- Page 1 Elpress Mini Instruction for use PVL130L PVL130P PVL350...
-
Page 2: Table Of Contents
In order to avoid human injury and environmental damage, do not disregard these instructions. After this symbol there is often a symbol which explains the warning. Operational warnings To avoid damaging the pump unit, do not disregard them ELPRESS MINI | INSTRUCTION FOR USE... -
Page 3: Introduction
Read these instructions for use carefully before starting to use the tool. This tool shall only be used for crimping of Elpress’ terminals for electrical conductors with Elpress’ matched tool accessories. Crimping with this tool must only be performed by operators trained in its use and who have good knowledge about crimping and the risks that are involved. -
Page 4: Brief Description Of The Important Features Of The Tool
- The crimping head can be smoothly turned by 300° around its longitudinal axis in order to gain better access to tight corners and other difficult working areas. - The tool has a very light weight and provides a good handling through an ergonomic design. ELPRESS MINI | INSTRUCTION FOR USE... -
Page 5: Crimp Dies
KRD50-xx/KSD50-xx MB12 KRD70-xx/KSD70-xx MB14 KRD95-xx/KSD95-xx MB17 KR10-xx/KS10-xx KRT16-xx/KST16-xx MB8.5 KRT25-xx/KST25-xx MB10 KRT35-xx/KST35-xx MB12 KRT50-xx/KST50-xx MB14 KRT70-xx/KST70-xx MB16 6-16 CUT-connectors MB4016 4-10 KR/KS terminals MB4016 Transformer tapchanger Size Ø 5 mm Size Ø 7 mm ELPRESS MINI | INSTRUCTION FOR USE... -
Page 6: Working With The Tool
• Electric motors in use can create sparks that can ignite explosive fluids and materials. Do not use the MINI-tools in explosive environments. • Do not use the MINI-tools in rain and wet environments. ELPRESS MINI | INSTRUCTION FOR USE... -
Page 7: Service And Maintenance
PVL350 and PVL130L shall be lubricated regular. We recommend that the tool is send to an Elpress authorized service centre or Elpress service department for service one time per year or more often if the tool is used more than normal. -
Page 8: The Light Diode Display
5 Trouble shooting A. The tool leaks oil; return the tool to Elpress service. Do not open the tool - no action can be done without special equipment and competence. B. The tool does not reach the required working force; stop the crimping process. -
Page 9: Waste And Scrap
40 min 40 min 40 min. Number of crimps/charge (approx.) 120-150 Working temp., °C -10 + 40 -10 + 40 -10 + 40 The number of crimps/charge is very approximately; it depends on crimp- type, area, temperature etc. ELPRESS MINI | INSTRUCTION FOR USE... -
Page 10: Declaration Of Conformity
DECLARAÇÃO DE CONFIRMADADE DICHIARAZIONE DI CONFORMITÀ Tillverkare/Producent/Produsent/Valmistaja/Manufacturer/Hersteller/ Producent/Fabricant/Costruttore/Fabricante/Fabricante ELPRESS AB P.O. Box 186 SE-872 24 KRAMFORS Tel +46 612 71 71 00 Fax +46 612 71 71 51 Kramfors 2017-01-27 ..........Johannes Bålhammar Technical manager ELPRESS MINI | INSTRUCTION FOR USE... - Page 11 Dichiariamo sotto la nostra esclusiva responsabilità che questo prodotto è conforme alle seguenti norme e documenti normativi: EN 60745-1, EN 12100, EN ISO 13857, EN 349, EN 60204-1, EN 28662-1, EN 61000-6-3, EN 61000-6-2, EN 60529, EN 1037 conformemente alle disposizioni delle direkttive 2006/42/EG, 2014/30/EU, 2011/65/EU. ELPRESS MINI | INSTRUCTION FOR USE...
