8315 Series TankGate Interface
Data Communication Gateway for L&J Tankway (MCG 1000,
MCG 1500, MCG 2000) Devices
Installation &
Operations Manual
www.varec.com
Varec, Inc.
5834 Peachtree Corners East, Norcross (Atlanta), GA 30092 USA
Tel: +1 (770) 447-9202 Fax: +1 (770) 662-8939
IOM035GVAE0405
