- Page 1 TMCZ 105 F MOBILE TYPE AIR CONDITIONER WITH OZONE-FRIENDLY R410A REFRIGERANT USER’S MANUAL ErP Model WARNING! PLEASE READ CAREFULLY THIS MANUAL BEFORE OPERATING YOUR NEW AIR CONDITIONER. - 1 -...
-
Page 3: Table Of Contents
Table of Contents GENERAL INFORMATION ...................... 4 SAFETY PRECAUTIONS ......................6 NAME OF THE COMPONENTS ....................9 OPERATING PANEL ......................10 IR REMOTE CONTROL ......................13 COOLING MODE ........................14 HEATING EFFECT ......................... 16 DEHUMIDIFY MODE ......................18 CLEANING & MAINTENANCE OF AIR CONDITIONER ............19 TROUBLESHOOTING ...................... -
Page 4: General Information
GENERAL INFORMATION INTRODUCTION / TECHNICAL DATA Congratulations for purchasing new Mobile type Air Conditioner TMCZ 105 F. Your Mobile type Air Conditioner has been developed and manufactured in accordance with standards of the state of the art technology. Three operating modes are available: Cooling, Deumidify and Heating. - Page 5 The colour of the Unit can change slightly due to direct solar radiation. The Mobile Air Conditioner TMCZ 105 F is equipped with a special thermal deactivation. This protects the Unit from overheating in extreme ambient conditions.
-
Page 6: Safety Precautions
SAFETY PRECAUTIONS • To take best advantage from your new air conditioner and for correct operation, please read carefully this Manual. • Hazard and safety levels are shown via warning and alert signs as listed below. May result in life-threatening danger or severe injury if Warning operated incorrectly. - Page 7 SAFETY PRECAUTUIONS Caution • N e v e r b l o c k t h e • The air conditioner blowout vent or intake is designed for indoor use; exposure to direct vent with clothing or sunlight or rain may rags.
- Page 8 SAFETY PRECAUTIONS Warning • Keep the power plug • Never turn on and off clean from dust and the air conditioner by plugging and unplugging make sure it is securely the power tap from the inserted into the wall wall receptacle. receptacle.
-
Page 9: Name Of The Components
NAME OF THE COMPONENTS OUTLINE OF MOBILE AIR CONDITIONER TMCZ 105 F 1. Operating panel 2. Control lamp 3. Air outlet grid 4. Air hose connection piece 5. Air hose 6. Upper condensation water outlet with rubber plug 7. Carrier handles 8. -
Page 10: Operating Panel
OPERATING PANEL DESCRIPTION OF FUNCTIONS [POWER] Press this button to switch on/off the Unit. [FUNC] Press this button to select the functions “Cooling” , “Heating” or “Dehumidify”. [TEMP+] In “Cooling” mode, every time the button is pressed, temperature rises by 1°C, up to a maximum value of 30°C. - Page 11 [TIMER] Button for selecting programmable automatic start/stop of Mobile Air Conditioner TMCZ 105 F. Time interval for automatic start: This function is used for automatic start of Unit at the end of set time interval. Proceed in the following way: i) When Unit is powered but not in operation, press [TIMER] button twice to select time interval (number of hours) at the end of which Unit will automatically start operation.
- Page 12 OPERATING PANEL [SLEEP] Press this button to select “Sleep” function. The microprocessor integrated in the Unit will raise the pre-set temperature by 2°C per hour up to a maximum of 4°C after 2 hours. Then temperature will be kept steady up to the end of set time interval.
-
Page 13: Ir Remote Control
IR REMOTE CONTROL [POWER] Press this button to start/stop the Unit. 2. [FUNC] Press this button to select the functions “Cooling”, “Heating” or “Dehumidify”. 3. [TIMER] For programming automatic start/stop of the Air Conditioner. 4. [AUTO] Automatic fan speed. 5. [HI] High fan speed. -
Page 14: Cooling Mode
COOLING MODE COOLING MODE • In the summertime, it is recommended to start the Unit early on hot days, thus avoiding heating up of the room. • This Unit has a self-evaporating function for condensation water, so that it is normally not necessary to empty the water tank in “Cooling”... - Page 15 COOLING MODE COOLING IN OUTDOOR OPERATION The Unit is outside the room to be cooled. Connect the air hose and the air outlet grid to the Unit as displayed in the illustration; the air hose connection piece and air outlet grid need to be exchanged according to the position of the Unit (indoor operation or outdoor operation).
-
Page 16: Heating Effect
HEATING EFFECT HEATING EFFECT • In the wintertime, on cold days, it is recommended to start the Unit early in order to avoid intensive cooling of the room. • For the heating function, to improve the heating effect and avoid lower temperatures (lower than 17°C), we recommend you to remove the rubber cap from the upper water condensation outlet, thus allowing the condensation water to leak out of the Unit through the drainage hose. - Page 17 HEATING EFFECT Select “HEATING” function (“Heating effect”). Select your desired temperature: the settable temperature range is between 15°C and 25°C. Note: After starting the Unit, or after switching over from a mode to another mode, the fan operates, but compressor Further information are available in the Chapter “Troubleshooting”.
-
Page 18: Dehumidify Mode
DEHUMIDIFY MODE DEHUMIDIFY MODE Humidity is extracted from the air, collected in the water tank and discharged through the condensation water outlet. Only air the room if the humidity of the outside air is lower than humidity inside the room. Select “DEHUMIDIFY”... -
Page 19: Cleaning & Maintenance Of Air Conditioner
CLEANING & MAINTENANCE OF AIR CONDITIONER MAINTENANCE Before performing any maintenance operation, check that the power plug is disconnected from the wall power socket. Please follow the instructions below: 1. Cleaning the outside of the air conditioner Clean the outside of the Unit by using a dry soft cloth. Do not use any solvent, by-products of oil, abrasive powders or chemical products in general in order to avoid damaging the plastic external surfaces. -
Page 20: Troubleshooting
ERROR MESSAGES Caution! Mobile type Air Conditioner TMCZ 105 F is equipped with a 3-minutes compressor-delay system which means the compressor needs 3 minutes to start. Consequently, when Unit is started (POWER button), or in case of switching over from one function to another one (e.g. - Page 21 TROUBLESHOOTING ERROR/ CAUSE SUGGESTED REMEDY PROBLEM You can achieve the most effective and economical cooling comfort if room has not yet been heated up. Air Conditioner operates Unit does not cool correctly. more effectively if room temperature has not raised and has been kept steady. To drastically cool the air in a very hot room requires much more time and energy.
- Page 22 NOTES...
- Page 23 NOTES...
- Page 24 TERMAL Srl 14, Via della Salute 40132 Bologna - Italy Tel. +39.051.41.33.111 Fax +39.051.41.33.112 www.termalgroup.com Due to on-going technological development of the Products by the Manufacturer, we...
