Summary of Contents for D&R ELECTRONICS 934-0485A
- Page 1 934-0485A Custom Tahoe Storage INSTALLATION MANUAL CONTENTS Unpacking ——– Installation ——– Warranty ——– REV JAN 31, 2013 Return Policy ——–...
- Page 2 UNPACKING Before beginning any installation, unpack the equipment received. After unpacking, examine ALL components received for any damage that may have occurred while in transit. If any damage has occurred, file a claim IMMEDIATELY with the courier stating the extent of damage. Check ALL envelopes, packing slips, shipping labels and tags before removing or destroying them.
- Page 3 Step 2 Check Mounting location points Carefully open the drawer. Measure and evaluate the mounting locations of the cabi- net. There are four mounting locations. Step 3 Place Retainer Nuts on Sub frame Place Retainer Nuts on Sub frame based on the mounting locations found in Step 2..
- Page 4 Step 4 Place Cabinet on Subframe Carefully place Cabinet on Sub frame and Secure using 3/8 X 1” Hex Bolts, 3/8” Lock Washers and 3/8” Washers on locations found in Step 2. Step 5 Close the Drawers...
- Page 5 Step 6 Replace the Cabinet Top, replace front four bolts and washers removed in Step 1. Step 7 Cargo Partition Insert Cargo partition and cargo partition bracket. Replace the remainder of the top hardware to attach the partition to the cabinet. Arrow pointing to side bolt location, 1 on each side 2x 1/4-20 x 1/2 Hex bolt, 2pc Flat washer and 1/4-20 Nyloc Nut.
- Page 6 WARRANTY D & R Electronics warrants its new products to be free from defects in material and workmanship, under normal use and service for a period of one year on parts replacement and one year on labor. This warranty applies only to original purchasers acquiring the product directly from D&R Electronics, or its authorized dealers.
