Page 1: Table Of Contents
Easy HD Expressway! DC-103 Quick Installation Guide PACKAGE CONTENTS POWER ON CONNECT TO A DVB-T RECEIVER ADJUST THE FOCUS OF THE LENS CONNECT TO A CVBS MONITOR MIC-IN USB UART PORT MONITOR BOOT MESSAGES CUSTOM CONFIGURATION MODULATION SETTING DESCRIPTION THE CHANNEL DATA RATE MUST BE LARGER THAN THE VIDEO ENCODING BIT RATE. -
Page 2: Package Contents
Easy HD Expressway! Package Contents DC-103 Camera USB UART configuration board MCX to SMA female connector A special USB cable for firmware update 12 V DC-in USB UART Configuration board CVBS Video Output DVB-T RF Video output... -
Page 3: Power On
Power on Apply 12V DC to DC-103. It will take about 40 seconds for DC-103 to boot. When the boot process is completed, it begins to transmit the camera video from the SMA connector in DVB-T, and the CVBS output is also present. -
Page 4: Adjust The Focus Of The Lens
By default the focus of the lens may not be correct. Please turn the lens clockwise or anti-clockwise to get the best focus. Connect to a CVBS monitor A CVBS video output is optional. If it’s enabled, when the system boot is completed, there is a standard CVBS video output (default PAL). WWW.HIDES.COM.TW... -
Page 5: Mic-In
Mic-in If it’s bare bone DC-103, a condenser microphone is included. If DC-103 with housing, a 3 .5mm Phone Jack is provided. Note: By default MIC-in feature is disabled. When you want to enable MIC-in feature, it’s recommended to disable CVBS output with the configuration kit for better audio quality. -
Page 6: Usb Uart Port
Easy HD Expressway! USB UART PORT The USB UART port can be used to configure DC-103 or monitor the system boot status. You may connect the UAB UART to a Laptop PC. On most Windows platforms, the driver will be installed with in-box driver automatically. -
Page 7: Monitor Boot Messages
Easy HD Expressway! Monitor Boot Messages When you connect the USB UART port to a Laptop PC, and driver is well installed, you may use any UART terminal application to monitor debug message. The default communication parameters are 115200,n,8,1. WWW.HIDES.COM.TW... -
Page 8: Custom Configuration
Launch “iTE_SerialTool.exe “. Specify the correct COM port which corresponds to the USB UART port, then click on “Open” button. The following shows the USB UART port is open successfully. Click on “Get” button to retrieve current configurations. WWW.HIDES.COM.TW... -
Page 9: Modulation Setting Description
Options: 1000, 2000, 3000, 4000, 5000, 6000, 7000 and 8000KHz. Constellation ccHDtv DTVCAM constellation options. 0: QPSK 1: 16QAM (In 16QAM mode, only Guad Interval 1/4 and 1/8 are supported) Note:64QAM is not supported by DC-103 CodeRate ccHDtv DTVCAM code rate options. WWW.HIDES.COM.TW... -
Page 10: The Channel Data Rate Must Be Larger Than The Video Encoding Bit Rate
Maximum bit rate = 1512 / 2048 * 188 / 204 * 64 / 56 * TBandwidth * Tcode_rate * TConstellation * TGuardInterval (bps) = 423 / 544 * TBandwidth * Tcode_rate * TConstellation * TGuardInterval (bps) Refer to the table shown below. The channel data rate MUST be larger than the video encoding bit rate. WWW.HIDES.COM.TW... - Page 11 1 / 16 1 / 2 5854671 6830450 13660900 7806228 15612457 1 / 16 2 / 3 1 / 16 2 / 3 7684256 15368512 8782007 17564014 1 / 16 3 / 4 1 / 16 3 / 4 WWW.HIDES.COM.TW...
-
Page 12: Video And Other Setting Description
Higher GOP , higher compression efficiency but poorer quality Select the TV standard for the analog video CVBS output CVBS PAL, NTSC or Disable Fast Playback Mode can shorten the latency at the cost of video Fast Playback Disabled WWW.HIDES.COM.TW... - Page 13 Channel provider name (for SDT) [Hides] Service Name Channel service name (for SDT) [DC-103] SIPSI_Table_Duration Duration in minutes. 0: SI/PSI table always be sent N: After N minutes, TS SI/PSI table will not be sent. And the TV system could only scan the DTVCAM channel in this period.
-
Page 14: Update Firmware
3. Connector USB UART to a laptop PC and launch a UART terminal application (like “Tera Term” ). 4. Connect the UART terminal to DC-103 UART port with the parameters 115200,n,8,1 Note: it’s recommended to switch off Local echo on the terminal. - Page 15 Easy HD Expressway! 5. Power on DC-103 (Note: Do NOT attach USB disk when DC-103 is powered on.). 6. Wait until you see the following messages on the terminal. 7. You may attach the USB disk with the special USB cable...
- Page 16 If it successes, there is no message. ./updateFW.sh Comment: If it successes, there are some messages, kernel version is : 3.0.8 Ready copy driver and sdkCam2TV_UART !! copy 1080P configure file cd /;umount /mnt Refer to the following example, WWW.HIDES.COM.TW...
- Page 17 Easy HD Expressway! 10. Remove the USB cable and disk 11. Power off DC-103 12. Attach(Recover) the USB connector cable WWW.HIDES.COM.TW...
-
Page 18: Rf Board
Easy HD Expressway! RF Board WWW.HIDES.COM.TW... - Page 19 Easy HD Expressway! WWW.HIDES.COM.TW...
- Page 20 Easy HD Expressway! WWW.HIDES.COM.TW...
- Page 21 Easy HD Expressway! WWW.HIDES.COM.TW...
