MARKSETBOT SETUP GUIDE
Welcome to the MarkSetBot family! By using MarkSetBot, you're not only creating an easier
world for your race committee and other race organizers, but you're helping to move race
administration and sailing to a new, more efficient, environmentally friendly, and technological
platform. But, perhaps most importantly, you've invested in a product and a company vested in
growing sailing. So, please reach out to us at sales@marksetbot.com or
marksetbot.zendesk.com with any questions, concerns, or comments!
Hopefully by now you've received your Bot and all of the parts surrounding it. This document
along with the video series found here: https://youtu.be/5Svco93sYDI should help to guide you
through the process of setting up and activating your Bot!

WHAT IS IN THE BOXES:

- 62" x 16" x 10" box
o 1 Minn Kota Electric Trolling Motor
o 1 Minn Kota propeller
o 1 frame
o 1 ProNav upper unit
o 1 Retaining strap for Pelican case (goes between Port and Starboard deck bars
o Fasteners: Frame and deck bolts (built in to plywood shipping mount)
▪ 6 x 2.75" carriage bolt
▪ 6 x 1/4 20 wing nuts
▪ 2 x spare carriage and wing nuts
26" x 18" x 18" box
-
o 1 deck (black) with ProNav lower unit attached
o 1 Pelican Box
▪ 1 Nexus smartphone; this is the "brain" of the Bot – Unless otherwise
specified, you need to provide your own SIM card. If the Nexus 5x, you need
a nano SIM. If the Nexus 5, you need a micro SIM
▪ 1 USB-C Charger
▪ 1 lithium-ion battery
▪ 2 Y connectors
o 1 grey padded bag containing:
▪ 1 air compressor
▪ 1 air compressor tube
o 1 kit containing
▪ 110v to lithium-ion battery charger
▪ Patch kit
▪ Zip ties
o 2 pontoons
o 1 rudder
