Features of your Elemental H
• Microcomputer control system
• Digital temperature control
• Temperature memory system
• Anti-corrosive evaporator
• Energy-efficient operation
• LED display
• 1-year warranty
EHC200
Input Voltage: 120V
Amperage: 2.2A
Wattage: 170W
BTU: 1,130 BTU
Water Capacity: 13-40 gallons
Recommended Pump Size: 130-280 gph
Flow Rate: 66.5-410 gph
Refrigerant: R134a
Compatible Tubing:
" or
1
/
2
Thank you for choosing to grow with Elemental Solutions! Your satisfaction
and success are important to us. For best results, carefully read the
following instructions before using your Elemental H
O Chiller
2
EHC210
Input Voltage: 120V
Amperage: 3A
Wattage: 310W
BTU: 2,940 BTU
Water Capacity: 26-80 gallons
Recommended Pump Size: 250-600 gph
Flow Rate: 264-660 gph
Refrigerant: R134a
" ID
Compatible Tubing:
3
/
4
EHC220
Input Voltage: 120V
Amperage: 4.4A
Wattage: 420W
BTU: 4,100 BTU
Water Capacity: 50-135 gallons
Recommended Pump Size: 300-800 gph
Flow Rate: 317-793 gph
Refrigerant: R134a
" or 1" ID
Compatible Tubing:
3
/
4
O Chiller.
2
" or 1" ID
3
/
4
rev:22013
Advertisement
Summary of Contents for Elemental Solutions EHC200
- Page 1 Thank you for choosing to grow with Elemental Solutions! Your satisfaction and success are important to us. For best results, carefully read the following instructions before using your Elemental H O Chiller. Features of your Elemental H O Chiller • Microcomputer control system •...
- Page 2 2. Remove the rubber caps from the water inlet and outlet on the top of the unit. Attach the inlet and outlet fittings to the water inlet and outlet. Tighten the screw caps to secure the fittings. For EHC200, use the smaller fittings with ½” ID tubing and the larger fittings with ¾”...
- Page 3 Displaying Current Temperature and Temperature Setting Press the “Set” button to alternately display the current temperature and Operation Panel the programmed temperature. The temperature indicator light blinks when the programmed temperature is displayed. Decrease Temperature Increase Temperature Selecting Temperature Setting Setting Temperature Hold the “Set”...
- Page 4 Elemental Solutions 1-Year Limited Warranty All Elemental H O Chillers are protected against manufacturer defect by a limited 1-year manufacturer’s warranty. Limited 1-Year Warranty Terms Sunleaves Garden Products warrants this product to the original purchaser to be free of defective materials and work- manship under normal use and service for 1 year from the original date of purchase.
