LADDERSTORE LADDERFIX MICROLITE Instruction Leaflet page 2

Dimensions and manufacturing specifications
All drawings not to scale
Side elevation of hook
I 85 mm
K 80 mm
M 350 mm
I
J
M J
E
K
L
Plan of top bar
A 585 mm
C 530 mm
J 180 mm
L 350 mm
B 375 mm
D 620 mm
Plan of bottom bar
E 640mm
G 578mm
A
D
C
E
H
G
F 325mm
H 630mm
2
B
F
