HU-SOUTHWEST-1480

"Humidaire Southwest"

Gas-Fired

Humidaire Unit

Table of Contents

Summary of Contents for SAMUEL JACKSON Humidaire Southwest

Page 1 HU-SOUTHWEST-1480 “Humidaire Southwest” Gas-Fired Humidaire Unit...
Page 2: Table Of Contents
Electrical Schematic for Conditioning Hoppers Relay Panel ..81 13860 Relief Plug Assembly Installation ........82 Copyright © 2005 SAMUEL JACKSON, INCORPORATED. All rights reserved PAGE 0 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 3 Humidaire Unit installation will then go smoothly with no delays waiting or looking for missing parts. If the Humidaire Unit is part of a Samuel Jackson Conditioning Hopper Moisture System or a Steamroller System, more detailed information for your system will be shipped to you under separate cover.
Page 4: Introduction
415 Volts, 3 Phase, 50 Hz 380 Volts, 3 Phase, 50 Hz Drainage facilities should be provided for water drainage of 500 to 1000 US Gal/24 Hrs (typical). PAGE 2 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 5: Summary Of New Features
A single Moisture Mirror II will act as a common remote control for a maximum of four 1400 series Humidaire Units and eight Samuel Jackson 1400 series heaters at the same time. In addition to this, the Moisture Mirror II, properly equipped with sensors, can control the temperature of the Humidaire automatically while coordinating the interaction of all of your Sam Jackson moisture control products.
Page 6: Humidaire Unit Operation
This number will be helpful to the technician that offers assistance if you call the factory. Many PAGE 4 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 7 If it finds a problem with one of these devices, it alerts the operator with an ALARM or ERROR message that corresponds to the problem. PAGE 5 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 8 In all cases, the air temperature is adjusted manually. More details for operation with the optional Moisture Mirror II is described later in the manual. PAGE 6 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 9 Use the arrow buttons (“<” or “>”) to increase or decrease temperature settings (setpoint). Access this screen by pressing the large question mark button (“?”) on the home screen. Speedometer Screen PAGE 7 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 10 (part number 20750) and shrink in place with a propane powered heat gun. Heat guns are available from the factory for rental or purchase. PAGE 8 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 11 The flanges are where most leakage will occur. If the flanges are wrapped, then this water is captured and will soak the insulation. PAGE 9 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 12 52-E/C Seed Cotton Cup Electrode (Part No. 16003A). 30-E/C Bale Moisture Probe (Part No. 16002A) 830-T/C Tee Handle Module Moisture Probe, 38 inch long (Part No. 16876A) PAGE 10 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 13: Moisture Mirror Ii Option
Mirror II, offering remote control (normally from ginner’s console) of the unit via a CAT-5B Ethernet connection. It has the ability to control up to four 1400 series Samuel Jackson Humidaire Units and eight 1400 series Samuel Jackson Heaters. When the Moisture Mirror II is equipped with compatible moisture sensors at various stages in the ginning process it offers automatic dryer temperature control.
Page 14 Press “PUMP ON” and “PUMP OFF” buttons to enable or disable water pump Press “START” and “STOP” buttons to turn flame on and off PAGE 12 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 15 The maximum air temperature setting is 155 ° F [68 ° C]. Operating the Humidaire Unit at high temperatures will shorten its life. PAGE 13 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 16: Water Watch
Total gallons of intake and purge water since the counter was last reset Current average evaporation rate in gallons per minute PAGE 14 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 17: Tru-Temperature Diagnostic System
If a low water temperature condition persists for more than 30 minutes the Humidaire Unit is turned off and a message is displayed. PAGE 15 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 18: Powdered Acid Descaler
Many Humidaire Unit users find it handy to attach a garden hose with a spray nozzle for spray chamber cleaning to the hose faucet provided just before the fresh water inlet on the water tank. PAGE 16 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 19: Suggested Routine Water System Maintenance
(SCRN1). It is normal to find some lint fly sticking to it. This can be easily brushed off to keep water flow water pump unrestricted. PAGE 17 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 21 Closed position is shown here. 43 to 45 PSI on this gage (WPG4) Adjust this ball valve (BV) for correct pressure on WPG4 PAGE 19 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 22: Error & Alarm Logging System
ERROR & ALARM LOGGING SYSTEM The ERROR and ALARM LOGGING SYSTEM is designed to make troubleshooting easier for both the user and Samuel Jackson service personnel. This system remembers the last 500 ERRORS and ALARMS, thus showing a history of past problems.
Page 23: Errors And Alarms Explanation
ERROR. Press OK to clear each ALARM code and then to clear ERROR code 144. After ERROR code 144 is cleared, the operator can attempt to restart the burner. PAGE 21 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 24 Consult the factory if this error becomes a nuisance. Higher switch temperature settings are permissible for some applications. High Temperature Switches SCHT Spray Chamber High Temperature Switch PAGE 22 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 25 Verify setting of water pump motor overload relay MOL at 9.0 amperes • for 480V, or 11.5 amperes for 380V. Verify voltage at one of the following, 380/50, 415/50, or 480/60. • PAGE 23 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 26 Worn water pump impeller. • Blockage of water pump inlet screen. • Failed Water Valve Motor (WVM) or Gas Valve Motor (GVM). • PAGE 24 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 27 Humidaire Unit. For propane systems, check for malfunction of the vaporizer. The GLPS is set to 45 inches water column (about 1.5 PSI). PAGE 25 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 28 This input light should go off. Input light switch A for No. 10 – 17 inputs B for No. 20 – 27 inputs PAGE 26 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 29 Check that SSOV opens and closes. Check for gas leaks. Check operation of SSOV's proof of closure switch. Replace SSOV valve actuator and/or its proof of closure switch. PAGE 27 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 30 ERROR 141 FAN INTERLOCK BYPASSED: Samuel Jackson Humidaire Units are provided with a fan interlock relay (FIR) to provide immediate shutdown of the Humidaire Unit when the humid air fan is turned off. This error indicates that an electrical signal is being received through the fan interlock with no airflow present, effectively bypassing this important safety feature.
Page 31 With the power off, scrape the flame electrode and wipe the ceramic insulator with • a clean cloth. Make sure the power is switched off before doing this. PAGE 29 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 32 (-) junction and WHITE wire is connected to positive (+) junction on transmitter. Reversing these wires will cause this problem. Refer to ELECTRICAL INSTALLATION NOTES section in this manual for more • information. PAGE 30 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 33 ERROR 165 BAD AIR THERMOCOUPLE: The integrity of the thermocouple wiring and thermocouple is checked during the pre-ignition checks each time the Humidaire Unit is PAGE 31 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 34 POWER FAULT DURING OPERATION STAGE: This error means that electrical power was disconnected while the burner was on or during the 10 minute leak test after shutdown. Check for faulty supply wiring connections. PAGE 32 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 35: Test Program
Humidaire Unit to maintain the correct air velocity across the burner head. PAGE 33 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 36 The SETUP screen shown below will come up. Pressing the TEST PROGRAM button accesses the TEST PROGRAM. This button is only displayed when the flame is off. PAGE 34 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 37 Now methodically press each button on the TEST PROGRAM screen to check and make adjustments before attempting to light the unit. Details on each test follow. PAGE 35 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 38 Crack it open a little more and try the test again. Gas low fire valve is Gas Pilot Valve fully closed when (PV) handle is cross ways to pipe. PAGE 36 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 39 (PV) line behind the SSOV block will have to be disconnected to remove the SSOV block. Contact the factory for technical assistance. GPG1 SSOV block Screen on inlet to SSOV block PAGE 37 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 40 (WVM). The PLC will supply 4mA VDC control signal to the WVM to close the valve and 20 mA VDC control signal to open the valve. PAGE 38 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 41 “?” and then the next page button (> Rotate the three color rings so the tabs are in the positions shown here PAGE 39 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 42 Take the Air Flow (V.P.) reading and multiply this number by 0.7. This is the MIN V.P. setting. For example using the screen below, 0.37 X 0.7 = 0.26. Set MIN V.P. to 0.26. Example: 0.37 X 0.70 = 0.26 PAGE 40 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 43 If “PV OPEN TO LIGHT ONLY” setting is used, this valve can be set wide open for easy ignition. PAGE 41 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 44: Additional Settings
Moisture Mirror II is connected to the Humidaire Unit, the Moisture Mirror II has priority over time and date settings making changes to time and date via the color touch panel at the unit null and void. PAGE 42 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 45 (TP). The time that the screen remains in the clean screen mode with the buttons inactive is the TIME setting shown in seconds. This time is adjustable. PAGE 43 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 46 Traditional mode of operation may be needed when operating a Humidaire Unit on an unforgiving system or in a cold climate. PAGE 44 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 47 The default password is 1234. Touch the PASSWORD button to go to a screen that allows you to change the default password. The password can be a 1 to 4 digit number. PAGE 45 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 48: Installation Stub-Ups
PROPANE. 5 TO 20 PSI (0.3 TO 1.4 BARS). DO NOT RUN UNDER FLOOR. WATER SUPPLY FOR HUMIDAIRE 3/4” WATER LINE, 20 PSI MIN. UNIT PAGE 46 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 49 120VAC to unit. No other source of power is connected to unit. Gas Supply Connection Compressed Air Connection Water Supply Connection Connect 2 inch PVC water drainage line (gravity flow) here. PAGE 47 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 50 See Drawing CA15110A in this manual for electrical Electrical Panel hookup information. PAGE 48 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 51: Installation Notes And Instructions
It may be located on the discharge side of the fan, especially where two valves are used to distribute humid air to two points of application. PAGE 49 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 52 AND DRYING HEATERS included in this manual. Some local authorities may require piping the screened vent opening of the gas regulator to the outside of the building. PAGE 50 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 53 The gin’s septic system is not a good choice for the drainage water to run into. The septic system will quickly overflow from the purge water. PAGE 51 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 54 Humidaire’s PLC control system will verify the presence of the fan interlock before permitting operation. If bypassed, the Humidaire will signal this as an error later in operation. PAGE 52 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 55 (see picture below) and between the flange fitting connecting the hood to the square-to-round transition. Apply Silicone to Outlet Hood Flange Joints PAGE 53 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 56: 14900A Lint Flue Scanner Installation, Settings And Use
The 14900A control is used to determine when cotton is passing through a lint flue. It is used with the Samuel Jackson Humidaire Unit to operate its water pump only when cotton is being ginned. The 14900A control has a special mount which allows the 14953 photoelectric infrared scanner to look through a tiny window at the oncoming flow of air and lint.
Page 57 The voltage of the power supply for the load can be different from that supplied to the scanner on terminals 1 and 2. PAGE 55 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 62: Gas Piping
NFPA on the referenced subject, which is represented only by the standard in its entirety. PAGE 60 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 70: Component List
CONTROL VOLTAGE TRANSFORMER BOX BELOW 16480A, 480/380-120 DISCONNECT SWITCH AIR CYLINDER FLUSH PIPE 14471, 1.2 X 3 INCH DOOR SPRAY CHAMBER DOOR SPRAY CHAMBER 21400 PAGE 68 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 71 GAS LOW PRESSURE SWITCH MIDDLE CABINET 21332, D217089 GAO-A2-4-8 GPG1 GAS PRESSURE GAGE MIDDLE CABINET 19188, 2 1/2”, 0-5 PSI, 1/4 NPT DIAPHRAM, CENTER BACK MOUNT PAGE 69 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 72 21539, LC1D18G7 MIST MIST ELIMINATOR SPRAY CHAMBER 21412A WATER PUMP MOTOR OVERLOAD RELAY UPPER CABINET 21538, LRD16 WATER SPRAY NOZZLE SPRAY CHAMBER 13900, STAINLESS STEEL PAGE 70 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 73 21335, D222826 DMV-D512/11 THERMOCOUPLE (AIR) MOIST AIR PIPE 21708, 8”, TYPE ‘J’, 0-777, 4-20mA TRANSMITTER THERMOCOUPLE (WATER) WATER TANK 21710, 5”, TYPE ‘J’, 0-777, 4-20mA TRANSMITTER PAGE 71 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 74 11277B, 213-2-1/2, 0-60 PSI WPG4 WATER PRESSURE GAGE WATER PIPE 11277B, 213-2-1/2, 0-60 PSI WATER PUMP MOTOR, 7 1/2 HP BASE FRAME 21361, JMM3709T PAGE 72 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 75 7 ½ HP WATER PUMP, FOR 60 HZ, LESS MOTOR BASE FRAME 21360, 4SS85, 5 1/2 INCH DIA IMPELLER TRIM WATER VALVE MOTOR WATER PIPE 21560, M7284A1012 PAGE 73 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 76: Water Flow Diagram
A diagram for the water flow through the HU-SOUTHWEST is shown below. Refer to the previous component drawings and component lists for more information on the components shown in this flow diagram. PAGE 74 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 78: ½ Hp Water Pump Components & Seal Assembly
21904 – 5 1/2 Inch diameter Trim Impeller for 60 HZ 21905A – 6 9/16 Inch diameter Trim Impeller for 50 HZ 14974 – Pump Shaft Seal Kit 21603 – Pump Body O-ring PAGE 76 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 80: Supplemental Section
SUPPLEMENTAL SECTION Following is information on Samuel Jackson moist air applicators for seed cotton and lint cotton and the HG-1-1401A 1-million BTU/hr heater. More detailed information may be shipped to you under separate cover for your particular system. Steamroller Lint Conditioner The Steamroller is the most powerful lint conditioning system available.
Page 81: Hg-1-1401A 1-Million Btu/Hr Heater & Lint Slide Grid
A source for warm dry air is needed for the Steamroller. Hot air is also required for the Moisture Conditioning Condenser (not made by Samuel Jackson). The HU-SOUTHWEST cannot provide this dry hot air. A separate small heater for this, especially in cold climates is required. Samuel Jackson offers a 1-million BTU/hr heater for this job called the HG-1-1401A.
Page 82: Seed Cotton Conditioning Hoppers
Seed Cotton Conditioning Hoppers SAMUEL JACKSON CONDITIONING HOPPERS are used for restoring some moisture to seed cotton before ginning in order to preserve fiber quality. A Humidaire Unit provides the moist air. These special hoppers are installed between the conveyor distributor and the gin stand feeder.
Page 84: 13860 Relief Plug Assembly Installation
Depending on the Conditioning Hopper installation, this device may be located elsewhere. Consult factory for optimal placement of Relief Plug for your installation. PAGE 82 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
Page 86 The modifier of the controls assumes all liability for these consequences. Samuel Jackson, Incorporated 3900 Upland Avenue Lubbock, Texas 79407 806-795-5218 PAGE 84 of 84 HU-SOUTHWEST-1480 GAS-FIRED HUMIDAIRE UNIT © SAMUEL JACKSON, INCORPORATED 2005 ALL RIGHTS RESERVED...
