AquaScape 84031 Installation Instructions Manual

I N S T A L L A T I O N
GARDEN AND POND
LED LIGHTS
Aquascape Garden and Pond LED Lights are developed to provide
impressive lighting options for ponds, waterfalls, and landscapes. This
instruction manual will guide you through the proper installation of
Aquascape Garden and Pond Lights as well as recommended maintenance
procedures to ensure long-term effectiveness.
Garden and Pond 1-Watt LED Spotlight
Item #84031
Garden and Pond 1-Watt LED Waterfall
and Up Light
Item #84032
Garden and Pond 3-Watt Garden and Pond 3-Watt
LED Spotlight
Item #84033
Garden and Pond 6-Watt Garden and Pond 6-Watt
LED Spotlight
Item #84034
5
TABLE OF CONTENTS
Introduction ................................................... 1
Contents ...................................................... 1
Required Products .......................................... 1
Recommended Products .................................... 1
Safety Information ............................................. 1
Specifi cations Chart ....................................... 2
Installation ................................................... 2-3
General Maintenance ....................................... 3
Troubleshooting ................................................ 3
Replacement Parts .......................................... 3
Warranty Information ....................................... 3
Contact Us
For more information about our company or products,
please visit our website at aquascapeinc.com or call
US (866) 877-6637 CAN (866) 766-3426.
US (866) 877-6637 | CAN (866) 766-3426 | aquascapeinc.com
I N S T R U C T I O N S
Contents - #84032
No. Description
1. Waterfall and Up Light
2. Removable Stand
Contents - #84031, #84033, and #84034
No. Description
1. Spotlight
2. Removable Stand
3. Landscape Stake
Required Products
12-Volt Transformer
2 1
Recommended Products
B B
A A
Garden and Pond 3-Way
2 1
Quick-Connect Splitter
(#98489)
2 1
B B
A A
Garden and Pond 25'
2 1
Quick-Connect Lighting
Extension Cable 2
(#98998)
B
A
Garden and Pond Photocell
REV DESCRIPTION NAME DATE
1
INITIAL RELEASE EAK 1/15/19
with Digital Timer
2
Safety Information
WARNING: It is
recommended whenever
working in or near water to
have all electrical devices plugged
into a ground fault interrupter (GFCI)
that has been installed by a licensed
electrician.
• To reduce the risk of electrical shock
or damage to the light, all wiring and
junction connections should be made
per local codes. Requirements may vary
depending on usage and location.
Find us on:
1
2
2 1
B
Garden and Pond 6-Way
A
Quick-Connect Splitter
(#84022)
2 1
2 1
B
A
Garden and Pond 25'
2 1
5-Outlet Quick-Connect Lighting
1 Extension Cable
NOTE: TITLE BLOCK TOLERANCE
NOT APPLICABLE
(#84023)
B
A
PROPRIETARY AND CONFIDENTIAL UNLESS OTHERWISE SPECIFIED: CREATED BY EAK CREATED DATE 1/15/19 TITLE:
THE INFORMATION CONTAINED IN DIMENSIONS ARE IN INCHES PHOTOCELL W/ DIGITAL TIMER
CHECKED BY CHECKED DATE
THIS DRAWING IS THE SOLE TOLERANCES:
PROPERTY OF AQUASCAPE INC. FRACTIONAL 1/16 DWG. NO.
ANY REPRODUCTION IN PART OR
ANGULAR: MACH 5 BEND 5 84039-LI-AP-MD-1
AS A WHOLE WITHOUT THE WRITTEN TWO PLACE DECIMAL .010
PERMISSION OF AQUASCAPE INC IS
PROHIBITED. THREE PLACE DECIMAL .005 SCALE: 1:4 SIZE A SHEET 1 OF 1
INTERPRET GEOMETRIC TOLERANCING PER: ANSI
1
(#84039)
• The power cable should be protected
at all times to avoid punctures, cuts,
bruises, and abrasion.
• Operating the light fi xture outside of
the 9-15 volt operating range voids the
product warranty and may damage or
shorten the life of the LEDs.
IMPORTANT: Aquascape,
Inc. is not responsible for
losses, injury, or death
resulting from a failure to observe
these safety precautions, misuse or
abuse of pumps or equipment.
facebook.com/AquascapeInc
youtube.com/aquascape4
twitter.com/AquascapeInc
