Weaver Leather Original Cougar Saddle Instructions

Instructions for the Original Cougar Saddle
Front View
- Original Cougar Saddle
m
a- Leg Straps
b- Batten Seat
c- Accessory Elastic Strap
d- Ladder Lock
e- Rope Bridge Adjustment Strap Buckle

To Replace the Rope Bridge or Rubber Bumpers:

Disassembling the Cougar Saddle

1. Unlatch the Velcro on the leg strap (a) or batten seat (b) and unbuckle the
®
strap completely. Remove the slide that's on the quick-link buckle. Pull the
leg strap through the leg strap connector (n), as shown in figure A. If completely
removing to change from the leg straps (a) to the batten seat (b) or vise versa,
flip the saddle over, remove the saddle's leg straps (a) or batten seat (b). First,
undo the accessory elastic strap (c) by running it back through the ladder lock (d)
on the saddle's back.
2. Repeat the same procedure with the other leg strap (a) or batten seat (b).
3. Unbuckle the buckle on the waist back for the rope bridge adjustment strap (e),
as shown in figure B1. Pull the adjustment strap (f) through the side dee (g),
through the nylon loop (h), through the elastic loop (i) and through the ring (j)
on the rope bridge, as shown in figure B2.
figure B1
and the Cougar Saddle with Batten Seat
k
j
l
a
f- Rope Bridge Adjustment Strap
g- Side Dee
h- Nylon Loop
i- Elastic Loop
j- Ring
Rear View
h
e
g
f
i
n
figure B2
- Cougar Saddle with Batten Seat
o
d
c
b
k- Rope Bridge
l- Rubber Bumpers
m- Leg Strap Buckle
n- Leg Strap or Batten Seat Connector
o- Elastic Billet Holder
figure A
