OVERSPEED
Mode Indicator
BLANKING
Mode Indicator
VOLTAGE LEVEL
Mode Indicator
CLOCK
Mode Indicator

Changing Settings:

OVERSPEED 1

(Blinking Digits)
SETTING

OVERSPEED 2

(Flashing Strobes)
SETTING

BLANKING SPEED

SETTING

DEMO MODE

STEALTH MODE

SMART 650 Quick Reference Guide

UP and DOWN User Interface Buttons:

Used to move between modes and to increase/decrease values.

SELECT User Interface Button:

Used to select modes and to set values.

OVERSPEED Indicator:

Illuminated whenever a target speed is greater than or equal to either of the overspeed
settings. Blinks when in overspeed changing mode.

BLANKING Indicator:

Illuminated whenever a target speed is greater than or equal to the blanking speed setting.
Blinks when in blanking speed changing mode.

VOLTAGE LEVEL MENU Indicator:

Illuminated when the system voltage is being displayed. Blinks when in system menu or
changing options settings.

CLOCK Indicator:

Displays the current date and time of the sign. Blinks when changing date and time values.
Display Window:
Displays the current target speeds. It can also be used to view and change the system
settings. The rightmost decimal point is the Power LED which should constantly blink to
indicate the system is running. "nc" indicates the communication to the radar has been lost.
To change the Overspeed1 setting, using user interface buttons:
1. move to the OVERSPEED LED → SELECT →
2. move to "OS1" → SELECT → SELECT →
3. choose new value → SELECT
To change the Overspeed2 setting, using user interface buttons:
1. move to the OVERSPEED LED → SELECT →
2. move to "OS2" → SELECT → SELECT →
3. choose new value → SELECT
To change the Blanking Speed setting, using user interface buttons:
1. move to the BLANKING LED → SELECT →
2. choose new value → SELECT
To engage the demonstration mode, using user interface buttons:
1. move to the VOLTAGE LEVEL LED → SELECT →
2. move to "dE" → SELECT →
3. choose "On"/"OFF" → SELECT
To engage the stealth mode, using user interface buttons:
Part # 006-9009-10 Rev 0
