iBoard IB20RIC6 Installation Instruction

iRunning Board Installation Instruction
Part#: IB20RIC6
Application: For 2008-2018 Toyota Sequoia

Installation Procedure

Item Part Name
1
Step Board, Passenger
2
Step Board, Driver
3 Front Bracket (FB)
4 Front/Center Bracket (FCB)
5 Rear/Center Bracket (RCB)
6 Rear Bracket Driver Side
7 Rear Bracket Passenger Side (RRB)
RCB
Step
REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT. READ INSTRUCTIONS
1
CAREFULLY BEFORE STARTING INSTALLATION.
2 Attach mounting brackets as shown SEE FIGURE 1.
Insert square head bolts as shown (4 per slot,8 per board).SEEFIGURES 2.
3
Attach board to brackets as shown on FIGURE 3 . Make sure board and brackets are properly aligned and
4
tighten fasteners.
Repeat Installation for passenger side.
5
6 INSTALLATION IS COMPLETE.

FINISH PROTECTION

Westin products have a high quality finish that must be cared for like any other exposed finish on the vehicle. Protect
the finish with a non-abrasive automotive wax, (e.g. Pure Carnauba) on a regular basis. The use of any soap, polish
or wax that contains an abrasive is detrimental, as the compounds scratch the finish and open it to corrosion.
The instruction here is for your reference only. We strongly recommend the
professional installer for best result. We are not responsible for any damage
caused by the installation. Thank you for choosing our product!
QTY
1
1
2
2
2
(LRB) 1
1
FB
LRB
Description
Page 1 of 2
Item Part Name
8
M8X1.25-30mm Hex Bolt
9
M8 Flat Washers
10 M8 Lock Washers
11 M6 Square Head Bolt
12 M6 Nylon Lock Nuts
13 M6 Flat Washers
RRB
REV: 20180101
QTY
16
16
16
16
16
16
FCB
