Summary of Contents for ecoTree SLB-120

  • Page 1: Table Of Contents

    SLB - 120 HOCl Generation System Contents Product Overview Contents Safety Cautions Mechanism of HOCl Generation Component Identification Installation How to Use Troubleshooting Specification Limited Warranty...
  • Page 2: Product Overview

    SLB - 120 Product Overview Main Body SLB-120 1 ea Flow Regulator 1 set Product Prefilter 1 ea Overview Booster Pump 1 ea Power Cable 1 ea Connecting Tube Chlorine Test Paper 1 ea Make sure to check there is no damage caused by external shock to the box before opening the package.
  • Page 3: Safety Cautions

    SLB - 120 Safety Cautions Thank you for choosing ecoTree™ HOCl Generation System. Safety Please read this user's manual before installation to ensure proper use and maintenance. If there are any problems while using this device, please refer to user’s manual for troubleshooting.
  • Page 4 SLB - 120 Safety Cautions Precautions for Installation Install the HOCl storage tank in a well ventilated place. Avoid direct sunlight. (If you want to install the device outdoors, please contact your local seller.) Do not install in humid place. (Avoid places where condensation may occur, especially during winter.) Water supply condition: Temperature: 10~40℃(50℉~104℉), Flow Rate : 1.3~2.0 L/min, Water Pressure : 3 - 5 bar Check the pH of the water before installation.
  • Page 5 SLB - 120 Safety Cautions Cautions for Use Warning If the main unit is submerged, it may Do not twist or press the power cord cause an electric shock. Unplug the and make sure it is not broken. Caution power plug from the electric outlet, pull up the main unit and ask your local seller Be sure to unplug the power plug when to repair it.
  • Page 6 SLB - 120 Safety Cautions Cautions during Operation If the device is not in use for a long time, remove the HCl solution bottle from the device and keep it separately. For HCl replacement, refer to the user’s manual. (p.17) For other components replacement, contact your local seller.
  • Page 7 SLB - 120 Safety Cautions HOCl Cautions HOCl must be kept in a storage tank made of PE, PVC or FRP. When HOCl is exposed to organic materials, it may reduce the sterilizing ability. Note that the sterilizing ability of HOCl will decrease rapidly when HOCl is exposed to light. When using stored HOCl, check the pH and chlorine concentration before use.
  • Page 8 SLB - 120 Safety Cautions Precautions for handling 3% HCl Solution Use only the 3% HCl solution supplied with the device. When handling, wear protective goggles, gloves and clothes if necessary. Also wash your hands thoroughly after handling. If the 3% HCl is spilled on metal, rinse with sufficient amount of water. Do not subdivide or transport into other containers.
  • Page 9 SLB - 120 Safety Cautions Attention The following situations require first aid. ▶ Immediately wash skin with plenty of water. Skin contact ▶ Remove contaminated clothing or shoes and wash skin with plenty of water. Contact on clothing or shoes Do not try to neutralize the acid with alkaline solution.
  • Page 10: Mechanism Of Hocl Generation

    Mechanism of HOCl Generation ecoTree SLB-120 ecoTree SLB-120 uses un-divided electrolytic cell system. It generates Hypochlorous acid (HOCl) through electrolysis of 3% HCl and dilution with water. Electrolysis SLB-120 In general, electrolysis refers to the oxidation-reduction reaction of HOCl Generating System an electrolyte using electric current.
  • Page 11 SLB - 120 Mechanism of HOCl Generation HOCl Generation Process Chlorine Concentration : 20 ~ 40 ppm HOCl Solution pH : 5.0 ~ 6.5...
  • Page 12: Component Identification

    SLB - 120 Component Identification ③ ② ④ ⑤ Front ⑥ ① ① Main body ② Power button ⑧ ⑨ ③ Display Rear ④ Mechanical compartment ⑦ ⑤ Control panel ⑥ Raw material container ⑩ ⑦ Power connection Component ⑪ ⑧...
  • Page 13 SLB - 120 Component Identification Front control panel User interface Button Description System information System status Press 1~2 seconds to enter system menu. Menu Description Press to return to the previous menu . Date Displays the date information. Press to move to the next menu or the lower line. Flow rate Displays the current water flow rate.
  • Page 14: Installation

    SLB - 120 Installation Installation HOCl Generation System SLB-120 Installation and Operation...
  • Page 15 SLB - 120 Installation Installation of 3% HCl solution tank Installation site & Connection Use supplied 3% HCl for ecoTree™ only. The specifications of the tank shall be changed depending on the local conditions and purpose of use. Side Wall >80cm...
  • Page 16: How To Use

    SLB - 120 How to use How to use Menu Button Menu Screen Button Description Press 1~2 seconds to enter system menu. Press to return to the previous menu. Date & Time Set the date and time. Language Select English or Korean. Press to move to the next menu or the lower line.
  • Page 17 SLB - 120 How to use ① Power Switch [Rear] After Installation Connect the power plug into ② Power Socket and turn on ① Power Switch to operate. ② Power Socket The ③ Power Button lights on in red. When press ③ Power Button for 1-2 seconds, [Front] it turns to blue.
  • Page 18 SLB - 120 How to use When the system is powered on, the HOCl Generation System automatically checks internal components. Starting System ① message is shown on the display and then, ② Process Checking Complete message is displayed. [Graphic User Interface] If there is no error, ③...
  • Page 19 SLB - 120 How to use Start/stop HOCl generation Status : Stop Status : Operating ① ③ ① When the system initializing is completed, press the HOCl button for 1 – 2 seconds to change red LED to blue LED, then HOCl generation starts. ②...
  • Page 20: Troubleshooting

    SLB - 120 Troubleshooting Processing HOCl / Status : 3% HCl Change [HCl level Sensor error message] [Cause] 1 The level of 3% HCl solution is too low. [Action] 1 Troubleshooting Refill with the new 3% HCl solution tank. [Cause] 2 The 3% HCl solution tank is not adherent to the 3% HCl solution level sensor.
  • Page 21 SLB - 120 Troubleshooting [Hall Sensor error message] Processing HOCl / Status : Hall Sensor Error H a l l S e n s o r E r r o r [Cause] 1 The 3% HCl solution pump motor does not work. [Action] 1 Please contact your local seller.
  • Page 22: Specification

    SLB - 120 Specification Specification Precautions 1. Depending on water supply condition, production volume and chlorine concentration may vary. 2. Specifications may be changed without prior notification to improve the performance of the product. 3. The life cycle of the electrolyzer may vary depending on water quality, environment condition, and frequency of use.
  • Page 23: Limited Warranty

    Limited Warranty. This Limited Warranty only applies when the product is used, stored, handled, fabricated and/or installed in the manner recommended by SeouLin Bioscience in the SLB-120 User’s Manual. Non-covered defects 1.
  • Page 24 HOCl Generation System...
