Summary of Contents for Cabrio Dome 41400
-
Page 1: Table Of Contents
3: step 4: Putting arches together step 5: Pushing arches into a foil step 6: Pulling rope Manual Pulling Cabrio Dome over swimming pool Right tension of expander ropes 7 Right positioning of insert tubes Collapsing Cabrio Dome Saftey rules... -
Page 2: Introduction
Introduction Cabrio Dome is a collapsible swimming pool cover. With a simple pull at the rope, you can cover or uncover a swimming pool. Arches Two collapsible arches stretch the foil over a swimming pool. Each arch consist of four parts (20) that are connected with aluminium tubes (21), (22) and (23). -
Page 3: Step 2: Marks For Hooks And Fastener
Step 2: Marks for hooks (13) and fastener (28) (fig. 2.1 to 2.5) Marks for hooks (13), fastener (28) Mark marks for hooks starting from starting point “M” in a “S” (cm) Size (m) distance of 60 cm around the swimming pool 5-10 cm under ... -
Page 4: Step 3: Fixing "C" Profile
Adjust length of support (6) by sawing. The ground under the support must be solid. Stick at the end of “C” profile a fastener (28/B) according to (fig. 3.4). This fastener is very important when erecting the Cabrio Dome. fig. 3.2 Abb. 3.4 In ground swimming pools Fixing the „C“... -
Page 5: Step 4: Putting Arches Together
A connecting rope (24) is used by swimming pools bigger than 4.0m to prevent hanging down of the dome. When Cabrio Dome is erected, the connecting rope () must be under easy tension. Step 5: Pushing the arches into the foil ... -
Page 6: Manual
(28/A). (fig 7.1). If not, the Cabrio Dome can collapse on the other side while pulling. ... -
Page 7: Right Tension Of Expander Ropes
Right positioning of insert tubes (fig. 9.1/9.2) The design of Cabrio Dome makes possible a fold free form by minimal tension in expander ropes (11). If fold occur so is the expander rope under the fold to heavy tensioned. -
Page 8: Collapsing Cabrio Dome
10.3 Cabrio Dome resist wind (up to 3 Bf) but has to be removed from the swimming pool in case of storm. When windy close the doors. Cabrio Dome is not a cover suitable for winter and should be removed from a swimming pool. Store the foil dry and clean.
