Thomas Nenner
March 31, 2017
Release 2.5.6
The people counter 2D_Shop is an overhead sensor which analyzes infrared Images. This Process makes
the device light variations independent that might affects other devices counting accuracy. The advantages
from this technology are:
o Bidirectional counting.
o –Accuracy over 95%.
o -No shadows Influence.
o -Good accuracy in low light conditions.
This sensor provides real time analytics locally and on the cloud
2D_Shop camera . English manual
2D_Shop
Camera for Video Analytics
USER MANUAL
1
Advertisement
Table of Contents
Summary of Contents for Shopline 2D Shop
- Page 1 2D_Shop Camera for Video Analytics Thomas Nenner March 31, 2017 Release 2.5.6 USER MANUAL The people counter 2D_Shop is an overhead sensor which analyzes infrared Images. This Process makes the device light variations independent that might affects other devices counting accuracy. The advantages from this technology are: o Bidirectional counting.
-
Page 2: Table Of Contents
Index Site and hardware considerations ........................3 Connections diagram ..............................3 Coverage : ................................. 3 Standard model..............................3 Installation ................................4 Orientation ................................5 Electrical ................................... 5 Cabling ..................................6 Pulse system compatibility ............................6 IP address switch ..............................7 Parameters-Settings ............................. -
Page 3: Site And Hardware Considerations
1. Site and hardware considerations Connections diagram The camera sends the data on Ethernet on a server: Power RJ45 2D-Shop Supply Injector RJ45 Server Internet Figure 1 Connection diagram Coverage : It depends on the ceiling height and on the optical parameters. Two models are available : Standard model for ceilings up to 3.2 meter, High sensitivity for ceilings up to 4.5 m... -
Page 4: Installation
High sensitivity Ceiling Coverage height 2.5 m 2.6 m 3.0 m 3.1 m 3.5 m 3.7 m 4.0 m 4.1 m 4.5 m 3.5 m Figure 3 coverage for the high sensitivity model Installation The camera is attached under the ceiling with the omega shaped bracket and a pair of expansion bolts. Figure 4 back of the camera Attach the bracket first with a pair of expansion bolts Then introduce the camera and fasten the 8 mm hex bolt with a 10 mm wrench. -
Page 5: Orientation
Orientation The 3 leds must be inside the shop, in order to have a simple default software installation Inside Figure 5 : orientation of the camera Electrical On the back of the camera are two connectors : RJ45 connector : it is a POE link, the network cable carries the power and the Ethernet data. Green pulse connector : useful when the camera is for infra red beam replacement. -
Page 6: Cabling
Figure 7 : POEswitch passive When booting up, a multicolor led blinks on the camera, and after boot up it will extinguish. Cabling This a reminder only. Cat 5 or Cat6 Ethernet cable is necessary, with proper A or B cabling as shown in the next figure. Telephone cable will not work properly even on short distances. -
Page 7: Ip Address Switch
Entrances Exits A 15 Volts, 2A power supply is necessary. (a 12 V 1A power supply will NOT work) When detecting the camera will produce a 15 V pulse which can be fed in a dat logger as usual. IP address switch Flashing led at boot up IP adres reset switch... -
Page 8: Parameters-Settings
We must set our laptop to 199.188.177.xx to be able to communicate. Unknown address The Cbox finder program is available to find all devices in the network. It is available on our website : upgrade.shopline.fr http://upgrade.shopline.fr/Utilitaires/cbox_finder.exe Figure 10 : list of devices in the network It will show you the list of connected devices to the local network. - Page 9 Remember that hierarchy in people counting in shops is : Chain of stores Mychain Shop Paris Door Entrance Figure 11: Device identification 2D_Shop camera . English manual...
-
Page 10: Network Settings
Network settings Figure 12 : Network settings Device is delivered at address 192.168.1.7 DNS is set into the router which will work most of the time, if needed introduce another DNS address. This is quite important as the camera must find the time server on the internet to update internal clock; Automatic work or DHCP will set automatically parameters, they can be seen by “show current settings”... -
Page 11: Time Settings
Time settings Figure 13: Time settings Check that this is running fine, because we need the date and time for file generation. We may run on internal clock, but as it may drift one should update time from time to time. Remember that it needs the DNS Channels Figure 14 : Channel definition... -
Page 12: Data Delivery
IP address of the server It can be on the local server as seen on the figure, 192.168.1.37 or on a distant server like frequence.shopline.fr Login Name of the FTP account... -
Page 13: Source
File generated Files are generated according to proprietary SCB format, aggregation will be 1 file per day as “date.scb” They are plain text files which can be opened with any editor, like notepad. Source This sreen shows the image seen by the camera, as well as the region of interest and 2 counting lines. Underneath one can see the counting results , the arrow shows the direction of entrance, remember that the 3 leds must be inside the shop. -
Page 14: Validation
Figure 6 Extended menu for gain settings Validation This will send to a FTP server the recording of the image and the counts. One must realize that the volume can be high and overload the server. Heat map 2D_Shop camera . English manual... - Page 15 The heat map can be seen on the navigator screen and sent to a server for recording and further treatments. Note the zoom on the left image. 2D_Shop camera . English manual...
-
Page 16: Status, And Sytem
Status, and sytem These pages shows detailed information’s for debug and trouble shooting. In order to save the entire device configuration you must save changes pressing apply new settings 2D_Shop camera . English manual... -
Page 17: Local Server Configuration
Filezila server using default analytic directories, and main video alnalytic programs. http://upgrade.shopline.fr/Distribution%20FR/singlecam_setup.exe For simplicity click only on the real time part of the analytic, RPOS program If necessary use one of the popular POS software editor... - Page 18 Some technical informations…. Installation of the FTP server Check the account and correct : Login shopline Password shopline Main directory shopline with all the rights 2D_Shop camera . English manual...
-
Page 19: Technical
Sometime you must give clearance to FTP program itself Now you can test the ftp data delivery on the camera Directories On the camera we remember : PC address is for example 192.168.1.37 Account name is shopline Password shopline Directory comptage File name date.scb Result is C:\shopline\comptage\date.scb... -
Page 20: Real Time Analytics
4. Real time analytics After installation, an icon appears called RPOS Goto parameters type the password shop Set RPOS to files in default folder You are ready to enjoy real time analytics 2D_Shop camera . English manual... -
Page 21: Documentation
Documentation RPOS Real time analytics CPOS Statistical analytic Transport service Data transmission to headquarter Succursales Headquarter analytics 2D_Shop camera . English manual...
