Tricon Version 9–10 Systems
Field Terminations Guide
for Tricon v9–v10 Systems
Assembly No. 9700052-018
February 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tricon v9 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Triconex Tricon v9

  • Page 1 Tricon Version 9–10 Systems Field Terminations Guide for Tricon v9–v10 Systems Assembly No. 9700052-018 February 2009...
  • Page 2 Invensys Systems, Inc. © 2006–2009 by Invensys Systems, Inc. All rights reserved. Triconex, Tricon, Trident, TriStation 1131, TriStation MSW, and CEMPLE are trademarks of Invensys plc, its subsidiaries and affiliates. All other brands may be trademarks of their respective owners.

  • Page 3: Table Of Contents

    Thermocouple Input Modules ..........21 Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 4 9661-910 (120 VDC, commoned, 16 pts.) ........102 Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 5 9750-810 (0–5 VDC/0–10 VDC voltage input, basic, 32 pts.) ....209 9753-110 (0–5 VDC/0–10 VDC voltage input, basic, 16 pts.) ....211 Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 6 9794-110 (pulse input, 8 pts.) ..........323 Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 7 Overview ..............388 Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 8 Hot Surface ..............407 Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 9: Preface

    Preface This guide includes information on external termination products for Tricon v9 systems and Tricon v10 systems. Summary of Sections • Chapter 1, Introduction to Field Terminations—introduces the Triconex external field termination products for the Tricon system. • Chapter 2, Field Termination Options and Installation—provides information for...

  • Page 10: Related Documents

    Safety Considerations Guide for Tricon v9–v10 Systems • TriStation 1131 Developer’s Guide, v4.3 Product and Training Information To obtain information about Triconex products and in-house and on-site training, see the Triconex Web site or contact your regional Triconex support office. Web Site http://www.ips.invensys.com/en/triconex...

  • Page 11: We Welcome Your Comments

    E-mail support@ips.invensys.com We Welcome Your Comments To help us improve future versions of Triconex documentation, we want to know about any corrections, clarifications, or further information you would find useful. When you contact us, please include the following information: • The title and version of the guide you are referring to •...
  • Page 12 Preface Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 13: Chapter 1 Introduction To Field Terminations

    Introduction to Field Terminations Overview External Termination Panels Cables Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 14: Overview

    All cables and termination panels are built to withstand harsh industrial environments. The environmental specifications for components used on these products are the same as for a Tricon chassis. For more information, see the Planning and Installation Guide for Tricon v9–v10 Systems.

  • Page 15: External Termination Panels

    • Termination panels with interposing relays • Bypass panels for digital inputs • Termination panels with RTD/TC/AI input signal conditioning • Termination panels for 3603B digital output modules • Termination panels for 3806E analog output modules Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 16: Basic Termination Panels

    1, Division 2 field circuits. These panels contain extra circuitry designed to limit power available to the field terminals and have been examined and certified by TÜV Rheinland as being nonincendive. This guarantees that if the field wires are accidentally opened, shorted, or Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 17: Termination Panels With Interposing Relays

    ON and the corresponding point switch is ON. Each point has a location for a user-definable label. Each bypass termination panel comes with one or two 10-foot (3-meter) cables for connecting the termination panel to a Tricon backplane. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 18: Termination Panel With Rtd/Tc/Ai Input Signal Conditioning

    16-point non-commoned digital output module 3603B. Termination Panel 9863-710 for Analog Output Module 3806E The special analog output termination panel 9863-710, with buffered loopback signals, is available for use with the high-current analog output module 3806E. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 19: Cables

    • 50 stranded, stripped, tinned and labeled 22-gauge leads at opposite end Fanned-out cables should only be used with digital input and digital output modules. They are not certified for use with analog signals. Contact the Triconex Customer Support Center if you need a fanned-out cable for handling analog signals.
  • Page 20 8 Chapter 1 Introduction to Field Terminations Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 21: Field Termination Options And Installation

    Field Termination Options and Installation Overview Determining Field Termination Options by Module Part Number Determining Field Termination Options by Module Type Installation and Removal Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 22: Overview

    Overview This chapter provides information for determining field termination options using module part numbers or module types, and it describes how to install and remove termination panels and fanned-out cables. Determining Field Termination Options by Module Part Number This table identifies which termination products you can use with a given I/O module. Match your module part number in the left column to termination options on the right.
  • Page 23 Table 1 Termination Product Options (Listed by Module Part Number) (continued) Module Commoned Non-Common. Basic Nonincendive RG 1.180 Fanned-out Bypass ERT Loop-Back Module Description Part # Term Panels Term Panels Term Panels Term Panels Term Panels Cables Panels Cables/Panels 3603E DO, 120 VDC, 16 pts.
  • Page 24 Table 1 Termination Product Options (Listed by Module Part Number) (continued) Module Basic Term Nonincendive RG 1.180 Fanned-out Bypass ERT Loop-Back Module Description Upscale Downscale Part # Panels Term Panels Term Panels Cables Panels Cables/Panels 3706A Thermocouple input, type J, 9766-210 9766-510 9784-610,...
  • Page 25 Module 3-Wire 2-Wire Nonincendive RG 1.180 Module Description Voltage Basic RTD/TC/AI Part # 4-20 mA 4-20 mA Term Panels Term Panels 3721 AI; 0 to 5 VDC or –5 to +5 9763-810 9761-210, 9791-610, 9790-610, 4–20 mA, 0–5 V 9753-110, 0–5 V VDC;...

  • Page 26: Determining Field Termination Options By Module Type

    You need two termination panels (or cables) for each 32-point or 64-point DI module. Also, you can mix any combination of two termination products listed in a particular module’s column. For example, for a 115 VAC/VDC module you may use two 9561-810 Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 27: Pulse Input Modules

    20 Hz–20 kHz (3510) 20 Hz–20 kHz (3511) Basic termination panel 9753-110 9753-110 Nonincendive termination panel 9793-110 RG 1.180 Term Panel 9794-110 Note You need one termination panel for each 8-point PI module. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 28: Pulse Totalizer Input Modules

    Basic termination panel 9753-110 Nonincendive termination panel 9572-610 Fanned-out cable Contact Triconex for availability of pulse totalizer fanned-out cables. Note You need two termination panels for each 32-point pulse totalizer input module. Digital Output Modules This table identifies termination products you can use with 16-point non-supervised digital output modules.

  • Page 29: Supervised Digital Output Modules

    You need two termination panels (or cables) for each 32-point digital output module. Also, you can mix any combination of two termination products listed. For example, you may use two 9662-610 panels, or one 9653-610 basic panel and one 9101-010 fanned-out cable, and so on. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 30: Dual Digital Output Modules

    You need two termination panels (or cables) for each 32-point relay output module. Also, you can mix any combination of two termination products listed. For example, you may use two 9668-110 panels, two 9651-110 basic panels, or one 9668-110 panel and one 9651-110 basic panel. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 31: Analog Input Modules

    9792-610 (4-20 mA, 0-5 V, 48 VDC field) 9795-610 (4–20 mA, 0–10 V) 9783-110 (voltage input) Fanned-out cable Contact Triconex for availability of analog fanned- out cables. Note You need one termination panel for each 16-point AI module. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 32 RTD/TC/AI panel 9764-310 Fanned-out cable Contact Triconex for availability of analog fanned-out cables. Note You need two termination panels (or cables) for each 32-point AI module. Also, you can mix any combination of two termination products listed in a particular module’s column.

  • Page 33: Thermocouple Input Modules

    Nonincendive termination panel, upscale 9784-610 Nonincendive termination panel, downscale 9785-610 Note You need two termination panels for each 32-point thermocouple input module. Also, you can use a 9766-210 panel with a 9766-510 panel. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 34: Analog Output Modules

    RG 1.180 Term Panel 9860-610 Fanned-out cable Contact Triconex for availability of analog fanned-out cables. Note You need one termination panel for each 8-point AO module. This table identifies termination products you can use with 4-point bipolar analog output modules.

  • Page 35: Hart Interface Modules

    Termination Products for HART Interface Modules HART AI Interface HART AO Interface Termination Option (2770H) (2870H) Standard termination panel, current input 9761-210 Basic termination panel 9853-610 Nonincendive termination panel 9791-610 9861-610 RG 1.180 termination panel 9790-610 9860-610 Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 36: Installation And Removal

    These termination panels cannot be installed on a DIN rail. They must be installed on a standard 19 inch (47.5 cm) rack (Electronics Industries Association Standard #RS-310-C): • 9251-210 • 9670-110 • 9670-610 • 9671-810 • 9672-810 • 9673-810 Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 37 DIN rail, as shown in this picture. For Nuclear Class 1E applications, additional installation guidelines may be applicable and must be considered. Please contact the IPS Global Client Support (GCS) center for details. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 38 • As you apply pressure to the top of the connector on the cable, use your other hand to turn the thumbscrew clockwise until the connectors are mated completely. The minimum torque requirement is 8.85 lb in (10.0 d-Nm). Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 39 WARNING connectors used in ATEX installations, and replace it before the end of its five-year life span. Triconex recommends that you use the gasket in all hazardous locations requiring nonincendive circuits. (Order Triconex part number 3000793-001 for a kit of 25 gaskets.)
  • Page 40 9795-610 9565-710 9661-910 9750-410 9766-510 9853-610 9566-710 9662-110 9750-810 9771-210 9860-610 9566-810 9662-910 9750-210 9782-110 9861-610 9567-810 9662-610 9750-310 9783-110 9863-710 9570-610 9662-710 9753-110 9784-610 9571-610 9662-810 9760-410 9785-610 9572-610 9663-610 9760-210 9786-110 Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 41 Tighten the screws on the field wiring and power terminals of the ETPs in the list below to this torque: 12.0 lb in (1.0 lb ft) (1.36 Nm) 9670-110 9670-610 9671-610 9671-810 9672-810 9673-810 Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 42: Removing Or Replacing A Termination Panel

    Dangerous voltage may be present on the ELCO connector. 6 Dismount the termination panel from the DIN or rack rail. 7 To replace a termination panel, follow the procedure in Installing a Termination Panel on page Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 43: Installing A Fanned-Out Cable

    Dangerous voltages may be present on the ELCO connector if power has not been removed from the termination panel. 4 To replace a fanned-out cable, follow the procedure in Installing a Fanned-Out Cable on page Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 44 32 Chapter 2 Field Termination Options and Installation Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 45: Chapter 3 Digital Input Termination Panels

    16-Point Commoned Digital Input Term Panels 32-Point Commoned Digital Input Term Panels 16-Point Non-Commoned Digital Input Term Panels Basic Digital Input Term Panels Pulse Input and Pulse Totalizer Input Term Panels Bypass Term Panels Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 46: Overview

    This chapter describes external field termination panels you can use with digital input modules. Digital input termination panels are available in these configurations: • 16-point commoned • 32-point commoned • Non-commoned • Basic • Bypass Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 47: 16-Point Commoned Digital Input Term Panels

    Typical 16-Point Commoned DI Term Panel with Fuse Protection This figure represents a typical 16-point commoned digital input termination panel with resistors. Figure 2 Typical 16-Point Commoned DI Term Panel with Resistor Protection Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 48: 9561-810 (115 V, Commoned, 16 Pts.)

    This table describes digital input modules compatible with 9561–810. Table 21 Modules Compatible with 9561–810 Module Part Points per Module Description Fuse Number Module 3501E 115 VAC/VDC, non-commoned, isolated, TMR 1A, slow 3501T 115 VAC/VDC, non-commoned, isolated, TMR 1A, slow Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 49 This figure illustrates how to connect a 32-point digital input module and a 9561-810 with an AC power supply to the field. Figure 4 Field Wiring for 9561-810 with a 3501E or 3501T Module and an AC Power Supply Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 50: 9562-810 (48 V, Commoned, 16 Pts.)

    Appendix F, Panel Labels. Specifications This table describes specifications for 9562–810. Table 22 Specifications for Term Panel 9562–810 Feature Description Panel type Commoned Points Leakage current per point Maximum: 3.5 mA Typical: 2.0 mA Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 51 1A, slow self-test Field Wiring Diagrams This figure illustrates how to connect a 32-point digital input module and a 9562–810 to the field. Figure 6 Field Wiring for 9562-810 with a 3502E Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 52 Mux B Test B (AC Neutral) Threshold Detect Input Opto-Isolator Mux C spare module Test C LEDs are blown-fuse indicators Figure 7 Simplified Schematic of a 3502E DI Module with a 9562-810 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 53: 9563-810 (24 V, Commoned, 16 Pts.)

    Module Description Fuse Number Module 3503E 24 VAC/VDC, commoned in groups of 8, TMR with 1A, slow self-test 3505E 24 VDC, low-threshold, commoned in groups of 8 1A, slow with self test, TMR Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 54 42 Chapter 3 Digital Input Termination Panels Field Wiring Diagrams This figure illustrates how to connect a 32-point digital input module and a 9563–810 to the field. Figure 8 Field Wiring for 9563-810 with a 3503E or 3505E Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 55: 9563-910 (24 V, Commoned, Resistor Protected, 16 Pts.)

    The modules compatible with 9563-910 have 32 points, which means you must use two term panels for each digital input module. Each term panel comes with two sets of labels: 1-16 and 17-32. For information on how to apply the labels, see Appendix F, Panel Labels. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 56 24 VDC, low-threshold, commoned in groups of 8, TMR with self-test Field Wiring Diagrams This figure illustrates how to connect a 32-point digital input module and a 9563-910 to the field. Figure 10 Field Wiring for 9563-910 with a 3503E or 3505E Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 57 Input points Opto-Isolator Mux B 2.7K Test B Threshold Detect Input Opto-Isolator Mux C spare module Test C 9563-910 Panel Figure 11 Simplified Schematic of a 3503E or 3505E DI Module with a Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 58: 32-Point Commoned Digital Input Term Panels

    Typical 32-Point Commoned DI Term Panel with Fuse Protection This figure represents a typical 32-point commoned digital input term panel that has resistors for field device protection. Figure 13 Typical 32-Point Commoned DI Term Panel with Resistor Protection Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 59: 9565-810 (48 Vdc, Commoned, 32 Pts.)

    Compatible Modules This table describes digital input modules compatible with 9565–810. Table 29 Modules Compatible with 9565–810 Module Part Points per Module Description Fuse Number Module 3504E 24/48 VDC, commoned, high-density, DC-coupled, 1A, slow Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 60 48 Chapter 3 Digital Input Termination Panels Field Wiring Diagrams This figure illustrates how to connect a 64-point digital input module and a 9565–810 to the field. Figure 14 Field Wiring for 9565-810 with a 3504E Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 61: 9566-710 (24 Vdc, Commoned, 32 Pts.)

    Each term panel comes with two sets of labels: 1-32 and 33-64. For information on how to apply the labels, see Appendix F, Panel Labels. Specifications This table describes specifications for 9566–710. Table 30 Specifications for Term Panel 9566–710 Feature Description Panel type Commoned Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 62 24 VDC, commoned, single Field Wiring Diagrams This figure illustrates how to connect a 64-point digital input module and a 9566–710 to the field. Figure 16 Field Wiring for 9566-710 with a 3564 Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 63: 9566-810 (24 Vdc, Commoned, 32 Pts.)

    Each term panel comes with two sets of labels: 1-32 and 33-64. For information on how to apply the labels, see Appendix F, Panel Labels. Specifications This table describes specifications for 9566–810. Table 32 Specifications for Term Panel 9566–810 Feature Description Panel type Commoned Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 64 24/48 VDC, commoned, high-density, DC-coupled, TMR Field Wiring Diagrams This figure illustrates how to connect a 64-point digital input module and a 9566–810 to the field. Figure 18 Field Wiring for 9566-810 with a 3504E Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 65 64-POINT HIGH-DENSITY DIGITAL INPUT MODULE spare 180 Ohms Hi-Ref Low-Ref other points 2.7K Hi-Ref Low-Ref Hi-Ref Low-Ref 9566–810 Panel Figure 19 Simplified Schematic of a 3504E DI Module in a 24 V Application with a Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 66: 16-Point Non-Commoned Digital Input Term Panels

    Appendix F, Panel Labels. Specifications This table describes specifications for 9561–110. Table 34 Specifications for Term Panel 9561–110 Feature Description Panel type Non-commoned Points Leakage current per point Maximum: 3.3 mA Typical: 2.5 mA Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 67 1A, slow Field Wiring Diagrams This figure illustrates how to connect a 32-point digital input module and a 9561–110 to the field. Figure 21 Field Wiring for 9561-110 with a 3501E or 3501T Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 68 Threshold Detect Input Opto-Isolator Mux B Threshold Detect Input spare Opto-Isolator Mux C module LEDs are blown-fuse indicators Figure 22 Simplified Schematic of a 3501E or 3501T DI Module with a 9561–110 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 69: Basic Digital Input Term Panels

    The modules compatible with 9551–110 have 32 points, which means you must use two term panels for each digital input module. Specifications This table describes specifications for 9551–110. Table 36 Specifications for Term Panel 9551–110 Feature Description Panel type Basic Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 70 115 VAC/VDC, non-commoned, isolated, TMR Field Wiring Diagrams This figure illustrates how to connect a 32-point digital input module and a 9551–110 to the field. Figure 24 Field Wiring for 9551-110 with a 3501E or 3501T Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 71: 9552-610 (48 V, Basic, 16 Pts.)

    The modules compatible with 9552–610 have 32 points, which means you must use two term panels for each digital input module. Specifications This table describes specifications for 9552–610. Table 38 Specifications for Term Panel 9552–610 Feature Description Panel type Basic Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 72 48 VAC/VDC, commoned in groups of 8 with self test, TMR Field Wiring Diagrams This figure illustrates how to connect a 32-point digital input module and a 9552–610 to the field. Figure 26 Field Wiring for 9552-610 with a 3502E Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 73: 9553-610 (24 V, Basic, 16/32 Pts.)

    You must use two term panels for each digital input module. Specifications This table describes specifications for 9553–610. Table 40 Specifications for Term Panel 9553–610 Feature Description Panel type Basic Points 16 when used with 32-point modules 32 when used with 64-point modules Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 74 24 VDC, commoned, single Field Wiring Diagrams This figure illustrates how to connect a 32-point digital input module and a 9553–610 to the field. Figure 28 Field Wiring for 9553-610 with a 3503E or 3505E Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 75 One RTN connection is required. More than one is okay. One PWR connection is required. More than one is okay. Figure 29 Field Wiring for 9553-610 with a 3564 Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 76 PWR + to other points & sensors IN + Threshold Detect Opto-Isolator Test OFF Relays (opto-isolated) other other points points Figure 31 Simplified Schematic of a 3564 DI Module with a 9553–610 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 77: 9750-310 (24 Vdc, Basic, 32 Pts.)

    This table describes digital input modules compatible with 9750–310. Table 43 Modules Compatible with 9750–310 Module Part Points per Module Description Number Module 3504E 24/48 VDC, commoned, high-density, DC-coupled, TMR, configured as 24 VDC when used with 9750-310 Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 78 This figure illustrates how to connect a 64-point digital input module and a 9750–310 to the field. One RTN connection is required. More than one is okay. Optional ballast resistor. Figure 32 Field Wiring for 9750-310 with a 3504E DI Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 79: 9750-410 (48 Vdc, Basic, 32 Pts.)

    The modules compatible with 9750–410 have 64 points, which means you must use two term panels for each digital input module. Specifications This table describes specifications for 9750–410. Table 44 Specifications for Term Panel 9750–410 Feature Description Panel type Basic Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 80 This figure illustrates how to connect a 64-point digital input module and a 9750–410 to the field. One RTN connection is required. More than one is okay. Optional ballast resistor. Figure 34 Field Wiring for 9750-410 with a 3504E DI Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 81 IN + Hi-Ref Low-Ref other points Hi-Ref Low-Ref Hi-Ref Low-Ref For maximum noise immunity, install a 1W, 10k ohms ballast resistor. Figure 35 Simplified Schematic of a 3504E DI Module with a 9750–410 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 82: Pulse Input And Pulse Totalizer Input Term Panels

    This table describes specifications for 9753–110. Table 46 Specifications for Term Panel 9753–110 Feature Description Panel type Basic Points 8 when used with pulse input modules 16 when used with pulse totalizer input modules Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 83 When possible, install a terminating resistor as shown. For further information, see Technical Application Note (TAN) #006. Figure 37 Field Wiring for 9753-110 with a 3510 or 3511 PI Module Unused points must be shorted together. CAUTION Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 84 Do not use mechanical relay/switch contacts. To prevent point-to-point cross-talk, use individually shielded, twisted-pair wire for lengths greater than 50 feet (15 meters). Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 85 Comparator AC coupled Counter/ Micro- Timer Processor other points Comparator AC coupled Counter/ Micro- Timer Processor other points Figure 39 Simplified Schematic of a 3510 or 3511 PI Module with a 9753–110 Panel Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 86 Detect Leg A Opto-Isolator Threshold Counters Detect Leg B Opto-Isolator Threshold Counters Detect Leg C Opto-Isolator spare module Figure 40 Simplified Schematic of a 3515 Pule Totalizer Input Module with a 9753–110 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 87: Bypass Term Panels

    9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 TRICONEX REAR +24 RTN GND +24 RTN GND Figure 41 Typical 32-Point Bypass Term Panel for 32-Point DI Modules Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 88: Bp9228-010 (24 V, Bypass, 32 Pts., For 32 Pt. Modules)

    #6 ring-lug terminals, or 24-gauge to 12-gauge (0.2 mm2 to 3.3 mm2) wires. Specifications This table describes specifications for BP9228-010. Table 48 Specifications for Term Panel BP9228-010 Feature Description Panel type Bypass Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 89 24 VDC, low-threshold, commoned in groups of 8 with self-test Field Wiring Diagrams This figure illustrates how to connect a 32-point digital input module and a BP9228-010. BP9228-010 Figure 43 Field Wiring for with a 3503E or 3505E DI Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 90: Bp9229-010 (24 V, Bypass, 32 Pts., For 64 Pt. Modules)

    The modules compatible with BP9229-010 have 64 points, which means you must use two term panels for each digital input module. Specifications This table describes specifications for BP9229-010. Table 50 Specifications for Term Panel BP9229-010 Feature Description Panel type Bypass Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 91 Module 24 VDC, commoned 3504E Field Wiring Diagrams This figure illustrates how to connect a 64-point digital input module and a BP9229-010. BP9229-010 Figure 45 Field Wiring for with a 3504E DI Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 92 64-POINT HIGH-DENSITY DIGITAL INPUT MODULE +24V Keyswitch Hi-Ref Low-Ref other Bypass points switch Hi-Ref Low-Ref AC safety spare ground Hi-Ref module Low-Ref Figure 46 Simplified Schematic of a 3504E DI Module with a BP9229-010 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 93: Chapter 4 Digital Output Termination Panels

    8-Point Commoned Digital Output Term Panels 16-Point Commoned Digital Output Term Panels 16-Point Non-Commoned Digital Output Term Panels 121 Basic Digital Output Term Panels 135 Commoned Interposing Relay Term Panels 150 Non-Commoned Interposing Relay Term Panels 164 Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 94: Overview

    This chapter describes external field termination panels you can use with digital output modules. Digital output termination panels are available in these configurations: • 8-point commoned • 16-point commoned • Non-commoned • Basic • Commoned interposing relay • Non-commoned interposing relay Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 95: 8-Point Commoned Digital Output Term Panels

    Typical 8-Point Commoned AC DO Term Panel This figure represents a typical 8-point commoned DC digital output termination panel with fuses and blown-fuse indicators. Figure 48 Typical 8-Point Commoned DC DO Term Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 96: 9661-510 (115 Vac, Commoned, 8 Pts.)

    This table describes digital output modules compatible with 9661–510. Table 54 Modules Compatible with 9661–510 Module Part Points per Primary Secondary Module Description Number Module Fuse Fuse 3611E 115 VAC, commoned, supervised, 2.5A, fast None galvanically-isolated, TMR Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 97 A load must be installed at every point to prevent missing-load alarm. If a field load is not available, install a 2.2k ohm, 10W load resistor. Figure 49 Field Wiring for 9661-510 with a 3611E Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 98: 9661-810 (120 Vdc, Commoned, 8 Pts.)

    (PWR+ and PWR–). Each output point is protected by a fuse with a blown-fuse indicator. Specifications This table describes specifications for 9661–810. Table 55 Specifications for Term Panel 9661–810 Feature Description Panel type Commoned Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 99 To prevent missing-load alarm, install a load at each unused point. If a field load is not available, install a 2.2 k ohm, 10 W load resistor. Figure 51 Field Wiring for 9661-810 with a 3613E Module and No Shorted Load Detection Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 100 To prevent missing-load alarm, install a load at each unused point. If a field load is not available, install a 2.2 k ohm, 10 W load resistor. Figure 52 Field Wiring for 9661-810 with a 3613E Module and Shorted Load Detection Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 101: 9662-710 (24 Vdc Low-Power, Commoned, 8 Pts.)

    8 load terminals and commoned power terminals (PWR+ and PWR–). Each output point is protected by a fuse with a blown-fuse indicator. Specifications This table describes specifications for 9662–710. Table 57 Specifications for Term Panel 9662–710 Feature Description Panel type Commoned Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 102 To prevent missing-load alarm, install a load at each unused point. If a field load is not available, install a 470 ohm, 10 W load resistor. Figure 54 Field Wiring for 9662-710 with a 3615E Module and No Shorted Load Detection Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 103 To prevent missing-load alarm, install a load at each unused point. If a field load is not available, install a 470 ohm, 10 W load resistor. Figure 55 Field Wiring for 9662-710 with a 3615E Module and Shorted Load Detection Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 104: 9662-910 (24 Vdc, Commoned, 8 Pts.)

    (PWR+ and PWR–). Each output point is protected by a fuse with a blown-fuse indicator. Specifications This table describes specifications for 9662–910. Table 59 Specifications for Term Panel 9662–910 Feature Description Panel type Commoned Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 105 To prevent missing-load alarm, install a load at each unused point. If a field load is not available, install a 470 ohm, 10 W load resistor. Figure 57 Field Wiring for 9662-910 with a 3614E Module and No Shorted Load Detection Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 106 To prevent missing-load alarm, install a load at each unused point. If a field load is not available, install a 470 ohm, 10 W load resistor. Figure 58 Field Wiring for 9662-910 with a 3614E Module and Shorted Load Detection Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 107: 9667-910 (48 Vdc, Commoned, 8 Pts.)

    (PWR+ and PWR–). Each output point is protected by a fuse with a blown-fuse indicator. Specifications This table describes specifications for 9667–910. Table 61 Specifications for Term Panel 9667–910 Feature Description Panel type Commoned Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 108 To prevent missing-load alarm, install a load at each unused point. If a field load is not available, install a 470 ohm, 10 W load resistor. Figure 60 Field Wiring for 9667-910 with a 3617E Module and No Shorted Load Detection Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 109 To prevent missing-load alarm, install a load at each unused point. If a field load is not available, install a 470 ohm, 10 W load resistor. Figure 61 Field Wiring for 9667-910 with a 3617E Module and Shorted Load Detection Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 110 SPWR + to other Output points Switch SPWR – Drive Circuitry Voltage Voltage Loopback Sensor spare LEDs are blown-fuse indicators Figure 62 Simplified Schematic of a 3617E DO Module with a Commoned DO Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 111: 16-Point Commoned Digital Output Term Panels

    Figure 63 Typical 16-Point Commoned DC DO Term Panel with Fuses This figure represents a typical 16-point commoned digital output panel without fuses. Figure 64 Typical 16-Point Commoned DO Term Panel without Fuses Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 112: 9661-610 (115 Vac, Commoned, 16 Pts.)

    Termination panel 9661–610 is compatible with 115 VAC digital output modules and has 16 load terminals and commoned power terminals (PWR+ and PWR–). Each output point is protected by a fuse with a blown-fuse indicator. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 113 3A, fast Field Wiring Diagrams This figure illustrates how to connect the 16-point AC digital output module 3601E and a 9661–610 to the field. Figure 67 Field Wiring for 9661-610 with a 3601E Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 114: 9661-910 (120 Vdc, Commoned, 16 Pts.)

    Specifications This table describes specifications for 9661–910. Table 65 Specifications for Term Panel 9661–910 Feature Description Panel type Commoned Points Maximum total current 16 amps Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 115 This figure illustrates how to connect a 16-point DC digital output module and a 9661–910 to the field (1 of 16 points shown). Figure 69 Field Wiring for 9661-910 with a 3603E Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 116 A load must be installed at every point to prevent a missing-load alarm. If a field load is not available, install a 2.2k ohm, 10W load resistor. Figure 70 Field Wiring for 9661-910 with a 3623 Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 117 Output to other Switch points Drive Circuitry Output Switch Drive spare Voltage Circuitry Loopback Detector LEDs are blown-fuse indicators Figure 72 Simplified Schematic of a 3623 DO Module with a Commoned DO Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 118: 9662-610 (24 Vdc, Commoned, 16 Pts.)

    Module Description Number Module 3624 24 VDC, commoned, supervised, opto-isolated, self-protected, TMR 3625 24 VDC, commoned, supervised/non-supervised, opto-isolated, self-protected, TMR 3664 24 VDC, commoned, opto-isolated, self-protected, dual 3674 24 VDC, commoned, opto-isolated, self-protected, dual Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 119 When using a Model 3624 or 3625 module, a load must be installed at every point to prevent missing-load alarm. If a field load is not available, install a 470 ohm, 10 W load resistor. Figure 73 Field Wiring for 9662-610 with a 3624 or 3625 Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 120 This figure illustrates how to connect a 32-point DC dual digital output module with self protection and a 9662-610 to the field (1 of 32 points shown). Figure 74 Field Wiring for 9662-610 with a 3664 or 3674 Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 121 Current Output Loopback Switch Detector Analog/ Drive Digital Circuitry Voltage spare Loopback Detector * All output switches are opto-isolated. Figure 76 Simplified Schematic of a 3625 DO Module with a Commoned DO Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 122: 9662-810 (24 Vdc, Commoned, 16 Pts.)

    This table describes digital output modules compatible with 9662–810. Table 70 Modules Compatible with 9662–810 Module Part Points per Primary Module Description Number Module Fuse 3604E 24 VDC, non-commoned, opto-isolated, TMR 2.5A, fast Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 123 This figure illustrates how to connect the 16-point DC digital output module 3604E and a 9662-810 to the field (1 of 16 points shown). Figure 78 Field Wiring for 9662-810 with a 3604E Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 124: 9663-610 (115 Vac, Commoned, 16 Pts.)

    Specifications This table describes specifications for 9663–610. Table 71 Specifications for Term Panel 9663–610 Feature Description Panel type Commoned Points Maximum total current 30 amps Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 125 This figure illustrates how to connect the 16-point AC digital output module 3601E or 3601T and a 9663–610 to the field (1 of 16 points shown). Figure 80 Field Wiring for 9663-610 with a 3601E or 3601T Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 126: 9664-810 (120 Vdc, Commoned, 16 Pts.)

    Specifications This table describes specifications for 9664–810. Table 73 Specifications for Term Panel 9664–810 Feature Description Panel type Commoned Points Maximum total current 16 amps Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 127 This figure illustrates how to connect the 16-point DC digital output module 3603E or 3603T and a 9664–810 to the field (1 of 16 points shown). Figure 82 Field Wiring for 9664-810 with a 3603E or 3603T Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 128 A load must be installed at every point to prevent a missing-load alarm. If a field load is not available, install a 2.2k ohm, 10W load resistor. Figure 83 Field Wiring for 9664-810 with a 3623T Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 129 Output to other Switch points Drive Circuitry Output Switch Drive spare Voltage Circuitry Loopback Detector LEDs are blown-fuse indicators Figure 85 Simplified Schematic of a 3623T DO Module with a Commoned DO Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 130: 9667-810 (48 Vdc, Commoned, 16 Pts.)

    This table describes digital output modules compatible with 9667–810. Table 76 Modules Compatible with 9667–810 Module Part Points per Primary Module Description Number Module Fuse 3607E 48 VDC, non-commoned, opto-isolated, TMR 1.5A, fast Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 131 This figure illustrates how to connect the 16-point DC digital output module 3607E and a 9667-810 to the field (1 of 16 points shown). Figure 86 Field Wiring for 9667-810 with a 3607E Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 132 PS2 – Output Switch Drive Circuitry Output Switch Drive spare Voltage Circuitry Loopback Detector LEDs are blown-fuse indicators Figure 87 Simplified Schematic of a 3607E DO Module with a Commoned DO Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 133: 16-Point Non-Commoned Digital Output Term Panels

    Typical 16-Point Non-Commoned DO Term Panel for Module 3603B This figure represents a typical 16-point non-commoned digital output termination panel for modules 3601E, 3604E, and 3607E. Figure 89 Typical 16-Point Non-Commoned DO Term Panel for Modules 3601E, 3604E, and 3607E Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 134: 9251-210 (120 Vdc, Non-Commoned, 16 Pts., 3603B Module)

    Each output point has a: • Positive and negative terminal for connecting to a field load. • Positive and negative terminal for connecting field power. • Blown-fuse indicator (LED). Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 135 Field Wiring Diagrams This figure illustrates how to connect a 16-point digital output module and a 9251–210 to the field (1 of 16 points shown). Figure 92 Field Wiring for 9251-210 with a 3603B Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 136: 9661-110 (115 Vac, Non-Commoned, 16 Pts.)

    9661-110 (115 VAC, non-commoned, 16 pts.) Termination panel 9661–110 is compatible with 115 VAC digital output modules and has: • 16 LOAD+ and LOAD– terminals • 16 PWR+ and PWR– terminals • 16 fuses with blown-fuse indicators Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 137 Field Wiring Diagrams This figure illustrates how to connect a 16-point digital output module and a 9661–110 to the field (1 of 16 points shown). Figure 94 Field Wiring for 9661-110 with a 3601E Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 138: 9662-110 (24 Vdc, Non-Commoned, 16 Pts.)

    • 16 LOAD+ and LOAD– terminals • 16 PWR+ and PWR– terminals • 16 fuses with blown-fuse indicators Specifications This table describes specifications for 9662–110. Table 81 Specifications for Term Panel 9662–110 Feature Description Panel type Non-commoned Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 139 Field Wiring Diagrams This figure illustrates how to connect a 16-point digital output module and a 9662–110 to the field (1 of 16 points shown). Figure 96 Field Wiring for 9662-110 with a 3604E Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 140: 9664-110 (115 Vac, Non-Commoned, 16 Pts.)

    • 16 LOAD+ and LOAD– terminals • 16 PWR+ and PWR– terminals • 16 fuses with blown-fuse indicators Specifications This table describes specifications for 9664–110. Table 83 Specifications for Term Panel 9664–110 Feature Description Panel type Non-commoned Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 141 This figure illustrates how to connect a 16-point digital output module and a 9664–110 to the field (1 of 16 points shown). Termination panel Power Typical point Supply (1 of 16 points shown) – Load Figure 98 Field Wiring for 9664-110 with a 3601E or 3601T Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 142: 9667-110 (48 Vdc, Non-Commoned, 16 Pts.)

    • 16 LOAD+ and LOAD– terminals • 16 PWR+ and PWR– terminals • 16 fuses with blown-fuse indicators Specifications This table describes specifications for 9667–110. Table 85 Specifications for Term Panel 9667–110 Feature Description Panel type Non-commoned Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 143 Field Wiring Diagrams This figure illustrates how to connect a 16-point digital output module and a 9667–110 to the field (1 of 16 points shown). Figure 100 Field Wiring for 9667-110 with a 3607E Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 144: 9668-110 (Non-Commoned Relay Output, 16 Pts.)

    17-32. For information on how to apply the labels, see Appendix F, Panel Labels. Specifications This table describes specifications for 9668–110. Table 87 Specifications for Term Panel 9668–110 Feature Description Panel type Non-commoned relay output Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 145 This figure illustrates how to connect a 32-point relay output module and a 9668–110 to the field (1 of 32 points shown). Figure 102 Field Wiring for 9668-110 with a 3636R or 3636T Relay Output Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 146 LOAD 1 + Loopback Detector/ Isolator LOAD 1 – Point Register PWR1 – spare module Figure 103 Simplified Schematic of a 3636R or 3636T Relay Output Module with a Non-Commoned Relay Output Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 147: Basic Digital Output Term Panels

    When using 32-point modules, you must use two term panels for each relay output module. When using modules that are not self-protected, it is up to you to provide protection for all outpoint points. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 148 Number Module 3601E 115 VAC, non-commoned, opto-isolated, TMR 3603E 120 VDC, commoned, opto-isolated, TMR 3623 120 VDC, commoned, supervised, opto-isolated, TMR 3636R Non-commoned, simplex, normally open, galvanically-isolated 3636T Non-commoned, simplex, normally open, galvanically-isolated Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 149 To prevent missing-load alarm, install a load at each unused point. If a field load is not available for model 3623, install a 2.2k ohm, 10 W load resistor. Figure 105 Field Wiring for 9651-110 with a 3601E, 3603E, or 3623 DO Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 150 For specifications, contact the lamp manufacturer. The inrush current may be 10–15 times the rated nominal load current of the lamp. Figure 106 Field Wiring for 9651-110 with a 3636R or 3636T Relay Output Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 151 RTN1 (2E) Drive Circuitry to other points Output Switch Drive Circuitry Output Switch Drive spare Voltage Circuitry Loopback Detector Figure 108 Simplified Schematic of a 3603E DO Module with a Basic DO Panel Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 152 Register 2A (C1) Voted Output Drive Point Circuitry Register Loopback Detector/ Isolator 2E (C1) Point Register Figure 110 Simplified Schematic of a 3636R or 3636T Relay Output Module with a Basic DO Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 153: 9652-610 (48 Vdc, Basic, 16 Pts.)

    Basic digital output Points Compatible Modules This table describes digital output modules compatible with 9652–610. Table 92 Modules Compatible with 9652–610 Module Part Points per Module Description Number Module 3607E 48 VDC, non-commoned, opto-isolated, TMR Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 154 One PWR connection per point is recommended. One RTN connection per point is recommended. To prevent missing-load alarm, install a load at each unused point. Figure 111 Field Wiring for 9652-610 with a 3607E DO Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 155: 9653-610 (24 Vdc, Basic, 16 Pts.)

    Modules 3624, 3625, 3664, and 3674 have built-in protection. Specifications This table describes specifications for 9653–610. Table 93 Specifications for Term Panel 9653–610 Feature Description Panel type Basic digital output Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 156 One PWR connection per point is recommended. One RTN connection per point is recommended. To prevent missing-load alarm, install a load at each unused point. Figure 113 Field Wiring for 9653-610 with a 3604E DO Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 157 One RTN connection per point is recommended. When using a 3624 module, install a load at each unused point to prevent missing-load alarm. Figure 114 Field Wiring for 9653-610 with a 3624 or 3625 DO Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 158 Field Wiring for 9653-610 with a 3664 or 3674 DO Module Simplified Schematics This is a simplified schematic of a typical 16-point non-commoned digital output module with a basic digital output panel (1 of 16 points shown). Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 159 Simplified Schematic of a 3624 DO Module with a Basic DO Panel This is a simplified schematic of a typical 32-point commoned supervised digital output module with a basic digital output panel (1 of 32 points shown). Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 160 A or C Current Output Loopback Switch Detector Analog/ Drive Digital Circuitry Voltage spare Loopback Detector All output switches are opto-isolated. Figure 118 Simplified Schematic of a 3625 DO Module with a Basic DO Panel Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 161 Drive Circuitry LOAD1 (2C) RTN1 (2E) Voted Drive Output Circuitry Loopback Detector/ Isolator spare to other points Figure 119 Simplified Schematic of a 3664 or 3674 DO Module with a Basic DO Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 162: Commoned Interposing Relay Term Panels

    Each terminal accepts either #6 ring-lug terminals or 24-to-12-gauge (0.3mm to 2.1mm ) wires. Relay contacts are not protected by a fuse to allow maximum flexibility CAUTION for the application. You must provide the necessary contact protection for your application. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 163 Compatible Modules This table describes digital output modules compatible with 9670–610. Table 96 Modules Compatible with 9670–610 Module Part Points per Module Description Fuse Number Module 3601E 115 VAC, non-commoned, opto-isolated, TMR 3A, fast Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 164 This figure illustrates how to connect a 16-point digital output module and a 9670–610 to the field (1 of 16 points shown). Figure 121 Field Wiring for 9670-610 with a 3601E DO Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 165: 9671-810 (24 Vdc, Commoned Interposing Relay, 16 Pts.)

    Each term panel comes with two sets of labels: 1-16 and 17-32. For information on how to apply the labels, see Appendix F, Panel Labels. Each terminal accepts either #6 ring-lug terminals or 24-to-12-gauge (0.3mm to 2.1mm ) wires. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 166 10 to 15 times the rated nominal load current of the lamp. Use the inrush current to calculate the required output switching power. Contact the lamp manufacturer for detailed specifications regarding inrush amplitude and duration. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 167 9671-810 to the field (1 of 16 or 32 points shown). Figure 123 Field Wiring for 9671-810 with a 3604E, 3664, or 3674 DO Module Do not exceed 10 inch-pounds (1.13 Nm) of torque when securing leads CAUTION to the #6 terminal. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 168 Bridge Current- rectifier limiting Optical isolation Smoothing Threshold Detect other points Opto-Isolator spare module LEDs are blown-fuse indicators Figure 124 Simplified Schematic of a 3604E DO Module with a Commoned Interposing Relay Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 169: 9672-810 (48 Vdc, Commoned Interposing Relay, 16 Pts.)

    Each terminal accepts either #6 ring-lug terminals or 24-to-12-gauge (0.3mm to 2.1mm ) wires. Relay contacts are not protected by a fuse to allow maximum flexibility CAUTION for the application. You must provide the necessary contact protection for your application. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 170 Compatible Modules This table describes digital output modules compatible with 9672–810. Table 100 Modules Compatible with 9672–810 Module Part Points per Module Description Fuse Number Module 3607E 48 VDC, non-commoned, opto-isolated, TMR 1.25A, fast Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 171 (1 of 16 points shown). Figure 126 Field Wiring for 9672-810 with a 3607E DO Module Do not exceed 10 inch-pounds (1.13 Nm) of torque when securing leads CAUTION to the #6 terminal. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 172: 9673-810 (120 Vdc, Commoned Interposing Relay, 16 Pts.)

    Each terminal accepts either #6 ring-lug terminals or 24-to-12-gauge (0.3mm to 2.1mm ) wires. Relay contacts are not protected by a fuse to allow maximum flexibility CAUTION for the application. You must provide the necessary contact protection for your application. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 173 This table describes digital output modules compatible with 9673–810. Table 102 Modules Compatible with 9673–810 Module Part Points per Module Description Fuse Number Module 3603E 120 VDC, commoned, opto-isolated, TMR 1A, fast 3603T 120 VDC, commoned, opto-isolated, TMR 1A, fast Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 174 (1 of 16 points shown). Figure 128 Field Wiring for 9673-810 with a 3603E or 3603T DO Module Do not exceed 10 inch-pounds (1.13 Nm) of torque when securing leads CAUTION to the #6 terminal. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 175 Optical isolation Smoothing Threshold Detect other points Opto-Isolator spare module LEDs are blown-fuse indicators Figure 129 Simplified Schematic of a 3603E or 3603T DO Module with a Commoned Interposing Relay Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 176: Non-Commoned Interposing Relay Term Panels

    Each terminal accepts either #6 ring-lug terminals or 24-to-12-gauge (0.3mm to 2.1mm ) wires. Relay contacts are not protected by a fuse to allow maximum flexibility CAUTION for the application. You must provide the necessary contact protection for your application. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 177 Compatible Modules This table describes digital output modules compatible with 9670–110. Table 104 Modules Compatible with 9670–110 Module Part Points per Module Description Fuse Number Module 3601E 115 VAC, non-commoned, opto-isolated, TMR 3A, fast Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 178 This figure illustrates how to connect a 16-point digital output module and a 9670–110 to the field (1 of 16 points shown). Figure 131 Field Wiring for 9670-110 with a 3601E DO Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 179 Bridge Current- rectifier limiting Optical isolation Smoothing Threshold Detect other points Opto-Isolator spare module LEDs are blown-fuse indicators Figure 132 Simplified Schematic of a 3601E DO Module with a Non-Commoned Interposing Relay Panel Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 180 168 Chapter 4 Digital Output Termination Panels Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 181: Analog Input And Analog Output Termination Panels

    Overview 170 16-Point Current Input Term Panels 171 32-Point Current Input Term Panels 188 Thermocouple Input Term Panels 199 Voltage Input Term Panels 208 RTD/TC/AI Input Term Panels 218 Analog Output Term Panels 229 Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 182: Overview

    • Panels for use with signal conditioners, which interface with resistive thermal devices, thermocouples, and 4-20 mA transmitters (RTD/TC/AI) Analog output termination panels are available in 8-point current output and 4-point bipolar output configurations. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 183: 16-Point Current Input Term Panels

    This figure represents a typical 16-point current input termination panel. Figure 133 Typical 16-Point Current Input Term Panel This figure represents a typical 16-point, current input, user-configurable, termination panel. Figure 134 Typical 16-Point Current Input User-Configurable Term Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 184: 9761-210 (Current Input, 0-5 Vdc, 16 Pts.)

    0–5 VDC, non-commoned, differential, DC-coupled, TMR 3700A 0–5 VDC, non-commoned, differential, DC-coupled, TMR, +6% input over-range measurement 3721 0 to 5 VDC or –5 to +5 VDC (Use TriStation to configure input range), differential, DC-coupled, TMR Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 185 Field Wiring for 9761-210 with a 3700, 3700A, or 3721 AI Module or a 2770H HART AI Interface Module Note For additional instructions on installing HART Interface Modules, see the Planning and Installation Guide for Tricon v9–v10 Systems. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 186 32-POINT ANALOG INPUT MODULES spare Isolation/filtering 180 Ohms Hi-Ref Low-Ref other points 250 Ohms Hi-Ref Low-Ref Hi-Ref Low-Ref Figure 136 Simplified Schematic of a 3700, 3700A, or 3721 AI Module with a 9761-210 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 187: 9761-410 (Current Input, 0-10 Vdc, 16 Pts.)

    The modules compatible with 9761-410 have 32 points, which means you must use two term panels for each analog input module. Each term panel comes with two sets of labels: 1-16 and 17-32. For information on how to apply the labels, see Appendix F, Panel Labels. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 188 Module Part Points per Module Description Number Module 3701 0–10 VDC, non-commoned, differential, DC-coupled, TMR 3721 0 to 5 VDC or –5 to +5 VDC (Use TriStation to configure input range), differential, DC-coupled, TMR Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 189 This figure illustrates how to connect a 32-point analog input module and a 9761–410 to the field (1 of 32 module points shown). See Appendix E, Shield Ground for shield ground installation guidelines. Figure 138 Field Wiring for 9761-410 with a 3701 or 3721 AI Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 190: 9762-210 (Current Input, 0-5 Vdc, 16 Pts.)

    250 Ohm resistor for 0–5 VDC current-to-voltage conversion. The panel supports redundant 24 VDC power sources with diode ORing. Specifications This table describes specifications for 9762–210. Table 109 Specifications for Term Panel 9762–210 Feature Description Panel type Current input Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 191 This figure illustrates how to connect a 16-point analog input module and a 9762–210 to the field (1 of 16 module points shown). See Appendix E, Shield Ground for shield ground installation guidelines. Figure 140 Field Wiring for 9762-210 with a 3703E AI Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 192: 9762-410 (Current Input, 0-10 Vdc, 16 Pts.)

    500 Ohm resistor for 0–10 VDC current-to-voltage conversion. The panel supports redundant 24 VDC power sources with diode ORing. Specifications This table describes specifications for 9762–410. Table 111 Specifications for Term Panel 9762–410 Feature Description Panel type Current input Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 193 This figure illustrates how to connect a 16-point analog input module and a 9762–410 to the field (1 of 16 module points shown). See Appendix E, Shield Ground for shield ground installation guidelines. Figure 142 Field Wiring for 9762-410 with a 3703E AI Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 194 TERMINATION PANEL CABLE BACKPLANE 16-POINT ANALOG INPUT MODULES spare 180 Ohms Hi-Ref Low-Ref other points 500 Ohms Hi-Ref Low-Ref Hi-Ref Low-Ref Figure 143 Simplified Schematic of a 3703E AI Module with a 9762-410 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 195: 9771-210 (Current Input, 0-5 Vdc, User Configurable, 16 Pts.)

    0–5 VDC or 0–10 VDC (Use TriStation to configure for 0–5 VDC), non- commoned, differential, isolated, TMR 3721 0 to 5 VDC or –5 to +5 VDC (Use TriStation to configure input range), differential, DC-coupled, TMR Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 196 Typical point (1 of 16 points shown) Power Supply Field Xmtr (4-20 mA) – Power Supply Shield Ground Figure 144 Field Wiring for 9771-210 with a 3700, 3700A, 3703E, or 3721 AI Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 197 The sharing capability of this termination panel should only be used in those applications where these restrictions do not exist, or can be otherwise mitigated. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 198 ** To aid sharing the field transmitter with another system (for example, a DCS), the W jumper may be removed. Figure 146 Simplified Schematic of a 3700, 3700A, or 3721 AI Module with a 9771-210 Panel Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 199 ** To aid sharing the field transmitter with another system (for example, a DCS), the W jumper may be removed. Figure 147 Simplified Schematic of a 3703E AI Module with a 9771-210 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 200: 32-Point Current Input Term Panels

    This figure represents a typical 32-point current input basic panel. Figure 148 Typical 32-Point Current Input Basic Term Panel This figure represents a typical 32-point current input termination panel. Figure 149 Typical 32-Point Current Input Term Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 201: 9750-210 (Current Input, 0-5 Vdc, Basic, 32 Pts.)

    Modules Compatible with 9750–210 Module Part Points per Module Description Number Module 3704E 0–5 VDC or 0–10 VDC (Use TriStation to configure for 0–5 VDC), commoned, high-density, DC-coupled, TMR 3720 0–5 VDC, single-ended, high-density, TMR Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 202 This figure illustrates how to connect a 64-point analog input module and a 9750–210 to the field (1 of 64 module points shown). * One RTN connection is required. More than one is okay. Figure 150 Field Wiring for 9750-210 with a 3704E or 3720 AI Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 203: 9760-210 (Current Input, 0-5 Vdc, 32 Pts.)

    33-64. For information on how to apply the labels, see Appendix F, Panel Labels. Specifications This table describes specifications for 9760–210. Table 117 Specifications for Term Panel 9760–210 Feature Description Panel type Current input Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 204 This figure illustrates how to connect a 64-point analog input module and a 9760–210 to the field (1 of 64 module points shown). See Appendix E, Shield Ground for shield ground installation guidelines. Figure 152 Field Wiring for 9760-210 with a 3704E or 3720 AI Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 205: 9760-410 (Current Input, 0-10 Vdc, 32 Pts.)

    33-64. For information on how to apply the labels, see Appendix F, Panel Labels. Specifications This table describes specifications for 9760–410. Table 119 Specifications for Term Panel 9760–410 Feature Description Panel type Current input Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 206 This figure illustrates how to connect a 64-point analog input module and a 9760–410 to the field (1 of 64 module points shown). See Appendix E, Shield Ground for shield ground installation guidelines. Figure 154 Field Wiring for 9760-410 with a 3704E or 3720 AI Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 207: 9765-210 (3-Wire Current Input, 0-5 Vdc, 32 Pts.)

    The modules compatible with 9765–210 have 64 points, which means you must use two term panels for each analog input module. Each term panel comes with two sets of labels: 1-32 and 33-64. For information on how to apply the labels, see Appendix F, Panel Labels. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 208 Modules Compatible with 9765–210 Module Part Points per Module Description Number Module 3704E 0–5 VDC or 0–10 VDC (Use TriStation to configure for 0–5 VDC), commoned, high-density, DC-coupled, TMR 3720 0–5 VDC, single-ended, high-density, TMR Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 209 This figure illustrates how to connect a 64-point, 3-wire analog input module and a 9765–210 to the field (1 of 64 module points shown). See Appendix E, Shield Ground for shield ground installation guidelines. Figure 156 Field Wiring for 9765-210 with a 3704E or 3720 AI Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 210 50 mA Isolation/ filtering Ohms 500 mA Hi-Ref Low-Ref other points Hi-Ref Low-Ref Hi-Ref Low-Ref *LEDs are blown-fuse indicators. Figure 157 Simplified Schematic of a 3704E or 3720 AI Module with a 9765-210 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 211: Thermocouple Input Term Panels

    • TMR cold-junction temperature sensors • Upscale/downscale open-input bias circuitry Specifications This table describes specifications for 9765–610. Table 123 Specifications for Term Panel 9765–610 Feature Description Panel type Thermocouple input, upscale or downscale Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 212 Termination panel Typical unused point Typical point (1 of 16 points shown) – Shield Ground Figure 159 Field Wiring for 9765-610 with a 3708E Thermocouple Input Module Unused points must be shorted together. CAUTION Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 213: 9766-210 (Tc Input, Upscale, 16 Pts.)

    The modules compatible with 9766–210 have 32 points, which means you must use two term panels for each thermocouple input module. Each term panel comes with two sets of labels: 1- 16 and 17-32. For information on how to apply the labels, see Appendix F, Panel Labels. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 214 Table 126 Modules Compatible with 9766–210 Module Part Points per Module Description Number Module 3706A Type J, K, and T, differential, non-isolated, DC-coupled, TMR, upscale open-input detection. (Use TriStation to configure the thermocouple type.) Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 215 Termination panel Typical unused point Typical point (1 of 16 points shown) – Shield Ground Figure 161 Field Wiring for 9766-210 with a 3706A Thermocouple Input Module Unused points must be shorted together. CAUTION Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 216: 9766-510 (Tc Input, Downscale, 16 Pts.)

    The modules compatible with 9766–510 have 32 points, which means you must use two term panels for each thermocouple input module. Each term panel comes with two sets of labels: 1- 16 and 17-32. For information on how to apply the labels, see Appendix F, Panel Labels. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 217 Table 128 Modules Compatible with 9766–510 Module Part Points per Module Description Number Module 3706A Type J, K, and T, differential, non-isolated, DC-coupled, TMR, upscale open-input detection. (Use TriStation to configure the thermocouple type.) Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 218 Termination panel Typical unused point Typical point (1 of 16 points shown) – Shield Ground Figure 163 Field Wiring for 9766-510 with a 3706A Thermocouple Input Module Unused points must be shorted together. CAUTION Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 219 (1 of 32 module points shown). TERMINATION PANEL CABLE BACKPLANE 32-POINT THERMOCOUPLE INPUT MODULES spare Isolation/filtering –V Hi-Ref Low-Ref Hi-Ref Low-Ref Hi-Ref Low-Ref Figure 164 Simplified Schematic of a 3706A Thermocouple Input Module with a 9766-510 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 220: Voltage Input Term Panels

    This figure represents a typical 16-point voltage input basic termination panel. Figure 165 Typical 16-Point Voltage Input Basic Term Panel This figure represents a typical 16-point voltage input termination panel. Figure 166 Typical 16-Point Voltage Input Term Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 221: 9750-810 (0-5 Vdc/0-10 Vdc Voltage Input, Basic, 32 Pts.)

    Module Part Points per Module Description Number Module 3704E 0–5 VDC or 0–10 VDC (Use TriStation to configure for 0–5 VDC or 0–10 VDC), commoned, high-density, DC-coupled, TMR 3720 0–5 VDC, single-ended, high-density, TMR Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 222 This figure illustrates how to connect a 64-point analog input module and a 9750–810 to the field (1 of 64 module points shown). Figure 168 Field Wiring for 9750-810 with a 3704E or 3720 AI Module Unused points must be shorted together. CAUTION Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 223: 9753-110 (0-5 Vdc/0-10 Vdc Voltage Input, Basic, 16 Pts.)

    1-16 and 17-32. For information on how to apply the labels, see Appendix F, Panel Labels. Specifications This table describes specifications for 9753–110. Table 131 Specifications for Term Panel 9753–110 Feature Description Panel type Voltage input, basic Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 224 (1 of 16 or 32 module points shown). Figure 170 Field Wiring for 9753-110 with a 3700, 3700A, 3701, 3703E, or 3721 AI Module Unused points must be shorted together. CAUTION Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 225 32-POINT ANALOG INPUT MODULES PANEL spare Isolation/filtering IN1 + Hi-Ref IN1 – Low-Ref Hi-Ref Low-Ref Hi-Ref Low-Ref Figure 171 Simplified Schematic of a 3700, 3700A, 3701, or 3721 AI Module with a 9753-110 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 226: 9763-810 (0-5 Vdc/0-10 Vdc Voltage Input, 16 Pts.)

    Each term panel comes with two sets of labels: 1-16 and 17-32. For information on how to apply the labels, see Appendix F, Panel Labels. Specifications This table describes specifications for 9763–810. Table 133 Specifications for Term Panel 9763–810 Feature Description Panel type Voltage input Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 227 (1 of 16 or 32 module points shown). Figure 173 Field Wiring for 9763-810 with a 3700, 3700A, 3701, 3703E, or 3721 AI Module Unused points must be shorted together. CAUTION Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 228 TERMINATION PANEL CABLE BACKPLANE 32-POINT ANALOG INPUT MODULES spare Isolation/filtering Hi-Ref Low-Ref Hi-Ref Low-Ref Hi-Ref Low-Ref Figure 174 Simplified Schematic of a 3700, 3700A, 3701, or 3721 AI Module with a 9763-810 Panel Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 229 (1 of 16 module points shown). TERMINATION CABLE BACKPLANE 16-POINT ANALOG INPUT MODULES PANEL spare Hi-Ref Low-Ref Hi-Ref Low-Ref Hi-Ref Low-Ref Figure 175 Simplified Schematic of a 3703E AI Module with a 9763-810 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 230: Rtd/Tc/Ai Input Term Panels

    17-32. For information on how to apply the labels, see Appendix F, Panel Labels. Specifications This table describes specifications for 9764–310. Table 135 Specifications for Term Panel 9764–310 Feature Description Panel type RTD/TC/AI Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 231 For more information on analog input modules, see the Planning and Installation Guide for Tricon v9–v10 Systems. The input-signal conditioning modules used on Triconex termination panels are manufactured by Analog Devices™. Signal conditioning modules must be ordered separately and are available from Triconex or directly from Analog Devices.
  • Page 232 Type B Thermocouple (+800°C to Input Module +1800°C) Isolated, Linearized, +392°F to +2372°F +1 V to +5 V 7B47-N-11-1 1600024-160 Type N Thermocouple (+200°C to Input Module +1300°C) Shorting plug for unused 18201 1600048-300 points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 233 (1 of 16 points shown). Shield Point #12 Typical, see 9764-310 RTD/TC/AI ETP Pin-Outs on page 223 for other points Figure 178 Field Wiring for 9764-310 with RTD Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 234 (1 of 16 points shown). Field – Transmitter Point #6 Typical, see 9764-310 RTD/TC/AI ETP Pin-Outs on page 223 for other points Figure 180 Field Wiring for 9764-310 with AI Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 235 + and SH J3B (lower) J3A (upper) J3B (lower) Jump J3A (upper) J3B (lower) Jump Point 2 J3A (upper) – and SH – – J3B (lower) J3A (upper) + and SH J3B (lower) Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 236 + and SH J4B (lower) J4A (upper) J4B (lower) Jump J4A (upper) J4B (lower) Jump Point 6 J4A (upper) – and SH – – J4B (lower) J4A (upper) + and SH J4B (lower) Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 237 + and SH J5B (lower) J5A (upper) J5B (lower) Jump J5A (upper) J5B (lower) Jump Point 10 J5A (upper) – and SH – – J5B (lower) J5A (upper) + and SH J5B (lower) Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 238 + and SH J6B (lower) J6A (upper) J6B (lower) Jump J6A (upper) J6B (lower) Jump Point 14 J6A (upper) – and SH – – J6B (lower) J6A (upper) + and SH J6B (lower) Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 239 Point 16 J6A (upper) – and SH – – J6B (lower) J6A (upper) + and SH J6B (lower) 1. NC = No connect 2. X = Third wire (sense signal) 3. SH = Shield Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 240 Isolation/filtering Hi-Ref Low-Ref 7BXX – Typical Signal Conditioner Hi-Ref Low-Ref Hi-Ref Low-Ref * LEDs are blown-fuse indicators. Figure 182 Simplified Schematic of a 3700 or 3700A AI Module with a 9764-310 (RTD/TC/AI) Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 241: Analog Output Term Panels

    Typical Basic Current Output Term Panel This figure represents a typical BiPolar Analog Output termination panel. EXT TERM TRICON TRICONEX ATEX BPAO ETP 7400305 REV B Figure 185 Typical BiPolar Analog Output Term Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 242: 9863-710 (3806E Module, 8 Pts.)

    This table describes analog output modules compatible with 9863-710. Table 140 Modules Compatible with 9863-710 Module Part Points per Module Description Number Module 3806E 6 4–20 mA outputs, 2 20–320 mA outputs, commoned-return, DC- coupled, TMR Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 243 ** One RTN connection is required. More than one is okay. *** Typically connected to current analog input point to monitor 20–320 mA output voltages. Figure 186 Field Wiring for 9863-710 with a 3806E AO Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 244 PWRB (24A) RTN (22E) RTN (24E) Selector Logic Current loopback OUT2 (6A) Typical points RTN2 (6E) Selector Logic Current loopback Figure 187 Simplified Schematic of 3806E AO Module with a 9863-710 Panel Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 245 PWRB Power B + Power B – VT1+ Channel 1 V-to-I Out VT1- Channel 1 V-to-I Return VT5+ Channel 5 V-to-I Out VT5- Channel 5 V-to-I Return CGND Chassis Ground CGND Chassis Ground Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 246 The volt/amp characteristics of the good coils are programmed into the controller. A significant deviation in the volt/amp characteristics causes an alarm to be issued. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 247 This is a simplified schematic of a voltage-to-current converter. INPUT 0-28 VDC LOGIC SUPPLY E TO I 24 VDC CONVERTER OUTPUT 4-20 mA EQUIVALENT CIRCUIT Figure 190 Simplified Schematic of a Voltage-to-Current Converter Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 248: 9853-610 (Current Output, Basic, 8 Pts.)

    • 8 current return terminals (RTN) • Terminals for connecting redundant 24 VDC power supplies Specifications This table describes specifications for 9853–610. Table 143 Specifications for Term Panel 9853–610 Feature Description Panel type Current output, basic Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 249 Field Wiring for 9853-610 with a 3805E or 3805H AO Module or 2870H HART AO Interface Module Note For additional instructions on installing HART Interface Modules, see the Planning and Installation Guide for Tricon v9–v10 Systems. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 250 PWRB (24A) RTN (22E) RTN (24E) Selector Logic Current loopback OUT1 (2A) RTN1 (2E) Selector Logic Current loopback Figure 192 Simplified Schematic of a 3805E or 3805H AO Module with a 9853-610 Panel Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 251 2071 HART HART MUX MODULE CONTROLLER RS-485 HART CABLE CONTROLLER Figure 193 Simplified Schematic of a 2870H HART AO Interface Module with a 3805E or 3805H AO Module and a 9853-610 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 252: 9871-810 (3807 Module, 4 Pts.)

    This table describes the analog output module compatible with 9871–810. Table 146 Module Compatible with 9871–810 Module Part Points per Module Description Number Module 3807 4 analog output -60 to 60 mA analog outputs, commoned-return, DC-coupled, TMR with coil-diagnostic inputs Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 253 • If the I/O cable (the cable that connects the termination panel to the Tricon backplane) goes outside the cabinet that houses the Tricon chassis, the I/O cable should be routed in a metal conduit. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 254 Analog Coil Diagnostic Inputs Inputs Channel Select Shown with ATEX Field Return to Protective Earth (chassis ground) jumper installed Figure 195 Simplified Schematic of a 3807 BiPolar AO Module with a 9871-810 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 255: Chapter 6 Hazardous Location (Nonincendive) Termination Panels

    Overview 244 Field Wiring in Hazardous Locations 245 Analog Input Term Panels 246 Analog Output Term Panels 268 Digital Input Term Panels 275 Digital Output Term Panels 286 Pulse Input Term Panels 292 Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 256: Overview

    Digital Input 9572-610 24 VDC, commoned, 16 pts. 9570-610 24 VDC, high-density, 32 pts. 9571-610 24 VDC, fail-safe, 32 pts. Digital Output 9671-610 24 VDC, commoned, supervised, 16 pts. Pulse Input 9793-110 8 pts. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 257: Field Wiring In Hazardous Locations

    3 of the Planning and Installation Guide for Tricon v9–v10 Systems. In Europe, the ETPs listed in this chapter are in full compliance with the ATEX Directive and are suitable for use in Zone 2 Group IIB hazardous locations per the requirements of EN 60079-15, Electrical apparatus for explosive gas atmospheres - Part 15: Type protection “n”.

  • Page 258: Analog Input Term Panels

    1-16 and 17-32. For information on how to apply the labels, see Appendix F, Panel Labels. Specifications This table describes general specifications for 9791-610. Table 148 General Specifications for Term Panel 9791-610 Feature Description Panel type Current input, 4–20 mA Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 259 CAUTION modules may be affected by up to –0.08% Full-Scale Range (FSR), at maximum temperature. As a result, the accuracy of these modules is +0.15% to –0.23% FSR, at 140° F (60° C). Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 260 Field Wiring for 9791-610 with a 3700A, 3703E, or 3721 AI Module or 2770H HART AI Interface Module Note For additional instructions on installing HART Interface Modules, see the Planning and Installation Guide for Tricon v9–v10 Systems. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 261 32-POINT ANALOG INPUT MODULES TERMINATION PANEL spare Isolation/filtering 190–310 Ohms Hi-Ref Low-Ref other points 250 Ohms Hi-Ref Low-Ref Hi-Ref Low-Ref Figure 197 Simplified Schematic of a 3700A or 3721 Analog Input Module with a 9791-610 Panel Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 262 Hi-Ref Low-Ref other points 250 Ohms Hi-Ref Low-Ref Hi-Ref Low-Ref Figure 198 Simplified Schematic of a 2770H HART AI Interface Module with a 3700A or 3721 Analog Input Module and a 9791-610 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 263: 9787-110 (0-5 Vdc Voltage Input, 16 Pts.)

    When using 32-point modules, you must use two term panels for each module. Each term panel comes with two sets of labels: 1-16 and 17-32. For information on how to apply the labels, see Appendix F, Panel Labels. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 264 Output Connection (I+ and I–) Specifications when Used with 3703E Maximum output voltage 15 V Maximum output current 0.005 A Maximum output power 0.075 W C external, maximum 20.14 µF L external, maximum Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 265 9787-110 to the field (1 of 16 or 32 module points shown). See Appendix E, Shield Ground shield ground installation guidelines. Figure 200 Field Wiring for 9787-110 with a 3700A, 3703E, or 3721 AI Module Unused points must be shorted together. CAUTION Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 266 (1 of 32 module points shown). TERMINATION PANEL CABLE BACKPLANE 32-POINT ANALOG INPUT MODULES spare Isolation/filtering Hi-Ref Low-Ref Hi-Ref Low-Ref Hi-Ref Low-Ref Figure 201 Simplified Schematic of a 3700A or 3721 Analog Input Module with a 9787-110 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 267: 9785-610 (Tc Input, Downscale, 16 Pts.)

    The modules compatible with 9785–610 have 32 points, which means you must use two term panels for each thermocouple input module. Each term panel comes with two sets of labels: 1-16 and 17-32. For information on how to apply the labels, see Appendix F, Panel Labels. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 268 Table 156 Module Compatible with 9785-610 Module Part Points per Module Description Number Module 3706A Type J, K, and T, differential, non-isolated, DC-coupled, TMR, upscale open-input detection. (Use TriStation to configure the thermocouple type.) Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 269 (1 of 32 module points shown). See Appendix E, Shield Ground for shield ground installation guidelines. Figure 203 Field Wiring for 9785-610 with a 3706A Thermocouple Input Module Unused points must be shorted together. CAUTION Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 270: 9784-610 (Tc Input, Upscale, 16 Pts.)

    The modules compatible with 9784–610 have 32 points, which means you must use two term panels for each thermocouple input module. Each term panel comes with two sets of labels: 1-16 and 17-32. For information on how to apply the labels, see Appendix F, Panel Labels. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 271 Table 159 Module Compatible with 9784-610 Module Part Points per Module Description Number Module 3706A Type J, K, and T, differential, non-isolated, DC-coupled, TMR, upscale open-input detection. (Use TriStation to configure the thermocouple type.) Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 272 (1 of 32 module points shown). See Appendix E, Shield Ground for shield ground installation guidelines. Figure 205 Field Wiring for 9784-610 with a 3706A Thermocouple Input Module Unused points must be shorted together. CAUTION Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 273 (1 of 32 module points shown). TERMINATION PANEL CABLE BACKPLANE 32-POINT THERMOCOUPLE INPUT MODULES spare Isolation/filtering –V Hi-Ref Low-Ref Hi-Ref Low-Ref Hi-Ref Low-Ref Figure 206 Simplified Schematic of a 3706A Thermocouple Input Module with a 9784-610 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 274: 9786-110 (Tc Input, Upscale/Downscale, 16 Pts.)

    32° F to 140° F (0° C to 60° C) Output Connection (I+ and I–) Specifications Maximum output voltage 15 V Maximum output current 0.005 A Maximum output power 0.075 W C external, maximum 20.14 µF L external, maximum Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 275 (1 of 16 module points shown). See Appendix E, Shield Ground for shield ground installation guidelines. Figure 207 Field Wiring for 9786-110 with a 3708E Thermocouple Input Module Unused points must be shorted together. CAUTION Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 276: 9789-610 (4-20 Ma, High-Density, 32 Pts.)

    The modules compatible with 9789-610 have 64 points, which means you must use two term panels for each module. Each term panel comes with two sets of labels: 1-32 and 33-64. For information on how to apply the labels, see Appendix F, Panel Labels. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 277 L internal, maximum 43 µH Output Connection (+) Specifications Maximum output voltage 32 V Maximum output current 0.169 A Maximum output power 1.347 W C external, maximum 1.18 µF L external, maximum 4.95 mH Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 278 This figure illustrates how to connect a 3704E or 3720 analog input module and a 9789-610 to the field (1 of 64 module points shown). See Appendix E, Shield Ground for shield ground installation guidelines. Figure 209 Field Wiring for 9789-610 with a 3704E or 3720 AI Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 279 64-POINT ANALOG INPUT MODULE spare 190-310 Ohms Hi-Ref Low-Ref other points 250 Ohms Hi-Ref Low-Ref Hi-Ref Low-Ref Figure 210 Simplified Schematic of a 3704E or 3720 Analog Input Module with a 9789-610 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 280: Analog Output Term Panels

    Maximum voltage 32 V Output Connection (L+) Specifications Maximum output voltage 32 V Maximum output current 0.126 A Maximum output power 0.990 W C external, maximum 1.15 µF L external, maximum 4.95 mH Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 281 9861–610 to the field (1 of 8 module points shown). Figure 211 Field Wiring for 9861-610 with a 3805E or 3805H AO Module or a 2870H HART AO Interface Module Unused points must be shorted together. CAUTION Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 282 Selector Logic Current loopback PWRB Selector Logic Current loopback OUT2 Typical point RTN2 Selector Logic Current loopback Figure 212 Simplified Schematic of a 3805E or 3805H Analog Output Module with a 9861-610 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 283: 9871-810 (3807 Module, 4 Pts.)

    • Two terminals per point: Out, Rtn (L+, L–) • Per point snubbers suitable for inductive loads up to 1.0 henries • A four-position terminal for redundant 24 VDC loop power • Two, one-position terminals for protective earth connection Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 284 Maximum voltage 32 V Output Connection (L+) Specifications Maximum output voltage 32 V Maximum output current 0.126 mA Maximum output power 0.990 W C external, maximum 1.15 µF L external, maximum 4.95 mH Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 285 • If the I/O cable (the cable that connects the termination panel to the Tricon backplane) goes outside the cabinet that houses the Tricon chassis, the I/O cable should be routed in a metal conduit. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 286 +18 / -18 Analog Coil Diagnostic Inputs Inputs Channel Select ATEX-required Field Return to Protective Earth (chassis ground) jumper Figure 215 Simplified Schematic of a 3807 BiPolar Analog Output Module with a 9871-810 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 287: Digital Input Term Panels

    Appendix F, Panel Labels. Specifications This table describes general specifications for 9572-610. Table 172 General Specifications for Term Panel 9572-610 Feature Description Panel type Commoned Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 288 3503E 24 VAC/VDC, commoned in groups of 8, TMR with self-test 3505E 24 VDC, low-threshold, commoned in groups of 8 with self test, TMR 3515 0 to 1 kHz pulse totalizer input, non-commoned Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 289 This figure illustrates how to connect a 3503E or a 3505E digital input module and a 9572-610 to the field (1 of 32 module points shown). Figure 216 Field Wiring for 9572-610 with a 3503E or 3505E DI Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 290 Do not use mechanical relay/switch contacts. To prevent point-to-point cross-talk, use individually shielded, twisted-pair wire for lengths greater than 50 feet (15 meters). Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 291 250 Ohms Opto-Isolator Mux B Test B Threshold Detect Input Opto-Isolator Mux C spare module Test C Figure 218 Simplified Schematic of a 3503E or 3505E Digital Input Module with a 9572-610 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 292: 9570-610 (24 Vdc, High-Density, 32 Pts.)

    The modules compatible with 9570-610 have 64 points, which means you must use two term panels for each module. Each term panel comes with two sets of labels: 1-32 and 33-64. For information on how to apply the labels, see Appendix F, Panel Labels. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 293 L internal, maximum 30.0 µH Output Connection (+) Specifications Maximum output voltage 32 V Maximum output current 0.169 A Maximum output power 1.347 W C external, maximum 1.18 µF L external, maximum 4.96 mH Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 294 This figure illustrates how to connect a 3504E digital input module and a 9570-610 to the field (1 of 64 module points shown). Figure 220 Field Wiring for 9570-610 with a 3504E DI Module Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 295: 9571-610 (24 Vdc, Fail-Safe, 32 Pts.)

    The modules compatible with 9571-610 have 64 points, which means you must use two term panels for each module. Each term panel comes with two sets of labels: 1-32 and 33-64. For information on how to apply the labels, see Appendix F, Panel Labels. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 296 4.96 mH Compatible Modules This table describes the digital input module compatible with 9571-610. Table 180 Module Compatible with 9571-610 Module Part Points per Module Description Number Module 3564 24 VDC, commoned, fail-safe, single Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 297 (opto-isolated) 190-310 Ohms to other points & sensors other points Threshold Detect Opto-Isolator Test OFF Relays (opto-isolated) other points Figure 223 Simplified Schematic of a 3564 Digital Input Module with a 9571-610 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 298: Digital Output Term Panels

    When using 32 point modules, you must use two term panels for each digital output module. Each term panel comes with two sets of labels: 1-16 and 17-32. For information on how to apply the labels, see Appendix F, Panel Labels. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 299 24 VDC, non-commoned, opto-isolated, TMR 3624 24 VDC, commoned, supervised, opto-isolated, self-protected, TMR 3625 24 VDC, commoned, supervised/non-supervised, opto-isolated, self- protected, TMR 3664 24 VDC, commoned, opto-isolated, self-protected, dual 3674 24 VDC, commoned, opto-isolated, self-protected, dual Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 300 * A load must be installed at every point to prevent missing-load alarm. If a field load is not available, install a 470 Ohm, 10 W load resistor. Figure 224 Field Wiring for 9671-610 with a 3604E, 3624, or 3625 DO Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 301 This figure illustrates how to connect a 3664 or a 3674 dual digital output module and a 9671-610 to the field (1 of 32 module points shown). Figure 225 Field Wiring for 9671-610 with a 3664 or 3674 DO Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 302 PS2 – Output to other Switch points Drive Circuitry Output Switch Drive spare Voltage Circuitry Loopback Detector Figure 227 Simplified Schematic of a 3624 Digital Output Module with a 9671-610 Panel Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 303 L – Output Circuitry PS1 – to other points PS2 – Loopback Detector/ Isolator spare to other points Figure 229 Simplified Schematic of a 3664 or 3674 Digital Output Module with a 9671-610 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 304: Pulse Input Term Panels

    L internal, maximum 0.043 µH Output Connection (I+ and I–) Specifications Maximum output voltage 15 V Maximum output current 0.005 A Maximum output power 0.075 W C external, maximum 20.14 µF L external, maximum Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 305 ** When possible, install a terminating resistor as shown. For further information, see Technical Application Note (TAN) #006, on the IPS Global Client Support Web Site. Figure 230 Field Wiring for 9793-110 with a 3511 PI Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 306 Comparator AC coupled Counter/ Micro- Timer Processor other points Comparator AC coupled Counter/ Micro- Timer Processor other points Figure 231 Simplified Schematic of a 3511 PI Module with a 9793-110 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 307: Rg 1.180 Termination Panels

    RG 1.180 Termination Panels Overview 296 Analog Input Term Panels 297 Analog Output Term Panels 319 Pulse Input Term Panels 323 RTD/TC/AI Input Term Panels 326 Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 308: Overview

    4-20 mA, 0-5 VDC, 16 pts., 48 VDC field 9783-110 0-5 VDC, voltage input, 16 pts. 9782-110 TC input, isolated, 16 pts. Analog Output 9860-610 8 pts. Pulse Input 9794-110 16 pts. RTD/TC/AI 9764-310 RTD/TC/AI input, 16 pts. Input Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 309: Analog Input Term Panels

    1-16 and 17-32. For information on how to apply the labels, see Appendix F, Panel Labels. Specifications This table describes general specifications for 9790-610. Table 188 General Specifications for Term Panel 9790-610 Feature Description Panel type Current input, 4–20 mA Points Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 310 CAUTION modules may be affected by up to –0.08% Full-Scale Range (FSR), at maximum temperature. As a result, the accuracy of these modules is +0.15% to –0.23% FSR, at 140° F (60° C). Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 311 Field Wiring for 9790-610 with a 3700A, 3703E, or 3721 AI Module or 2770H HART AI Interface Module Note For additional instructions on installing HART Interface Modules, see the Planning and Installation Guide for Tricon v9–v10 Systems. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 312 32-POINT ANALOG INPUT MODULES TERMINATION PANEL spare Isolation/filtering 190–310 Ohms Hi-Ref Low-Ref other points 250 Ohms Hi-Ref Low-Ref Hi-Ref Low-Ref Figure 233 Simplified Schematic of a 3700A or 3721 Analog Input Module with a 9790-610 Panel Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 313 CABLE BACKPLANE 16-POINT ANALOG INPUT MODULES spare 190–310 Ohms Hi-Ref Low-Ref other points 250 Ohms Hi-Ref Low-Ref Hi-Ref Low-Ref Figure 234 Simplified Schematic of a 3703E Analog Input Module with a 9790-610 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 314: 9795-610 (4-20 Ma, 0-5 Vdc, 16 Pts.)

    When using 32-point modules, you must use two term panels for each module. Each term panel comes with two sets of labels: 1-16 and 17-32. For information on how to apply the labels, see Appendix F, Panel Labels. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 315 When used with the 9795-610, the accuracy of these modules may be CAUTION affected by up to –0.08% Full-Scale Range (FSR), at maximum temperature. As a result, the accuracy of these modules is +0.15% to –0.23% FSR, at 140° F (60° C). Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 316 This figure illustrates how to connect a 3703E or 3721 analog input module and a 9795-610 to the field (1 of 16 or 32 module points shown). See Appendix E, Shield Ground for shield ground installation guidelines. Figure 236 Field Wiring for 9795-610 with a 3703E or 3721 AI Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 317 32-POINT ANALOG INPUT MODULES TERMINATION PANEL spare Isolation/filtering 190–310 Ohms Hi-Ref Low-Ref other points 250 Ohms Hi-Ref Low-Ref Hi-Ref Low-Ref Figure 237 Simplified Schematic of a 3721 Analog Input Module with a 9795-610 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 318: 9792-610 (4-20 Ma, 0-5 Vdc, 16 Pts., User-Configurable, 48 Vdc Field)

    When using 32-point modules, you must use two term panels for each analog input module. Each term panel comes with two sets of labels: 1-16 and 17-32. For information on how to apply the labels, see Appendix F, Panel Labels. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 319 When used with the 9792-610, the accuracy of these modules may be CAUTION affected by up to -0.08% Full-Scale Range (FSR), at maximum temperature. As a result, the accuracy of these modules is +0.15% to - 0.23% FSR, at 140° F (60° C). Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 320 Typical point (1 of 16 points shown) Power Supply Field Xmtr (4-20 mA) – Power Supply Shield Ground Figure 239 Field Wiring for 9792-610 with a 3700, 3700A, 3703E, or 3721 AI Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 321 The sharing capability of this termination panel should only be used in those applications where these restrictions do not exist, or can be otherwise mitigated. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 322 ** To aid sharing the field transmitter with another system (for example, a DCS), the JP jumper may be removed. Figure 241 Simplified Schematic of a 3700, 3700A, or 3721 AI Module with a 9792-610 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 323: 9783-110 (0-5 Vdc Voltage Input, 16 Pts.)

    When using 32-point modules, you must use two term panels for each module. Each term panel comes with two sets of labels: 1-16 and 17-32. For information on how to apply the labels, see Appendix F, Panel Labels. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 324 0–5 VDC or 0–10 VDC (Use TriStation to configure input range), non- commoned, differential, isolated, TMR 3721 0 to 5 VDC or –5 to +5 VDC (Use TriStation to configure input range), differential, DC-coupled, TMR Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 325 9783-110 to the field (1 of 16 or 32 module points shown). See Appendix E, Shield Ground shield ground installation guidelines. Figure 243 Field Wiring for 9783-110 with a 3700A, 3703E, or 3721 AI Module Unused points must be shorted together. CAUTION Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 326 (1 of 32 module points shown). TERMINATION PANEL CABLE BACKPLANE 32-POINT ANALOG INPUT MODULES spare Isolation/filtering Hi-Ref Low-Ref Hi-Ref Low-Ref Hi-Ref Low-Ref Figure 244 Simplified Schematic of a 3700A or 3721 Analog Input Module with a 9783-110 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 327: 9782-110 (Tc Input, Upscale/Downscale, 16 Pts.)

    • Two, sixteen-position field terminals; support for 16 points • Two terminals per point, for differential analog input (I+, I–) • Two, one-position terminals for protective earth connection • TMR cold-junction temperature sensors • Upscale/downscale open-input bias circuitry Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 328 Module Description Number Module 3708E Type E, J, K, and T, differential, isolated, DC-coupled, TMR, upscale or downscale open-input detection. (Use TriStation to configure the thermocouple type and specify upscale or downscale open-input detection.) Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 329 (1 of 16 module points shown). See Appendix E, Shield Ground for shield ground installation guidelines. Figure 246 Field Wiring for 9782-110 with a 3708E Thermocouple Input Module Unused points must be shorted together. CAUTION Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 330 (1 of 16 module points shown). TERMINATION PANEL CABLE BACKPLANE 16-POINT THERMOCOUPLE INPUT MODULES spare Hi-Ref Low-Ref Hi-Ref Low-Ref Hi-Ref Low-Ref Figure 247 Simplified Schematic of a 3708E Thermocouple Input Module with a 9782-110 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 331: Analog Output Term Panels

    This table describes the analog output module compatible with 9860–610. Table 199 Module Compatible with 9860–610 Module Part Points per Module Description Number Module 2870H HART analog output interface 3805E/H 4–20 mA, commoned-return, DC-coupled, TMR Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 332 Field Wiring for 9860-610 with a 3805E or 3805H AO Module or a 2870H HART AO Interface Module Unused points must be shorted together. CAUTION Note For additional instructions on installing HART Interface Modules, see the Planning and Installation Guide for Tricon v9–v10 Systems. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 333 Selector Logic Current loopback PWRB Selector Logic Current loopback OUT2 Typical point RTN2 Selector Logic Current loopback Figure 249 Simplified Schematic of a 3805E or 3805H Analog Output Module with a 9860-610 Panel Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 334 2071 HART HART MUX MODULE CONTROLLER RS-485 HART CABLE CONTROLLER Figure 250 Simplified Schematic of a 2870H HART AO Interface Module with a 3805E or 3805H AO Module and a 9860-610 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 335: Pulse Input Term Panels

    This table describes pulse input modules compatible with 9794–110. Table 201 Modules Compatible with 9794–110 Module Part Points per Module Description Number Module 20 Hz to 20 kHz pulse input, non-commoned, AC-coupled, 25 ms 3511 typical input update rate Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 336 ** When possible, install a terminating resistor as shown. For further information, see Technical Application Note (TAN) #006, on the IPS Global Client Support Web Site. Figure 251 Field Wiring for 9794-110 with a 3511 PI Module Unused points must be shorted together. CAUTION Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 337 Comparator AC coupled Counter/ Micro- Timer Processor other points Comparator AC coupled Counter/ Micro- Timer Processor other points Figure 252 Simplified Schematic of a 3511 PI Module with a 9794-110 Panel Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 338: Rtd/Tc/Ai Input Term Panels

    Termination panel 9764-310 can be used in applications that are required to meet RG 1.180 guidelines. For more information, including a description, specifications, compatible modules, field wiring diagrams, and simplified schematics, see 9764-310 (RTD/TC/AI input, 0–5 VDC, 16 pts.) on page 218. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 339: Chapter 8 Fanned-Out Cables

    Fanned-Out Cables Overview 328 Description of Fanned-Out Cables (9101-010) 328 Fanned-Out Cables with Digital Input Modules 329 Fanned-Out Cables with Digital Output Modules 335 Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 340: Overview

    Connectors. Fanned-out cables should only be used with digital input and digital output modules. They are not certified for use with analog signals. Contact the Triconex Customer Support Center if you need a fanned-out cable for handling analog signals. The part number for a fanned-out cable is 9101-010. The last two digits of the part number represent the standard cable length of 10 feet (3 meters).

  • Page 341: Fanned-Out Cables With Digital Input Modules

    3502E 48 VAC/VDC, commoned in groups of 8, TMR with self-test 3503E 24 VAC/VDC, commoned in groups of 8, TMR with self-test 3505E 24 VAC/VDC, low-threshold, commoned in groups of 8, TMR.with self-test Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 342 Field Wiring for 9101-010 with a 3501E, 3501T, 3502E, 3503E, or 3505E Module Note You must re-key the female connector to match its corresponding male connector on the Tricon chassis. For instructions on re-keying connectors, see Appendix A, Re-Keying Connectors. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 343 Input Opto-Isolator Mux A Threshold Input Detect Opto-Isolator Mux B Threshold Input Detect spare Opto-Isolator Mux C module Figure 254 Simplified Schematic of a 3501E or 3501T DI Module with a Fanned-Out Cable Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 344 Detect Input Opto-Isolator Mux B Test B Threshold Detect Input Opto-Isolator Mux C spare module Test C Figure 255 Simplified Schematic of a 3502E, 3503E, or 3505E DI Module with a Fanned-Out Cable Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 345: Connecting 64-Point Digital Input Modules To Fanned-Out Cables

    Field Wiring for 9101-010 with a 3564 Module Note You must re-key the female connector to match its corresponding male connector on the Tricon chassis. For instructions on re-keying connectors, see Appendix A, Re-Keying Connectors. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 346 Two cables are required for 64 points. Only one RTN connection is required for proper operation of a 64-point digital input module. Figure 257 Simplified Schematic of a 3564 DI Module with a Fanned-Out Cable Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 347: Fanned-Out Cables With Digital Output Modules

    You must re-key the female connector on each fanned-out cable to match the corresponding male connector on the Tricon backplane. Male connectors are mounted on the backplane directly above their respective I/O slots. For instructions on re-keying connectors, see Appendix A, Re-Keying Connectors. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 348 To prevent missing-load alarm, install a load at each unused point. Figure 258 Field Wiring for 9101-010 with a 3601E, 3603E, 3604E, 3607E, or 3623 Module For proper operation, one PWR connection per point is required. CAUTION Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 349 For proper operation, one RTN connection and one PWR connection per CAUTION point are required. Note You must re-key the female connector to match its corresponding male connector on the Tricon chassis. For instructions on re-keying connectors, see Appendix A, Re-Keying Connectors. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 350 Switch RTN1 (2E) Drive Circuitry to other points Output Switch Drive Circuitry Output Switch Drive spare Voltage Circuitry Loopback Detector Figure 260 Simplified Schematic of a 3603E DO Module with a Fanned-Out Cable Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 351 Switch RTN1 (2E) Drive Circuitry Output Switch Drive Circuitry Output Switch Drive spare Voltage Circuitry Loopback Detector Figure 261 Simplified Schematic of a 3601E, 3604E, or 3607E DO Module with a Fanned-Out Cable Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 352 RTN1 (2E) Drive Circuitry Output to other Switch points Drive Circuitry Output Switch Drive spare Voltage Circuitry Loopback Detector Figure 262 Simplified Schematic of a 3623 or 3624 DO Module with a Fanned-Out Cable Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 353: Connecting 32-Point Digital Output Modules To Fanned-Out Cables

    To prevent missing-load alarm, install a load at each unused point. If a field load is not available, install a 470-Ohm, 10-W resistor. One RTN connection per point is required. Figure 263 Field Wiring for 9101-010 with a 3625 Module Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 354 Field Wiring for 9101-010 with a 3664 or 3674 Module Note You must re-key the female connector to match its corresponding male connector on the Tricon chassis. For instructions on re-keying connectors, see Appendix A, Re-Keying Connectors. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 355 Output Drive Circuitry LOAD1 (2C) RTN1 (2E) Voted Drive Output Circuitry Loopback Detector/ Isolator spare to other points Figure 266 Simplified Schematic of a 3664 or 3674 DO Module with a Fanned-Out Cable Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 356: Connecting 32-Point Relay Output Modules To Fanned-Out Cables

    You must re-key the female connector on each fanned-out cable to match the corresponding male connector on the Tricon backplane. Male connectors are mounted on the backplane directly above their respective I/O slots. For instructions on re-keying connectors, see Appendix A, Re-Keying Connectors. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 357 Point Register 2A (C1) Voted Output Drive Point Circuitry Register Loopback Detector/ Isolator 2E (C1) Point Register Figure 268 Simplified Schematic of a 3636R or 3636T Relay Output Module with a Fanned-Out Cable Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 358 346 Chapter 8 Fanned-Out Cables Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 359: Appendix A Re-Keying Connectors

    Re-Keying Connectors Re-Configuring a System 348 I/O Connector Key Positions 349 Re-Keying a Connector 353 Re-Keying a Fanned-Out Cable 354 Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 360: Re-Configuring A System

    2 Re-key the female connector on the cable to match the backplane connector. All unused slots are delivered from the factory keyed Small=1, Large=1. 3 Mark cable as being modified. 4 Install new or replacement termination assembly. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 361: I/O Connector Key Positions

    9563-810 24 VAC/VDC 3503E 3505E 9565-810 48 VDC 3504E 9566-710 24 VDC 3564 9566-810 24 VDC 3504E 9141-010 115 VA /120 VDC 9670-110 9670-610 9673-810 9142-010 48 VDC 9672-810 9143-010 24 VDC 9671-810 Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 362 Regarding termination panel 9251-210: for the termination panel and the end of the cable that connects to the termination panel, the keying is Large=1, Small=1. For the chassis and the end of the cable that connects to the chassis, the keying is Large =1, Small=3. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 363 4–20 mA (10 VDC) 3703E 9763-810 0–5/0–10 VDC 3703E 9765-610 Thermocouple 3708E 9766-210 Thermocouple 3706A 9766-510 Thermocouple 3706A 9760-210 4–20 mA (5 VDC) 3704E 9760-410 4–20 mA (10 VDC) 3704E 9765-210 4–20 mA (5 VDC) 3704E Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 364 1. Small key is “1” at term panel end of cable. Table 214 Bypass Panel Key Positions Termination Small Large Rating Module panel BP9228-010 Bypass 3503E 3505E Table 215 RTD Panel Key Positions Termination Small Large Rating Module panel 9764-310 3700 3700A Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 365: Re-Keying A Connector

    This procedure explains how to re-key a connector on the Tricon backplane. If a Tricon system includes 115V modules, a high-voltage potential exists CAUTION on the backplane. To avoid shorts that could lead to damage, Triconex recommends removing all power from the Tricon system before you re- key the backplane connectors.

  • Page 366: Re-Keying A Fanned-Out Cable

    10 Replace the female connector in its housing by lining up the thumbscrew with the opening in the top of the housing. 11 Replace the four screws that secure the female connector to the housing. 12 Tighten the two screws that secure the housing to the cable. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 367: Appendix B Fanned-Out Cable Pinouts

    Fanned-Out Cable Pinouts Signal Names 356 Connector #1 357 Connector #2 359 Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 368: Signal Names

    I/O RX I/O RX I/O RX I/O TX I/O TX I/O TX EICM POWER MODULE DIGITAL DIGITAL DIGITAL DIGITAL 3006 3006 3006 4329 OUTPUT OUTPUT 4119 MODEL 8310 INPUT INPUT 3501E 3501E 3603B 3603B Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 369: Connector #1

    PWR8 PWR8 IN8+ OUT8 IN8+ LOAD8 LOAD8 IN16 IN16 IN8– RTN8 IN8– RTN8 IN8– IN17 IN17 IN9+ PWR9 SEC1 IN9+ LOAD9 IN18 IN18 IN9– RTN9 IN9– IN19 IN19 IN10+ PWR10 SEC2 IN10+ LOAD10 Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 370 Reserved for Tricon internal use. Do not connect for any purpose. Note CGND is the Tricon chassis ground (protective earth). Pins r, s, X and Y on the panel connector are not used. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 371: Connector #2

    RTN22 IN45 IN45 IN23+ PWR23 LOAD23 IN46 IN46 IN23– RTN23 IN47 IN47 IN24+ PWR24 LOAD24 IN48 IN48 IN24– RTN24 IN49 IN49 IN25+ PWR25 LOAD25 IN50 IN50 IN25– RTN25 IN51 IN51 IN26+ PWR26 LOAD26 Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 372 CGND CGND CGND CGND CGND CGND CGND CGND CGND CGND CGND Note CGND is the Tricon chassis ground (protective earth). Pins r, s, X and Y on the panel connector are not used. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 373: Appendix C Recommended Replacement Parts

    2-amp fast-acting fuse, 235002 Littlefuse Relay output 5 mm x 20 mm termination GMA-2A Bussman 1410009-001 panels 5MF2 Bel Fuse 2-amp fuse, 312002 Littlefuse Bypass panel 1410020-001 1/4 in x 1-1/4 in 3AG2 Bel Fuse Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 374 PW-10-120-10 IRC, RCD 1100282-001 termination SQP-10-120-10 panels I-to-V Resistor, 250 ohm, S102C 250 .010% Vishay V9 analog 0.6 W, 0.01% termination PF2260H 250 ohm Riedon panels .01% 1100375-001 WAC250R00T Wilbrecht Electronics Inc. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 375 2000236-001 Triconex 2000236-001 56-pin connectors on termination cables, panels, backplane and main chassis Spring-loaded terminal, 18 73 34 6 Phoenix 1420045-016 All applicable V9 16-position termination panels except basic, bypass, and interposing relay Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 376 ELCO These gaskets must be connectors used replaced before the end in hazardous of their 5-year lifespan. locations (those requiring nonincendive circuits). Key for blank logical slot 2000508-001 Triconex 2000508-001 All chassis Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 377: Appendix D Panel Dimensions

    Panel Dimensions This figure illustrates the dimensions described in Table 220 Panel Dimensions (page 366). Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 378 5 in (12.7 cm) 4.25 in (10.795 cm) 9662-710 4.5 in (11.43 cm) 5 in (12.7 cm) 4.25 in (10.795 cm) 9662-810 4.5 in (11.43 cm) 5 in (12.7 cm) 4.25 in (10.795 cm) Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 379 10 in (25.4 cm) 4.25 in (10.795 cm) 9765-610 4.5 in (11.43 cm) 5 in (12.7 cm) 4.25 in (10.795 cm) 9766-210 4.5 in (11.43 cm) 5 in (12.7 cm) 4.25 in (10.795 cm) Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 380 5 in (12.7 cm) 4.25 in (10.795 cm) BP9228-010 3.5 in (8.89 cm) 19 in (48.26 cm) 8 in (20.32 cm) BP9229-010 3.5 in (8.89 cm) 19 in (48.26 cm) 8 in (20.32 cm) Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 381: Appendix E Shield Ground

    ZRSG Ref. # Type Description Phoenix Order # NLS-MS 3/10 Neutral busbar 04 04 18 5 AB/SS Support 04 04 42 8 AKG 4 Black N/PE terminal block 04 21 03 2 Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 382 370 Appendix E Shield Ground Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 383: Appendix F Panel Labels

    Panel Labels 16-Point Non-Commoned DI/DO/RO Panels 373 16-Point Non-Commoned AI/TI Panels 374 16-Point Commoned AI/DI/DO Panels 375 32-Point Commoned AI/DI Panels 376 16-Point Commoned AI ATEX/RG 1.180 Panels 377 16-Point RTD/TC/AI Panels 378 Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 384: Overview

    Any unused labels can be stored or discarded. Attach the appropriate labels to each panel as shown in these illustrations. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 385: 16-Point Non-Commoned Di/Do/Ro Panels

    Labels (for front and back row) Labels (for front and back row) – – – – – – – – – – – – – – – – Second Panel Figure 269 16-Point Non-Commoned DI/DO/RO Panel Label Placement Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 386: 16-Point Non-Commoned Ai/Ti Panels

    First Panel Labels (for front and back row) 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 Second Panel Figure 270 16-Point Non-Commoned AI/TI Panel Label Placement Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 387: 16-Point Commoned Ai/Di/Do Panels

    First Panel Labels (for front and back row) 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 Second Panel Figure 271 16-Point Commoned AI/DI/DO Panel Label Placement Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 388: 32-Point Commoned Ai/Di Panels

    33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 Second Panel Figure 272 32-Point Commoned AI/DI Panel Label Placement Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 389: 16-Point Commoned Ai Atex/Rg 1.180 Panels

    Labels (for front and back row) 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 Second Panel Figure 273 16-Point Commoned AI ATEX/RG 1.180 Label Placement Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 390: 16-Point Rtd/Tc/Ai Panels

    17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 Figure 274 16-Point RTD/TC/AI Panel Label Placement Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 391: Appendix G Part Number Cross-Reference

    9566-710 3000530-380 4000093-310 9566-810 3000540-380 4000093-310 9567-810 3000530-180 4000093-110 9570-610 3000768-370 4000165-310 9571-610 3000768-390 4000165-310 9572-610 3000771-380 4000165-310 9651-110 3000410-160 4000094-110 9652-610 3000410-260 4000094-210 9653-610 3000410-360 4000094-310 9661-110 3000570-110 4000094-110 9661-510 3000550-160 4000094-110 Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 392 9671-810 3000290-380 4000111-310 9672-810 3000290-280 4000111-210 9673-810 3000290-181 4000111-110 9750-210 3000420-120 4000093-510 9750-310 3000420-310 4000093-310 9750-410 3000420-410 4000093-210 9750-810 3000420-180 4000093-510 9753-110 3000400-510 4000103-510 9760-210 3000470-510 4000093-510 9760-410 3000470-530 4000093-510 9761-210 3000510-510 4000103-510 Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 393 3000771-560 4000142-510 9791-610 3000771-510 4000164-510 9792-610 3000772-660 4000103-510 9793-110 3000767-115 4000164-510 9794-110 3000767-165 4000142-510 9795-610 3000771-460 4000142-510 9853-610 3000400-530 4000098-510 9860-610 3000770-610 4000157-510 9861-610 3000770-560 4000163-510 1600049-010 9863-710 4000098-510 1600049-100 9871-810 3000818-560 4000163-510 Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 394 382 Appendix G Part Number Cross-Reference Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 395: Appendix H Minimum Bend Radiuses Of Cables

    2.125 in (5.3975 cm) 4000042-xxx 5.6 in (14.224 cm) 4000043-1xx 4.6 in (11.684 cm) 4000050-00x 3.25 in (8.255 cm) 4000052-006 2.5 in (6.35 cm) 4000054-x10 4.6 in (11.684 cm) 4000055-x10 5.6 in (14.224 cm) Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 396 2.125 in (5.3975 cm) 4000091-0xx 2.125 in (5.3975 cm) 4000092-x10 5.6 in (14.224 cm) 4000093-x10 5.6 in (14.224 cm) 4000094-x10 5.6 in (14.224 cm) 4000096-x01 3.5 in (8.89 cm) 4000098-510 6.25 in (15.875 cm) Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 397 6.6 in (16.764 cm) 4000141-x10 6.6 in (16.764 cm) 4000142-x10 8.1 in (20.574 cm) 4000143-x10 5.5 in (13.97 cm) 4000144-x10 6.6 in (16.764 cm) 4000147-510 7.4 in (18.796 cm) 4000150-510 7.4 in (18.796 cm) Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 398 6.25 in (15.875 cm) 4000183-5xx 5 in (12.7 cm) 4000184-5xx 5.5 in (13.97 cm) 4000185-3xx 5 in (12.7 cm) 4000186-3xx 5 in (12.7 cm) 4100002-001 3.5 in (8.89 cm) 4100005-xx0 2 in (5.08 cm) Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 399: Appendix I Low-Density Chassis I/O Module Compatibility

    Low-Density Chassis I/O Module Compatibility Overview 388 Module Upgrades 388 ETP Upgrades for Compatibility with I/O Modules 389 Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 400: Overview

    32 points 32 points 3704E 3720 64 points 64 points 3604E 3625 16 points 32 points 3614E 3625 8 points 32 points 3615E 3625 8 points 32 points 3624 3625 16 points 32 points Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 401: Etp Upgrades For Compatibility With I/O Modules

    3604E DO Module ETP Upgrade on page 392 • 3614E DO Module ETP Upgrade on page 394 • 3615E DO Module ETP Upgrade on page 396 • 3624 DO Module ETP Upgrade on page 398 Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 402: 3700 And 3700A Ai Module Etp Upgrade

    1 x 3000280-500 (interface module) user configurable, 2 x 3000656-210 (ETP) 32 pts. 9764-310 RTD/TC/AI, 9764-310L 2 x 4000182-510 (cable) 0–5 VDC, 1 x 3000280-500 (interface module) -5–5 VDC, 16 pts. 2 x 3000712-200 (ETP) Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 403: 3704E Ai Module Etp Upgrade

    0–5 VDC, 32 pts. 1 x 3000280-500 (interface module) 2 x 3000470-510 (ETP) 9760-410 Current input, 9760-410L 2 x 4000183-510 (cable) 0–10 VDC, 32 pts. 1 x 3000280-500 (interface module) 2 x 3000470-530 (ETP) Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 404: 3604E Do Module Etp Upgrade

    When you use the supervisory function of the Model 3625 DO Module CAUTION with the 9671-810L or the 2661-110L ETPs, only the ELCO termination cable and the relay coil will be monitored for field fault detection. Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 405 When you use the supervisory function of the Model 3625 DO Module CAUTION with the 9671-810 or the 9671-810L ETPs, only the ELCO termination cable and the relay coil will be monitored for field fault detection. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 406: 3614E Do Module Etp Upgrade

    1 x 3000280-300 (interface module) eight-point ETP 3 x 3000120-390 (ETP) 2652-910L4 2 x 4000174-310 (cable) Use this kit if you have no 1 x 3000280-300 (interface module) eight-point ETPs 4 x 3000120-390 (ETP) Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 407 A load must be installed at every point to prevent missing-load alarm. If a field load is not available, configure each unused point as non-supervised and install a 470 ohm, 10 W load resistor. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 408: 3615E Do Module Etp Upgrade

    1 x 3000280-300 (interface module) eight-point ETP 3 x 3000120-395 (ETP) 2652-95L4 2 x 4000174-310 (cable) Use this kit if you have no 1 x 3000280-300 (interface module) eight-point ETPs 4 x 3000120-395 (ETP) Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 409 A load must be installed at every point to prevent missing-load alarm. If a field load is not available, configure each unused point as non-supervised and install a 470 ohm, 10 W load resistor. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 410: 3624 Do Module Etp Upgrade

    A load must be installed at every point to prevent missing-load alarm. If a field load is not available, configure each unused point as non-supervised and install a 470 ohm, 10 W load resistor. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 411: Appendix J Using V8 Etas With V9/V10 Systems

    4000104-2xx, 3000110-260 48 VAC/VDC, 2 required per Commoned 2552-8 Digital Input, 3502E 4000104-2xx, 3000110-280 48 VAC/VDC, 2 required per Commoned, Redundant 2553-6 Digital Input, 24 VDC, 3503E 4000104-3xx, 3000110-360 Commoned 2 required per Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 412 3000120-380 24 VDC, Commoned, Redundant 2657-1 Digital Output, 3607E 4000115-2xx 3000120-210 48 VDC, Non-commoned 2657-6 Digital Output, 3607E 4000115-2xx 3000120-260 48 VDC, Commoned 2657-8 Digital Output, 3607E 4000115-2xx 3000120-280 48 VDC, Commoned, Redundant Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 413 Relay Output, 3636R 4000117-1xx, 3000250-060 Commoned 2 required per 2658-8 Relay Output, 3636R 4000117-1xx, 3000250-080 Commoned, 2 required per Redundant Analog Input 2750-2 AI, 0–20 ma/5 V 3700 4000118-5xx, 3000142-220 3700A 2 required per Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 414 0–5/0–10 VDC 2 required per 2756-2 Non-Isolated, 3706A 4000118-5xx, 3000142-900 Thermocouple Input (upscale) 2 required per 2756-5 (downscale) 2755-6 Isolated, 3708E 4000118-5xx 3000142-600 Thermocouple Input Analog Output 2852-1 Analog Output 3805E/H 4000116-5xx 3000259-100 Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 415: Appendix K Warning Labels

    Warning Labels Overview 404 General Hazard 405 Hazardous Voltage 406 Hot Surface 407 Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 416: Overview

    Labels must meet the requirements of ANSI Z535, ISO 3864, and IEC 1310-1. Labels are available from Triconex upon request. Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 417: General Hazard

    Black border Black letters on 30 mm 1.2 inch 0.06 x base width white background minimum Sans serif font Upper or lower case 2.54 mm ( 0.10 inch) high Figure 275 General Hazard Label Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 418: Hazardous Voltage

    Black border Black letters on 30 mm 1.2 inch 0.06 x base width white background minimum Sans serif font Upper or lower case 2.54 mm ( 0.10 inch) high Figure 276 Hazardous Voltage Label Field Terminations Guide for Tricon v9–v10 Systems...

  • Page 419: Hot Surface

    Black border Black letters on 30 mm 1.2 inch 0.06 x base width white background minimum Sans serif font Upper or lower case 2.54 mm ( 0.10 inch) high Figure 277 Hot Surface Label Field Terminations Guide for Tricon v9–v10 Systems...
  • Page 420 408 Appendix K Warning Labels Field Terminations Guide for Tricon v9–v10 Systems...

This manual is also suitable for:

Tricon v10

Table of Contents

Save PDF
