- Page 1 MODEL: GCT300MP MULTI PURPOSE DUMP TRAILER OWNERS MANUAL...
-
Page 2: Parts List
I. Parts List No. Picture Description Qty Steel Tray Big Plastic Bed Frame 1pc No. Picture Description... - Page 3 Frame Brace 2pcs Wheel 4pcs Handle Axle...
-
Page 4: Hardware List
Hardware List No. Picture Descriptio Lock 4sets Nuts&Flat Washer (Used to connect steel tray and bed frame) Flat Washer 4sets &Split Pin(Used while assemble wheels) Notice: All hardware have been pre-assembled in cart. Ⅱ. Assembly STEP Ⅰ Bed Frame & Steel Tray Assembly 1. - Page 5 3. Put pre-assembled bed frame on steel tray （1） , and then unlock dump handle by pulling force in upward direction. Making marked part of bed frame locked on the HOOK of dump handle. 4. Attach pre-assembeld bed frame to the steel tray (1) using lock bolt & flat washer(8).
- Page 6 STEP Ⅱ Wheel Assembly Place the wheels (5) onto axle and bed frame(valve stems facing out), then place Flat washer, and using Split pins(9) to lock. STEP Ⅲ Handle Assembly Turn over the assembled cart, put handle(6) on the yoke. Using the convertible Handle: 1.
- Page 7 Handle to be trailer hitch: Then the simple yard cart have been assembled: STEP Put big plastic tub(2) on steel tray(1), using cotter pin to lock.
- Page 8 Multi-purpose dump trailer...
