OWNER'S MANUAL
SUBMERSIBLE SOLIDS HANDLING PUMPS
SWW05002VPK
Questions, problems, missing parts? Before returning to the store call K2 Customer
SWW05002TPK
SWW05001VPK
SWW07501VPK
Service 8 a.m. - 6 p.m., EST, Monday-Friday
1-844-242-2475
Model:
SWW05002TPK/SWW05002VPK
SWW07503TPK
SWW05001TPK/SWW05001VPK
SWW07501TPK/SWW07501VPK
SWW07503TPK
SWW05001TPK
SWW07501TPK
© 2019 Copyright GP Enterprises Co., Ltd.
Rev. 11/4/19
Advertisement
Table of Contents
Related Manuals for K2 PUMPS SWW05002TPK
Summary of Contents for K2 PUMPS SWW05002TPK
- Page 1 SUBMERSIBLE SOLIDS HANDLING PUMPS SWW05002VPK SWW07503TPK SWW05002TPK SWW05001VPK SWW05001TPK SWW07501VPK SWW07501TPK Questions, problems, missing parts? Before returning to the store call K2 Customer Service 8 a.m. - 6 p.m., EST, Monday-Friday 1-844-242-2475 © 2019 Copyright GP Enterprises Co., Ltd. Rev. 11/4/19...
-
Page 2: Safety Instruction
PERFORMANCE GPH of Water @ Total Feet Of Lift Max. Lift 0 ft. 5 ft. 10 ft. 15 ft. 20 ft. 25 ft. SWW05002TPK 6500 5000 4200 2400 18 ft. SWW05002VPK SWW07503TPK 8700 7500 6000 3900 20 ft. SWW05001TPK 9000 7320 5400 2700... -
Page 3: Pre-Installation
17. Follow all local electrical and safety codes, along with the National Electrical Code (NEC). In addition, all Occupational Safety and Health Administration (OSHA) guidelines must be followed. 18. The motor of this pump has a thermal protector that will trip if the motor becomes too hot. The protector will reset itself once the motor cools down and an acceptable temperature has been reached. -
Page 4: Installation
SPECIFICATIONS SWW05002TPK/ SWW05002VPK:115V, 60 HZ., 15 Amp Circuit Power supply SWW07503TPK/SWW05001TPK/SWW05001VPK/SWW07501TPK/SWW07501VPK: 115V, 60 HZ., 20 Amp Circuit Liquid temp. range 32-131° F (0-55° C) 2” FNPT Discharge size Sump basin Minimum 22 in. (559 mm) diameter, 30 in. (760 mm) depth NOTICE: Read this Owner’s Manual for installation, operation, and safety information. - Page 5 For SWW05002TPK/ SWW05002VPK /SWW07503TPK/SWW05001TPK/SWW07501TPK installation SWW05002TPK/SWW07503TPK/ SWW05002VPK SWW05001TPK/SWW07501TPK For SWW05001VPK/SWW07501VPK installation Fasten the bracket onto the switch with two screws. 2. Attach the bracket and switch to the discharge pipe with clamp (included), being sure to keep the vertical switch vertical.
-
Page 6: Operation
4. DO NOT handle or service pump while it is connected to power supply. 5. DO NOT remove grounding prong from plug or modify plug to protect against electrical shock, the power cord is a three-wire conductor and includes a 3-prong grounded plug. Plug pump into a 3-wire, grounded, grounding type receptacle. -
Page 7: Care And Cleaning
CARE AND CLEANING CAUTION: Always use the handle to lift the pump. Never use the power cord to lift the pump. To avoid skin burns, unplug the pump and allow time for it to cool after periods of extended use. Do Not When the power is disconnected, inspect the Do not disassemble the motor housing. -
Page 8: Troubleshooting
For SWW07503TPK Before removing pump from basin for service, always disconnect electrical power to pump and control switch. Submerge pump in a disinfectant solution (bleach) for at least one hour before disassembling pump. Put the pump upside down. ... - Page 9 (the “Warranty Period”). During the Warranty Period, K2 will repair or replace at no cost to you, to correct any such defect in products founds upon examination by K2 to be defective in materials or workmanship.
