to a router.

QUICK INSTALLATION

1- POWER ON
Plug in next to your router; wait until the WLAN LED is blinking.
2-Connect
For window users
WIFI BOOSTER MANUAL
