Exeter 4' Garden Bench
Assembly Guide
LEFT ARM ASSEMBLY
A
RIGHT ARM ASSEMBLY
SUPPORT BAR
SEQUOIA
PROFESSIONAL
1) Attach (1) Support Bar to
Arm Assemblies using
(4) "A" Bolts as shown.
A
For information on Care and Cleaning or to register
your
SEQUOIA PROFESSIONAL
www.sequioaprofurniture.com
HARDWARE
A
1/4"-20 X 1-3/4"
B
1/4"-20 X 2"
C
1/4"-20 X 3"
VERY IMPORTANT!
DO NOT fully tighten the bolts until all
bolts are started. Once all bolts are inserted,
go back & tighten all the bolts.
Retain these instructions for future reference
INCLUDED TOOLS
5/32" HEX KEY
product, please visit
x4
x10
x6
CM-BENSQ42
05.15.19
PAGE 1 OF 2
