WHAT'S IN THE BOX
• LED WORK LIGHT FIXTURE
w/ 10 FOOT LONG CORD
WHAT YOU'LL NEED
• AVAILABLE ELECTRICAL RECEPTACLE ON
JOBSITE
WARNING
• Turn off the power when you perform any
maintenance.
• Verify that the receptacle voltage is correct before
plugging in the fixture.
• Keep lens Bghtly closed when in operaBon.
• ModificaBons to the product voids the warranty.
Failure to heed these warnings may result in personal
injury or property damage.
WKL1-SERIES
WORK LIGHT
INSTALLATION INSTRUCTIONS
For use with:
Model #
Input Voltage
WKL1-304-1
WKL1-504-1
IMPORTANT
Before assembling your PREMISE LED
fixture, please make sure that you
carefully read through this
instrucBon sheet.
Note: The important safeguards and
instrucBons that appear in this sheet
are not meant to cover all possible
condiBons and situaBons that may
occur. It must be understood that
common sense, cauBon, and care are
factors that cannot be built into any
product. These factors must be
supplied by the person(s) caring for
and operaBng the fixture.
Wa2age
100-240V
30W
100-240V
50W
PREMISE LED Inc.
80-86 Carrier Drive
Toronto, ON Canada
M9W 5R1
PREMISELED.COM
1
