Hardline TH-1 Manual

Please read the following notice carefully before using,
install and operate the meter correctly.
1

Precautions

1.Please use the product accordance with the user guide strictly.
2.Please do not dismantle the product by yourself.
3. Due to the waterproof design of the product, it can be used in the rain, but can not be put into in deep water.
4.When the product is in the intense vibration or strong impact. It will cause a failure
5.The product must be used within the specified range of voltage.
6.The backlight function will need more battery level, battery life is limited ,when the battery level is low, please replace
the battery as soon as possible.The battery item is CR2032.
2

Installation

1.How to install the battery.
【Notice】:The original data will be retained after replace battery.
1
Open the battery cover
Please use a coin to rotate the battery
cover which has "open" word, and
will open the battery cover
2.How to install the product.
1
Put the rough surface of magic
tape on the back of the thermometer
4 Put the end of the sensor into the products which to be tested.
3.Check the correctness of the product installation.
Access to the sensor,if temperature data is displayed , which means the product was installed correctly.
3

product application

1.View the working data.
When the product is in the state with backlight,short press the MENU button,you can view "over temperature reminded value,
the maximum tested temperature value,temperature unit,sensor type and instant temperature value" in turn.
【Notice】: When the product is working without backlight, short or long press any button to make the product in the backlight.
2.Set the temperature reminder value.
1 In the temperature Reminder Value interface,long press the MENU button more than 2 seconds, then enter into the
temperature reminder value setting interface, the default value is "100 ℃".
2 In the temperature reminder value setting interface , long or short press SET button to add the setting value, long or short
press MENU button to reduce the setting value . The setting value range is from - 20 ℃ to + 300 ℃ (-4 ℉ - + 572 ℉).
2 Place the battery
Smooth side should be put upward.
2
Put the needle surface of magic
tape on the device
3 Close the battery cover
Please use a coin to rotate the battery cover which
has "CLOSE" word, and will close the battery
cover
3 Connect the product wire and temperature
sensor as below picture
1.
2.
