Inbody 570 Raspberry Pi Setup Instructions
STEP 1: Please check that you've received all of the following.
STEP 2: Connect USB to Null Modem Adapter
to Gender Changer as shown
STEP 3: Connect USB-Serial Cable to USB Port of
Raspberry Pi (as seen here).
EFFORT REWARDED.
1
Raspberry Pi
3
USB to Null
Modem Adapter
2
Power Adaptor
4
Gender Changer
myzone.org | 1
Advertisement
Table of Contents
Summary of Contents for Myzone Inbody 570
- Page 1 EFFORT REWARDED. Inbody 570 Raspberry Pi Setup Instructions STEP 1: Please check that you’ve received all of the following. Raspberry Pi Power Adaptor USB to Null Gender Changer Modem Adapter STEP 2: Connect USB to Null Modem Adapter to Gender Changer as shown STEP 3: Connect USB-Serial Cable to USB Port of Raspberry Pi (as seen here).
- Page 2 | Inbody 570 Raspberry Pi Setup Instructions STEP 4: Connect other end of connected cable run (Gender Changer) to port on back of scales. STEP 5: Connect network cable to Raspberry Pi. STEP 6: Connect Power Adaptor to mains and to Raspberry Pi.
- Page 3 | Inbody 570 Raspberry Pi Setup Instructions STEP 7: Now that the STEP 8: Enter Administrator STEP 9: Press arrow to hardware is connected you will Password (0000) and press navigate to 2nd page. need to configure the scales. Enter On the scales screen press Administrator Menu.
