- Page 1 IST1054V1.0 WWW.SANYSAFE.IT SANY SAFE L SANY SAFE XL - 21 -...
-
Page 2: Table Of Contents
XGSM and XGSM 4G ............................32 Technical characteristics........................32 SIM card inclusion / Antenna connector ....................32 Commissioning SANY SAFE L e SANY SAFE XL ................. 33 Tank SANY SAFE L e SANY SAFE XL ....................33 Estimated tank life ..........................33 Firmware update .............................. -
Page 3: Generality
HOT COMPONENTS, observed could cause damage to the device DANGER OF BURNS or the connected equipment. Dimensions SANY SAFE XL SANY SAFE L 166 mm 264 mm 166 mm 353 mm - 23 -... -
Page 4: Technical Features
Not used Output Available for manual signaling Connections Universal GSM 2 G models SANY SAFE L 2G SANY SAFE XL 2G GSM 4 G models SANY SAFE L 4G SANY SAFE XL 4G GPRS always connected to the CLOUD Programming configuration parameters with APP – Sany Safe GSM included User management with APP –... -
Page 5: Installation
IST1054V1.0 Installation SANY SAFE can be installed on the wall. Its mounting is simplified thanks to a support bracket to which the central block of the sanitizer will be attached. For a lower aesthetic impact, SANY SAFE can also be installed inside built-in wardrobes, just be careful to ensure sufficient ventilation for the disposal of heat and to leave a small opening at the nozzle to allow the leaking of the sanitizing jet. -
Page 6: Mounting Sany Safe L
IST1054V1.0 Mounting SANY SAFE L VISTO ISO_PAG. 5 Verify that package has been positioned in the correct direction Once the equipment is un- before opening the package. packed remove the two M6x10 screws and remove front cover FORARE QUI FORARE QUI ... -
Page 7: Outdoor Connections Sany Safe L
IST1054V1.0 Outdoor connections SANY SAFE L Insert an easily accessible 16 A C-curve multi-pole mains switch and having a minimum distance between the contacts of at least 3 mm in the electrical installation of the building. For electric network power supply input, use double insulation cables. -
Page 8: Installation Sany Safe Xl
IST1054V1.0 Installation SANY SAFE XL Once the SANY SAFE has been removed from the packaging, remove the 4 M4x6 type fixing screws and remove the cover. Verify that package has been positioned in the correct direction before opening the package. Use the supplied drilling template for positioning the plate. -
Page 9: Outdoor Connections Sany Safe Xl
IST1054V1.0 Outdoor connections SANY SAFE XL Insert an easily accessible 16 A C-curve multi-pole mains switch and having a minimum distance between the con- tacts of at least 3 mm in the electrical installation of the building. For electric network power supply input, use double insulation cables. Input for network power supply connection Network connection SANY SAFE XL... -
Page 10: Board
IST1054V1.0 Board RESET BUZZER 1 2 3 4 5 6 7 8 - A + P - P + S - S + D - D + F - F DA DB 12 V PRIM DISABLE FIRE RS485 FAULT FLUID SMOKE TAMPER Terminal board... -
Page 11: Fuses
IST1054V1.0 Fuses F1 - T 500mA 250V Protection of the transformer primary F3 - F 6,3A 250V Fuse protecting 220 V network input Buttons RESET Press and release to reset the microprocessor Dip Switch DIP SWITCH DESCRIPTION DEFAULT Activates the delivery warning buzzer - notice time 1 ‘ Disable the delivery warning buzzer - notice time 1 ‘... -
Page 12: Xgsm And Xgsm 4G
IST1054V1.0 XGSM and XGSM 4G With the XGSM card it is possible, through connection in GPRS / 3G / LTE / 4G, to send commands and receive information on the status of the SANY SAFE, with the dedicated SANY SAFE application. The application allows configuration of the parameters and user management of the sanitizer. -
Page 13: Commissioning Sany Safe L E Sany Safe Xl
IST1054V1.0 Commissioning SANY SAFE L e SANY SAFE XL • Unscrew the cap of the installed tank and the one in replace- ment. • Screw the cap making sure that the suction tube reaches the bottom of the container, if necessary move the tube until the filter rests on the bottom of the tank •... -
Page 14: Firmware Update
Factory values: • SANY SAFE L is programmed to carry out a light sanitation in a 60m3 environment, every day at 1 am • SANY SAFE XL is programmed to perform a light sanitation in a 300m3 environment, every day at 1 am... -
Page 15: Warnings For The Installer
• before any maintenance on the appliance, disconnect the mains power supply • AVS Electronics is not responsible for damage caused by incorrect installation or by improper use of the equipment. General warnings • Avoiding staying for long periods in environments saturated with sanitizing steam, it could cause irritation to the mucous membranes of the respiratory tract and to the eyes. -
Page 16: Sany Safe L And Sany Safe Xl
Within a few minutes, the activation will be displayed Automatic sanitization • SANY SAFE L is programmed to carry out a light sanitization in an environment of 60m3, every day at 1 am - the estimated sanitization time is 1 minute •... -
Page 17: Description
SANY SAFE Description SANY SAFE APP allows you to connect an Apple / Android device to a SANY SAFE L or SANY SAFE XL sanitizer using a GSM 2G or 4G card connected directly to the AVS cloud. With SANY SAFE you can: Fully manage an AVS system: ●... - Page 18 IST1054V1.0 Download SANY SAFE app and manage your Sanitizer Create a new system ADD A SYSTEM Once the application is opened, you are asked to enter with the sanitizer identification (PID) and to assign a name. The PID can be scanned directly with the mobile camera or typed. Feed SANY SAFE for at least 5 minutes, before carrying out any operation with the APPLICATION ENABLE A TANK...
- Page 19 IST1054V1.0 HOME SCREEN The main data are summarized in this screen. Name assigned to SANY SAFE SANY SAFE model (L or XL) Number of sanitizations available Next sanitization: the date and time of the next sanitization will be indicated Number of sanitizations carried out: the number indicates how many times the sanitizations have been activated % of fluid remaining: The fluid level is expressed in % Status: indicates whether SANY SAFE is online, and therefore can...
- Page 20 • Within a few minutes, the activation will be displayed Via Valsugana, 63 35010 (Padova) ITALY Tel. 049 9698 411 marketing@avselectronics.it www.sanysafe.it support@avselectronics.it AVS ELECTRONICS Spa reserves the right to make changes at any time without notice. - 40 -...
