Compotents
REF
Illustration
A
B
C
D
Assembly Instruction CL-802/702
Description
Seat
Seat supports
10-1.50mm x 75mm
bolts
washers
Wedge Anchors
QTY
1
2
4
4
4
Advertisement
Table of Contents
Related Manuals for Canaan CL-802
Summary of Contents for Canaan CL-802
- Page 1 Assembly Instruction CL-802/702 Compotents Illustration Description Seat Seat supports 10-1.50mm x 75mm bolts washers Wedge Anchors...
- Page 2 Assembly Instruction CL-802/702 Tools Required Long arm hex key, wrench, and linesman plier. Recommendations * To protect the powdercoating finish during assmebly, please place unwrapped powdercoated parts on non-marring surface. Please do not place parts on cement or other hard surface. If damage on finish occurs, please use touch-up paint to avoid rust in future.
- Page 3 Instruction for Surface Installation CANAAN INC. Instruction for Surface Installation 1. Drill the proper size and depth hole. That the holes are too large can usually be detected earliest when the wedge anchors moves forward by more than a fraction of an inch (1/4” max) during tightening.
