Summary of Contents for Sun2Solar 805401
- Page 1 ™ INSTALLATION AND OPERATION MANUAL Model Sku #s: 805401, 805430, 805431, 805404, 805405, 805406, 805407 Read all instructions before assembling or using the Sun2Solar™ Heater Systems. Retain this Manual for future use. 03/16 Distributed By: Millstream Dist. LLC 1-800-253-4775...
-
Page 2: Table Of Contents
Manual may damage the product and will void the warranty. CAUTION: You are advised to consult with a professional when installing the Sun2Solar™ Heater on a roof, fence or rack system. When installing the collectors near the pool, especially on an elevated rack system, ensure that the structure does not provide access to the pool. -
Page 3: How Sun2Solar™ Heater Works
274119 Backwash Fitting- 274062 INSTALLATION READ THE ENTIRE MANUAL PRIOR TO THE INSTALLATION AND USE OF THE SUN2SOLAR™ SYSTEM TOOLS REQUIRED GUIDELINES FOR POSITIONING Flathead screwdriver or 5/6” (8mm) nut driver * The collector(s) needs at least 6 hours of full sunlight daily. -
Page 4: Installation Of Sun2Solar™ Heater/Layout Options
2 x 20 INSTALLATION This layout is for a single collector near the pool filter. Installing the collector on a rood, rack or fence may require additional plumbing and hardware kits. Rubber End Cap 1. Ensure there is adequate work space to unroll the 20’ collector. 2. - Page 5 4 x 20 INSTALLATION OR MULTI-SYSTEM INSTALLATION This layout is for a system of more collectors installed near the pool filter equipment. Installing the collector on a roof, rack or fence may require additional plumbing and hardware kits. Rubber End Cap 1.
- Page 6 ROOF/RACK/FENCE INSTALLATION NOTE: The mounting hardware is sold separately. See page 7 for available kits options. If installing on a roof, use silicone sealant to prevent water leakage into structure. Apply adequate IMPORTANT: amounts of sealant to both of the pre-drilled hole and over the screw head once installed. 3.
-
Page 7: Winterization
You can leave the collectors in place (as long as they are completely drained) and they will withstand even the harshest winters. Sun2Solar recommends that you store your collectors inside in a warm dry place. -
Page 8: Troubleshooting
TROUBLESHOOTING PROBLEMS POSSIBILITIES / SOLUTIONS Sun2Solar™ *Make sure that water is flowing through Sun2Solar™ Heater by checking the flow Heater does not at the pool return. *Note the weather- has it been cloudy or raining? appear to be heating the pool.
